WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
84
ADVANCED PROGRAMMING
Edit Inhibit Auto Mode
If this mode is turned on, the Bonding sequence will be interrupted at the specified bond allowing the
operator to manually align the bond. The operator needs to hold the “G” key or the GO button during the
bonding sequence for the inhibit mode to take place.
INHIBIT AUTO MODE
INHIBIT AUTO MODE for Bond #5: Off
5=On 6=Copy
7=Prev bond 8=Suggest 9=Next bond
A=Prev option 0=Off G=Next option
To edit “Inhibit Auto Mode”
From the H
OME menu press 4 (EDIT), A (BOND EDIT), 4 (EDIT BOND), and then 8 (INHIBIT AUTO MODE)
Key Format:
Previous
Menu
1
Go To
Device/Type
2
Home
3
4
On
5
Copy
6
Previous
bond
7
Suggest
8
Next bond
9
Previous
Option
A
Off
0
Next option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
85
ADVANCED PROGRAMMING
Edit Speed
From this menu, the operator may specify the speed in which a specific bond is to be place at to reduce
the impact for certain bonds. There are six speeds available for each bond. 0 being the Fastest and 5
being the slowest.
N
OTE! Speed setting 4 and 5 have a 100ms pause at Search elevation for very light
bond forces. This works to cancel the inertia effect resulting from the machine
operating at these higher speeds.
SPEED for Bond #1 is 1
(0 through 5) 5=Slower 6=Copy
7=Prev bond 8=Suggest 9=Next bond
A=Prev option 0=Faster G=Next option
To edit “Speed”
From the H
OME menu press 4 (EDIT), A (BOND EDIT), 4 (EDIT BOND), and then 9 (SPEED)
Key Format:
Previous
Menu
A
Go To
Device/Type
2
Home
3
4
↑
Slower
5
Copy
6
Previous
bond
7
Suggest
8
Next bond
9
Previous
Option
A
↓
Faster
0
Next option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
86
ADVANCED PROGRAMMING
Edit Pre-Bond Delay
Directly after the tool contacts the work surface and counts a specified number of Z-steps into the work, it
has a small pre-bond delay before the ultrasonics are fired. This is done to cancel any remaining motor or
motion vibrations in the machine, and to allow it to make a good solid bond. This option enables the
operator to increase the delay time before the ultrasonic power is used. The default value for this function
is 5 msecs.
PRE-BOND DELAY
DELAY before Bond #5: 5 msecs
4=Key in 5=Increase 6=Copy
7=Prev bond 8=Suggest 9=Next bond
A=Prev option 0=Decrease G=OK
Minimum Pre-Bond Delay = 0 msecs.
Maximum Pre-Bond Delay = 25 msecs.
To edit “Bond Delay”
From the H
OME menu press 4 (EDIT), A (BOND EDIT), 4 (EDIT BOND), and then 0 (BOND DELAY)
Key Format:
Previous
Menu
1
Go To
Device/Type
2
Home
3
Key in
4
↑
Increase
5
Copy
6
Previous
bond
7
Suggest
8
Next bond
9
Previous
Option
A
↓
Decrease
0
OK
G
