WES7 / Win10 - Installation Manual 04/2019 Edition
6
2 Scope of Delivery
A media standard package is available for installing the Windows Embedded Standard 7 and
Windows 10 IoT operating systems.
CAUTION
Installation of the operating system is provided for the computer types mentioned in the
following table only (the computer type is displayed during the BIOS boot or is registered
in the BIOS).
For station software version 605.x (WES7 with 32 bit only):
Operating system DVD Pack WES7(605) V2.6, item no. [00117111-xx]
The DVD package contains:
– SIPLACE WES7 Configurator CD V2.4.3, item no. [00711123-xx]
– SIPLACE WES7 627B/C/827B/C V2.1 DVD, item no. [03101485-xx]
– SIPLACE WES7 627D/827D V1.0 DVD, item no. [03164755-xx]
– SIPLACE WES7 iBASE_102-A V1.0 DVD, item no. [03121253-xx]
– SIPLACE WES7 iBASE_402-A V1.0 DVD, item no. [03121255-xx]
– Installation Manual "Operating Systems Windows Embedded Standard 7 / Windows 10 IoT",
item no. [00198622-xx]
For station software version 7xx:
Operating system USB package WES7(7xx) V3.3, item no. [00117122-xx]
The bootable USB stick contains:
– SIPLACE WinPE for WES7-Restore V2019-1 (to start up the computer)
– SIPLACE WES7 Configurator V2.4.4 (current version for the computer configuration)
– Installation Manual "Operating Systems Windows Embedded Standard 7 / Windows 10 IoT",
item no. [00198622-xx]
– The following image files:
– SIPLACE_WES7x64_iBaseABP402A_V41.wim
– SIPLACE_WES7x64_SIMATICBoxPC827D_V3.wim
– SIPLACE_WES7x64_SIMATICMicroBox427D_V4.wim
– SIPLACE_WES7x86_SIMATICBoxPC627-827B+C_V4.wim
– SIPLACE_WES7x86_iBaseABP402A_V2.wim
WES7 / Win10 - Installation Manual 04/2019 Edition
7
For station software version 7xx:
Operating system USB package Win10(7xx) V1.0, item no. [00117132-xx]
The bootable USB stick contains:
– SIPLACE WinPE for Win10-Restore V2019-1 (to start up the computer)
– SIPLACE Win10 Configurator V1.0.0 (current version for the computer configuration)
– Installation Manual "Operating Systems Windows Embedded Standard 7 / Windows 10 IoT",
item no. [00198622-xx]
– The following image file:
– SIPLACE_Win10x64_SIMATICMicroBox427D_V1.wim
– SIPLACE _Win10x64_iBaseABP402A_V1.wim
The individual packages are also available at the ASM Software Download Center.
WES7 / Win10 - Installation Manual 04/2019 Edition
8
3 Prerequisites for Installation
In Windows, the station computer must be equipped with at least 2 GB memory with WES7, 32-bit
and 4 GB memory with WES7 / Win10, 64-bit respectively. If necessary, station computers in the
field have to be exchanged or upgraded with a memory extension. Please refer to the Technical
Information TI2014-09E04.
3.1 Hardware Components of the Computer System for the
Station / Coplan / BulkFeeder X Computer
Overview Station computer types
X-series
X-series
S
SX-
series
DX-
series
D-series
TX-
series
CA4
CA4 V2
E by
SIPLACE
SIMATIC
BoxPC
627B/827B
WES7
32 bit
WES7
32 bit
WES7
32 bit
WES7
32 bit
SIMATIC
BoxPC
627C/827C
WES7
32 bit
WES7
32 bit
WES7
32 bit
WES7
32 bit
WES7
32 bit
WES7
32 bit
SIMATIC
BoxPC
627D/827D
WES7
32 bit
WES7
32 bit
WES7
64 bit
SIMATIC
MicroBox
427D
WES7
Win10
64 bit
WES7
Win10
64 bit
WES7
64 bit
iBASE ABP
102-A
WES7
32 bit
iBASE ABP
402-A
WES7
Win10
64 bit
WES7
32 bit
WES7
64 bit
Table 3-1: Overview Station computer types
