Fine Details Hyper-fine scanning with parallel blue lasers, perfect for capturing intricate details of parts such as injection molds and gear teeth with exceptional precision. Large Parts Adaptive photogrammetry system to…
Powerful Scan at Your Fingertips
Exceptional Accuracy
Accuracy
With exceptional precision and reliability, KSCAN-E sets a new standard for non-destruc-
tive inspection solutions across various industrial applications.
0.020 mm
Volumetric accuracy when paired with the
MSCAN-L15 photogrammetry system
0.015 mm + 0.012 mm/m
Volumetric accuracy when paired with
800-mm precise scale bar
0.015 mm + 0.015 mm/m
Efficient Measurement
Its innovative quad-cross technology
accelerates point cloud generation.
Combined with a high frame rate and
measurement rate, it greatly enhanc-
es efficiency.
Quad-cross blue laser lines
4×27
Measurements/s
8.29 million
Frame rate
180 FPS
Excellent Detail Capture
Equipped with 17 parallel blue laser lines and
high-performance industrial cameras, the 3D
scanner offers a resolution of up to 0.010 mm.
Combined with DefinSight real-time meshing, it
enables users to accurately capture fine features
such as gaps and slots, ensuring every detail is
clearly presented.
Blue laser lines
17 parallel
Resolution
0.01 mm
05 06
Fine Details
Hyper-fine scanning with parallel blue lasers, perfect for capturing intricate details of parts
such as injection molds and gear teeth with exceptional precision.
Large Parts
Adaptive photogrammetry system to eliminate cumulative errors, excellent for
measuring large parts such as car body and heavy equipment.
Infrared large-area scanning to reduce the number of targets and enhance efficiency.
Scan Anything, Anytime
07 08
-Ensure high volumetric accuracy even in complex, large-scale environments
-Support target optimization through scale bar
-38 infrared laser lines
-Max working distance of up to 1.5 m
-Large scan area of up to 1440 mm * 1000 mm
KSCAN-E is robust, flexible and versatile, ideal for scan-
ning small to large objects wherever you are. With 4×27
quad-cross blue laser lines, the KSCAN-E allows for rapid
data capture without compromising accuracy.
Hole & Edge
High-precision grayscale recognition for various holes and slots.
Supports both laser and grayscale measurements.
Ideal for measuring edges of stamping parts and irregular parts.
Complex Grooves
Deep-hole scanning mode with a single laser line easily scans hard-to-mea-
sure areas such as engine cylinders and internal grooves of cast parts.
Various Applications
Aerospace Automotive
Railway and Ships Mold
Energy & Heavy Industry Non-industry
