Flux Dispenser (Optional) on SIPLACE 80F
4
Retrofitting Instructions
Edition 08/98
Page
2
from 14
q
Retrofitting Instructions Flux Dispenser (Optional) on SIPLACE 80F
4
Edition 08/98
3
from
14
1 Information for Retrofitting / Retrofit Kit
1.1 Purpose of Retrofitting
To ensure reliable flip chip component handling, a flux must be applied to the PCB before components are
placed on it. This ensures that the subsequent soldering process will be reliable. After the flip chip component
has been picked up with the placement head and the position has been measured, the flux dispenser applies
the flux to the PCB at the placement position. The flip chip component is placed immediately after the flux is
applied.
1.2 Preconditions
Software Software Version
Line computer software
≥Version 401.01
Station software (GUI)
≥Version 401.xx
Machine controller software
≥Version 401.xx
Test software SITEST
≥Version 401.xx
1.3 Required Material
Item No.:
− 1 unit of soldering flux for SIPLACE 80F
4
consisting of: 00116418-01
1 unit Dosing pump, complete 00325637-01
1 unit Centering pin 00325166-01
1 unit Rinsing tank, complete 00325184-01
3 unit Centrifugal tube 100 ml. 00325119-01
3 unit Sealing for centrifugal tube 00325120-01
1 unit Test tube rack 00325121-01
1 unit Suction pipe 00325171-01
1 unit Component illumination board, flux 00323901-01
1 unit Cable controller flux pump 00323902-01
1 unit Cable flux monitor 00323903-01
1 unit Cable V24 flux 00324119-01
2 unit Syringe 1 mL 00325632-01
1 unit Camera holder 00325165-01
1 unit Plastic hose PU-3 0.5 m 00305706-01
Flux Dispenser (Optional) on SIPLACE 80F
4
Retrofitting Instructions
Edition 08/98
Page
4
from 14
1 unit Tube coupler Y-PK-3 00305382-01
1 unit Brush holder 00330936-01
1 unit Round brush 00330895-01
20 unit Sealing cap type D 00331025-01
1 unit Special design fluxes: Light barrier PCB version 00331031-01
1.4 Required Tools
− Current service manual for 80F4
− Set of socket head cap screws
− Set of screwdrivers
− Set of open-end wrenches
− Side cutters, small
− Measuring tape
− Drill
− Spiral bit, diameter, 4 mm
− Tap M3
