4 Operation User manual Docking station SIPLACE X-Series S / TX 4.2 Adjusting the conveyor height Edition 02/2018 70 4.2.1 T ools Y ou will need the following tools to adju st the height of the COT insert: – Allen wrench…
User manual Docking station SIPLACE X-Series S / TX 4 Operation
Edition 02/2018 4.2 Adjusting the conveyor height
69
4.2 Adjusting the conveyor height
The COT insert for the docking station can be easily converted to PCB conveyor heights of 900,
930 and 950 mm.
4
Fig. 4.2 - 1 Adjusting the conveyor height
(1) Holes for the PCB conveyor height
(2) PCB conveyor height 830 mm (2a, 2b, 2c) with hexagonal nut M8 and washer, 2x each
(3) Slot for height adjustment
(4) Sliding plate for docking station
(5) Allen screw M5x12, 4 x (for the cover on electrical components)
(6) Guidance
(7) Hexagon socket-head screw M8x18, 2x
(8) Side panel, COT insert
(9) Cover on electrical components
(10)Feeder module control unit (FCU)
1
950 mm
930 mm
900 mm
2a
3
4
5
6
7
8
9
10
830 mm
2b
2b
3
4 Operation User manual Docking station SIPLACE X-Series S / TX
4.2 Adjusting the conveyor height Edition 02/2018
70
4.2.1 Tools
You will need the following tools to adjust the height of the COT insert:
– Allen wrench, set
– Fork wrench, SW 13
4.2.2 Converting the COT insert to other heights
Disconnect the docking station from the power supply.
Disconnect the docking station from the compressed air supply.
The weight of the COT insert is approx. 40 kg.
If required, enlist the help of a second person to help you with the conversion.
Follow the steps in the order described.
4.2.3 Converting the COT insert to heights of 900, 930 or 950 mm
4
Fig. 4.2 - 2 Order of conversion steps
Loosen the two hexagon socket-head screws M8x18 (item 7 in fig. 4.2 - 1, page 69) and re-
move the left and right guidance (item 6 in fig. 4.2 - 1
, page 69 ).
Loosen the Allen screws M5x12, 4 x (item. 5 in fig. 4.2 - 1, page 69) and remove the cover on
the electrical components (item 9 in fig. 4.2 - 1
, page 69 ).
1
950 mm
930 mm
900 mm
2
2
2
1
1
830 mm
User manual Docking station SIPLACE X-Series S / TX 4 Operation
Edition 02/2018 4.2 Adjusting the conveyor height
71
4
Unscrew the two screwed connections (item 2a in fig. 4.2 - 1, page 69 ).
Loosen the two other screwed connections (item 2b in fig. 4.2 - 1, page 69 ).
Remove the two M8 hexagonal nuts and washers (item 2c in fig. 4.2 - 1, page 69 ).
Hold the COT insert by its side (item 9 in fig. 4.2 - 1, page 69) and remove the two hexagon
socket-head screws M8x40 here.
Swivel the COT insert to the next highest position.
Fasten the side panel at this point. Tighten the nuts loosely to do this.
Hold the COT insert by the FCU (item 10 in fig. 4.2 - 1, page 69) and remove the screwed
connections at item 2 in fig. 4.2 - 1
, page 69 )
Swivel the COT insert to the next highest position.
Fasten the side panel at this point.
Check that all screwed connections at items 2a, 2b and 2c are tightened firmly.
Fasten the right and left guidances (item 8 in fig. 4.2 - 1, page 69) with the hexagon socket-
head screw M8x18 (item 7 in fig. 4.2 - 1
, page 69 ).
Fit the cover back on the electrical components (item 9 in fig. 4.2 - 1, page 69) and fix into
place with the Allen screws M5x12, 4 x (item 5 in fig. 4.2 - 1
, page 69 ).
4
CAUTION
Risk of damage!
When raising and lowering the COT insert, cables can be damaged.
When raising and lowering the COT insert, make sure that no cables are damaged.
PLEASE NOTE
If you want to lower the COT insert to a different height, follow the above instructions
in reverse order.
