2 Operational safety User manual Docking station SIPLACE X-Series S / TX
2.3 ESD guidelines Edition 02/2018
62
2.2.1.2 Warning label W 203
Item no.: 03009342-01
Position of label: See fig. 2.2 - 5
, page 62 )
Number per machine: 2
2
Fig. 2.2 - 4 Warning label W203, item no. 03009342-01
2
Fig. 2.2 - 5 Warning label W203, item no. 03009342-01 - positions of W203
2.3 ESD guidelines
Please observe the instructions about the ESD guidelines specified in the user manual for the
placement machine.
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the machine while it is running!
W 203
W 203
User manual Docking station SIPLACE X-Series S / TX 3 Product description
Edition 02/2018 3.1 Overview
63
3 Product description
Item no. 00116933-01 Docking station for SIPLACE X-Series S /TX
3.1 Overview
3
Fig. 3.1 - 1 Docking station - dimensions in millimeters, connection points
(1) Compressed air connection
(2) CAN bus connection
(3) Power supply connection
1
2
3
3 Product description User manual Docking station SIPLACE X-Series S / TX
3.1 Overview Edition 02/2018
64
3.1.1 Technical data
3
Length x width 950 mm x 930 mm
Height (to centering pin) 864 mm for 900 mm PCB conveyor height
894 mm for 930 mm PCB conveyor height
914 mm for 950 mm PCB conveyor height
Weight 120 kg
Compressed air pressure values p
min
0.5MPa (5.0bar)
p
max
1.0MPa (10.0bar)
Compressed air connection Connection plug KS 2-M5-A
Compressed air consumption 50 Nl/min
*a
*)a Under normal atmospheric conditions at 20°C and 1013 hPa
Supply voltage 88 - 264 V~
Number of wires/phases 3 / 1
Frequency max. 63 Hz
Rated current max. 2 A
Performance 0.8 kW
Fuse 2 x 8A
