KLR-1712 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Pa…
KLR-1712
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KGA-M1180-00 LEVELING BOLT ASSY. 4 /
39 92902-05200 WASHER,PLAIN 2
2 KG7-M8503-00 MODULE ADAPTER 1 /
40 90990-12J004 SCREW, BIN. HEAD W/W 12
3 KG7-M8502-01 MIST FILTER 1 /
41 KG7-M8502-40 MIST FILTER ELEMENT 1 Spare parts E
4 KG7-M8501-01 AIR FILTER 1 /
42 KG7-M8501-40 FILTER ELEMENT 1 Spare parts E
5 KLR-M1129-01 PLATE 25-1 1 /
Í
43 KHW-M8582-40 VALVE 1 Spare parts B
6 90990-42J006 JOINT 1 /
Í
44 KHY-M1127-00 COVER,VALVE 1 /
Í
7 90990-42J008 JOINT 1 /
Í
45 KKX-M8596-00 PRESSURE GAUGE 1 /
Í
8 $SL12-03 JOINT 4 /
46 KLR-M1126-01 PLATE 25-2 1 /
Í
9 KLR-M8501-00 EXHAUST VALVE 1 /
Í
47 KLR-M1128-00 BRACKET,USB CABLE 1 /
Í
10 $KM-31 MUFFLER 2 /
Í
48
11 91312-04005 BOLT HEX,SOCKET HEAD 4 49
12 91312-06012 BOLT HEX,SOCKET HEAD 1 50
13 92902-06200 WASHER,PLAIN 1 51
14 91312-04008 BOLT HEX,SOCKET HEAD 2 52
15 98902-03004 SCREW BINDING HEAD 2 53
16 KLF-M6680-00 HNS,ADAPTER USB 1 /
Í
54
17 KHY-M1111-00 PLATE 11 1 /
Í
55
18 KHY-M8504-01 REGULATOR 1
Ozone-proof revision
/
Í
56
19 $SLY10-03 JOINT 1 /
Í
57
20 $TL4-02 JOINT 1 /
Í
58
21 90990-12J004 SCREW, BIN. HEAD W/W 5 59
22 KHY-M1123-00 PLATE 23 1 /
Í
60
23 KHY-M8582-00 VALVE 1 B
Í
61
24 $TL8-01 JOINT 1 /
62
25 $KM-11 MUFFLER 1 /
63
26 91312-03030 BOLT HEX,SOCKET HEAD 4 64
27 91312-05010 BOLT HEX,SOCKET HEAD 12 65
28 KLR-M1123-00 PLATE AMP 1 /
Í
66
29 K46-M641F-00 PARTS, 1-3 2 /
Í
67
30 $BAA1000 DIN RAIL 1 100mm cut /
Í
68
31 90990-11J003 SCREW, PAN HEAD W/W 2 69
32 KLR-M6521-A0 SENS. WAIT AMP ASSY 1
O/P Sub Stopper
/
Í
70
33 KLR-M6522-A0 SENS. POS.1 AMP ASSY 1 TCN 11F /
Í
71
34 KLR-M6523-A0 SENS. POS.2 AMP ASSY 1 TCN 19F /
Í
72
35 KV7-M1125-00 PLATE,CLAMP 1 /
Í
73
36 KLR-M1151-00 PLATE SIDE 1 1 /
Í
74
37 KLR-M1152-00 PLATE SIDE 2 1 /
Í
75
38 KHY-M11B0-00 AIR TAG 1 /
76
1
1
Pneumatic Inlet / Etc
Base
