Machine protection DX4 Page 6 / 11 23.11.2021
Machine protection DX4
Page 5 / 11 23.11.2021
Machine protection DX4
Page 6 / 11 23.11.2021
Machine protection DX4
Page 7 / 11 23.11.2021
Pos. Item no. Description Part marking
1 03078913-04 MONITOR SCD1520-TDC SPARE PART
2 03042042-01 MONITOR SUPPORT X-SERIES
COMPL.
SPARE PART
3 03059594-03 USB-KEYBOARD ACTIVE KEY WITH
TOUCH-PAD
SPARE PART
03076372-01 CENTER HOUSING SX4 LOWER
PART CPL
03002455-01 SUPPORT BLOCK
03076649-01 STOP ANGLE FOR LOCK
03076374-01 HOUSING SX4 LOWER ELEC.CUR.
PART CPL.
03002448-01 LOCK WITH DOUBLE BIT / LOCKING
BAR T=38
03080227-01 SUPPORT PLATE
4 03008853-03 STOP CABLE COMPL. F. CENTER
COVER
SPARE PART
03010689-01 CABLE HOLDER D=4,8MM PANDUIT
19-A
00341997-01 LABEL GROUNDING POINT GNYE
D12.5
03076380-01 CENTER HOUS. LOW, POW. SUPPLY
WELD. ASSY
03009338-01 WARNING LABEL NO. 201
03076375-01 HOUSING LOWER CONTROL PART
SX4 CPL.
03081230-01 HOUSING LOWER CORNER SX4
03080741-01 COVER SX4 BOTTOM PLACE 1
03080893-01 COVERCORNER SX4 PLACE 4
03080875-01 COVERCORNER SX4 PLACE 2
03080890-01 COVER SX4 BOTTOM PLACE 3
5 03085644-01 FLAP COVER FRONT COMPLETE DX4 SPARE PART
03080297-04 FLAP-COVER FRONT, CPL. FOR SX4
6 03085659-01 FLAP COVER TOP COMPLETE DX4 SPARE PART
03080298-01 RETRACTABLE COVER CPL. FOR SX4
03081237-01 HOUSING ASSEMBLY KIT SX4
03079984-01 ASSEMBLY PARTS HOUSING SX4
03067568-02 BUFFER, COVER-GUIDE SPARE PART
03071934-01 GUIDE, CORNER RIGHT
