www.asm-smt.com Maintenance Workflow 1 SIPLACE TX Job Card Edition 08/2017 EN
www.asm-smt.com
Maintenance Workflow 1 SIPLACE TX
Job Card
Edition 08/2017 EN
All names identified by ® are registered trademarks of ASM Assembly Systems GmbH & Co. KG. The remaining trademarks in this publication may be trademarks whose use by third parties
for their own purposes could violate the rights of the owner.
We have reviewed the contents of this publication to ensure consistency with the hardware and software described. Since variance cannot be precluded entirely, we cannot guarantee full
consistency. However, the information in this publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Copyright © ASM Assembly Systems Technical data subject to change
ASM Assembly Systems GmbH & Co. KG
Rupert-Mayer-Strasse 44
81379 Munich
Germany
Item no.: 00198076-01
www.asm-smt.com Printed by ASM Assembly Systems
www.asm-smt.com
Introduction
Safety Introduction
Equipment required for Workflow 1 Maintenance TX-Series
1 Remove tables (COT) and exchange nozzles
2 Empty and clean nozzle reject bin
3 Cleaning the Z-Axis C&P20 P
4 Check and clean the magnetic surfaces of X- and Y-Axis
5 Clean conveyors, lifting tables, gantry cables
6 Clean feeder modules and cut the tapes
7 Return the tables (COT)
8 Check the cover fans
9 Check filter disc: C&P20 P
10 Check nozzle seating: CPP and C&P20 P
11 Endurance run
Table of Contents
