WES7 / Win10 - Installation Manual 04/2019 Edition 11 Name SIMATIC BoxPC 627D/827D CPU / clock frequency Intel ® Core( TM ) i3 / 2,40 GHz Exchange PC for 60x: Intel® Celeron® G1820TE / 2,20 GHz RAM 4 GB Harddisk SSD Seri…
WES7 / Win10 - Installation Manual 04/2019 Edition
10
Name
SIMATIC BoxPC 827C
CPU / clock frequency
Intel® Core(
TM
) i3 / 2.13 GHz
RAM
2 GB
Harddisk
HDD
Serial interfaces
1
USB interfaces
Yes
Network
2x 100 MBit
Table 3-6: SIMATIC BoxPC 827C
WES7 / Win10 - Installation Manual 04/2019 Edition
11
Name
SIMATIC BoxPC 627D/827D
CPU / clock frequency
Intel® Core(TM) i3 / 2,40 GHz
Exchange PC for 60x:
Intel® Celeron® G1820TE / 2,20 GHz
RAM
4 GB
Harddisk
SSD
Serial interfaces
1
USB interfaces
Yes
Network
2x 1000 MBit
Table 3-7: SIMATIC BoxPC 627D/827D
Name
SIMATIC MicroBox 427D
CPU / clock frequency
Intel® Core
(TM)
/ 1,6 GHz
RAM
4 GB
Harddisk
SSD
Serielle Schnittstellen
1
USB interfaces
Yes
Network
2x 1000 MBit
Table 3-8: SIMATIC MicroBox 427D
Name
iBASE ABP 102-A
CPU / clock frequency
Celeron® Dual Core T3100 / 1.9 GHz
RAM
2 GB
Harddisk
HDD
Serial interfaces
1
USB interfaces
Yes
Network
2x 1000 MBit
Table 3-9: iBASE ABP 102-A
Name
iBASE ABP 402-A
CPU / clock frequency
Intel® Celeron® CPU 1020E/ 2.2 GHz
RAM
4 GB
Harddisk
SSD (SX), HDD (E by SIPLACE)
Serial interfaces
2
USB interfaces
Yes
Network
2x 1000 MBit
Table 3-10: iBASE ABP 402-A
WES7 / Win10 - Installation Manual 04/2019 Edition
12
4 Installation
4.1 Overview
Choose computer configuration
SIPLACE WES7 Configurator
SIPLACE Win10 Configurator
Install and calibrate Touchscreen
BIOS settings on the Station / Coplan /
BulkFeeder X computer
Perform BIOS settings
Back up the machine data
BIOS update on the Station / Coplan /
BulkFeeder X computer
Perform BIOS update
Install WES7/Win10
(DVD or USB stick
suitable for the
computer)
Restore the initial configuration
See section 4.2.
See section 4.2.
Installing the operating system, see section 4.3.
See section 4.3.3►.
See chapter 5.
Figure 4-1: Installation
