A-6 A1 X フレーム ASSY 左 X f r am e a ss y - L eft ｲﾗｽﾄ 番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 60 7- 683 - 404 - 04 6 ｶｸｱﾅ ﾂｷﾎﾞﾙﾄ 3X8 BOL T ,HE XAGON SOCKET 3X8 26 61 7- 683 - …
A-5
A1
X
フレーム
ASSY
左
X frame assy - Left
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
30 4-455-248-04
X
ﾌﾚ
-
ﾑ
(L)
X FRAME (L)
1
31 4-455-277-02
ﾍﾞｱﾘﾝｸﾞ
ﾎﾙﾀﾞ
- Z
HOLDER (Z), BEARING
1
32 4-455-279-02
ﾓ
-
ﾀ
-
ﾌﾞﾗｹﾂﾄ
BRACKET, MOTOR
1
33 4-455-283-02
ﾍﾞｱﾘﾝｸﾞ
ｵｻｴ
RETAINER, BEARING
1
34 4-455-284-01
ﾅﾂﾄ
ﾎﾙﾀﾞ
- (Z)
HOLDER, NUT (Z)
1
35 4-455-285-03
Z
ﾌﾚ
-
ﾑ
(L)
Z FRAME (L)
1
36 4-455-293-01
Z
ｳﾚﾀﾝ
ｽﾄﾂﾊﾟ
-
URETHANE STOPPER, Z
4
37 4-455-294-01
Z
ｽﾄﾂﾊﾟ
-
ｶﾗ
-
COLLAR, Z STOPPER
4
38 4-455-668-01
FAN
ﾌﾞﾗｹﾂﾄ
FAN, BRACKET
1
39 4-455-670-02
FAN
ﾀﾞｸﾄ
FAN, DUCT
1
40 4-461-729-01
ｶﾗ
- (FWSSB-D17-V14-T5)
COLLAR (FWSSB-D17-V14-T5)
1
41 4-461-775-01
ｸﾞﾘｽ
ｶﾊﾞ
- (LZ, L)
COVER (LZ, L), GREASE
1
42 4-461-776-01
ｸﾞﾘｽ
ｶﾊﾞ
- (LZ, R)COVER (LZ, R),
GREASE
1
43 4-463-629-01
ﾍﾞｱﾘﾝｸﾞ
ﾅﾂﾄ
(Z)
NUT (Z), BEARING
1
44 4-466-199-01
ｹ
-
ﾌﾞﾙ
ｶﾞｲﾄﾞ
ｱ
-
ﾑ
(L)
ARM , CABLE GUIDE (L)
1
45 4-467-281-01
ﾎﾞ
-
ﾙﾈｼﾞ
ﾅﾂﾄ
ﾎﾙﾀﾞ
- (X, L)
BALL SCREW NUT HOLDER (X, L)
1
46 4-467-284-01
ﾍﾞｱﾘﾝｸﾞ
ﾎﾙﾀﾞ
- (X, S)
BEARING HOLDER (X, S)
1
47 4-467-686-01
ｸﾞﾘ
-
ｽ
ｶﾊﾞ
- (X, BT)
GREASE COVER (X, BT)
1
48 4-467-695-01
ｽﾄﾂﾊﾟ
-
ｶﾗ
- (X)
COLLAR (X), STOPPER
4
49 4-468-933-01
ﾎﾞ
-
ﾙ
ﾈｼﾞ
(SDA1520)
SCREW (SDA1520), BALL
1
50 4-700-061-01
ﾍﾞｱﾘﾝｸﾞ
(6000ZZ)
BEARING (6000ZZ)
1
51 4-705-584-11
ｽﾍﾟ
-
ｻ
(SQ-10)
SPACER (SQ-10)
4
52 4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
1
53 4-761-803-11
ﾌｱｲﾝ
U
ﾅﾂﾄ
(
ｼﾖﾘ
ｱﾘ
) (FU00SS)
NUT, FINE U (TREATMENT HAVE)
1
54 7-623-208-22
SW 3,TYPE 2
SW 3,TYPE 2
2
55 7-623-210-22
SW 4,TYPE 2
SW 4,TYPE 2
8
56 7-624-198-21
C
ｶﾞﾀ
ﾄﾒﾜ
10 (
ｼﾞｸ
ﾖｳ
)
STOP RING 10, TYPE C
1
57 7-682-160-01
+P 4X6
SCREW +P 4X6
1
58 7-682-954-01
+PSW 3X25
SCREW +PSW 3X25
4
59 7-683-403-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X6
BOLT,HEXAGON SOCKET 3X6
9
A-6
A1
X
フレーム
ASSY
左
X frame assy - Left
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
60 7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
26
61 7-683-406-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X12
BOLT,HEXAGON SOCKET 3X12
12
62 7-683-411-04
6
ｶｸ
ｱﾅ
ﾂｷ
ﾎﾞﾙﾄ
3X25
BOLT,HEXAGON SOCKET 3X25
4
63 7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8BOLT,HEXAGON
SOCKET 4X8
24
64 7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
4
65 7-683-421-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X12
BOLT,HEXAGON SOCKET 4X12
8
66 7-683-423-04
6
ｶｸｱﾅﾂｷ
ﾎﾞﾙﾄ
4X16
BOLT,HEXAGON SOCKET 4X16
24
67 7-683-427-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X25
BOLT,HEXAGON SOCKET 4X25
4
68 7-683-436-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X12
BOLT,HEXAGON SOCKET 5X12
4
69 7-683-437-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X14
BOLT,HEXAGON SOCKET 5X14
3
70 7-683-440-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X20
BOLT,HEXAGON SOCKET 5X20
4
71 7-683-442-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X25
BOLT,HEXAGON SOCKET 5X25
6
72 7-683-444-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X30
BOLT,HEXAGON SOCKET 5X30
4
73 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
4
74 7-688-005-11
W 5, MIDDLE
W 5, MIDDLE
10
75 4-455-213-01
ﾌﾟ
-
ﾘ
-
ｶﾊﾞ
- X
ｼﾞｸ
(L)
PULLEY COVER X AXIS (L)
1
76 4-471-955-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
UPPER (LZ-R)
CABLE CLAMP UPPER (LZ-R)
1
77 4-471-954-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
UPPER (LZ-L)
CABLE CLAMP UPPER (LZ-L)
1
78 4-455-282-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
S Z
CLAMP S Z, CABLE
1
79 4-455-281-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
L Z
CLAMP L Z, CABLE
1
80 4-471-956-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
ﾌﾞﾗｹﾂﾄ
(LZ)
CABLE CLAMP BRACKET (LZ)
1
81 4-455-280-01
ｾﾝｻ
-
ﾌﾟﾚ
-
ﾄ
Z (L)
PLATE Z, SENSOR (L)
1
82 1-492-214-11
ﾚ
-
ｻﾞ
-
ｾﾝｻ
(ZX2-LD50 0.5M)
SENSOR, LASER (ZX2-LD50 0.5M)
1
83 4-453-818-01
ﾁﾖｳ
ｺﾞｸ
ﾃｲﾄｳ
ﾎﾞﾙﾄ
(CBSTSR3-5)
BOLT (CBSTSR3-5)
8
84 7-683-402-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X5
BOLT,HEXAGON SOCKET 3X5
18
85 7-682-154-01
+P 3X25
SCREW +P 3X25
2
A-7
A2
X
フレーム
ASSY
右
X frame assy - Right
59
75
68
8
27
29
55
64
19
66
55
66
48
23
13
26
53
11
28
25
74
72
45
49
46
50
56
25
70
69
74
71
40
14
20
12
59
24
63
63
38
39
3
58
24
1
4
44
51
2
9
63
10
63
30
63
78
16
5
32
18
61
62
31
61
60
17
33
15
43
34
60
61
80
65
61
59
54
60
63
60
16
7
67
41
54
59
84
79
77
35
83
84
73
63
6
63
21
36
37
83
81
82
85
42
84
76
84
83
66
65
52
57
65
48
66
10
66
47
59
23
22
