A- 11 A 3 XYZ フレーム -2 XYZ f rame - 2 25 30 22 23 1 33 32 3 1 1 4 27 20 19 18 9 5 28 2 26 30 30 17 13 12 17 29 16 24 6 31 21 7 30 31 4 31 30 4 10 30 30 8 21 26 26 21 26 30 30 15 14 15 31
A-10
A2
X
フレーム
ASSY
右
X frame assy - Right
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
60 7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
26
61 7-683-406-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X12
BOLT,HEXAGON SOCKET 3X12
12
62 7-683-411-04
6
ｶｸ
ｱﾅ
ﾂｷ
ﾎﾞﾙﾄ
3X25
BOLT,HEXAGON SOCKET 3X25
4
63 7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
12
64 7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
4
65 7-683-421-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X12
BOLT,HEXAGON SOCKET 4X12
8
66 7-683-423-04
6
ｶｸｱﾅﾂｷ
ﾎﾞﾙﾄ
4X16
BOLT,HEXAGON SOCKET 4X16
24
67 7-683-427-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X25
BOLT,HEXAGON SOCKET 4X25
4
68 7-683-436-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X12
BOLT,HEXAGON SOCKET 5X12
4
69 7-683-437-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X14
BOLT,HEXAGON SOCKET 5X14
3
70 7-683-440-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X20
BOLT,HEXAGON SOCKET 5X20
4
71 7-683-442-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X25
BOLT,HEXAGON SOCKET 5X25
6
72 7-683-444-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X30
BOLT,HEXAGON SOCKET 5X30
4
73 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
4
74 7-688-005-11
W 5, MIDDLE
W 5, MIDDLE
10
75 4-455-213-11
ﾌﾟ
-
ﾘ
-
ｶﾊﾞ
- X
ｼﾞｸ
(R)
PULLEY COVER X AXIS (R)
1
76 4-471-955-11
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
UPPER (RZ-L)
CABLE CLAMP UPPER (RZ-L)
1
77 4-471-954-11
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
UPPER (RZ-R)
CABLE CLAMP UPPER (RZ-R)
1
78 4-455-282-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
S Z
CLAMP S Z, CABLE
1
79 4-455-281-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
L Z
CLAMP L Z, CABLE
1
80 4-471-956-11
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
ﾌﾞﾗｹﾂﾄ
(RZ)
CABLE CLAMP BRACKET (RZ)
1
81 4-455-280-11
ｾﾝｻ
-
ﾌﾟﾚ
-
ﾄ
Z (R)
PLATE Z, SENSOR (R)
1
82 1-492-214-11
ﾚ
-
ｻﾞ
-
ｾﾝｻ
(ZX2-LD50 0.5M)
SENSOR, LASER (ZX2-LD50 0.5M)
1
83 4-453-818-01
ﾁﾖｳ
ｺﾞｸ
ﾃｲﾄｳ
ﾎﾞﾙﾄ
(CBSTSR3-5)
BOLT (CBSTSR3-5)
8
84 7-683-402-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X5
BOLT,HEXAGON SOCKET 3X5
18
85 7-682-154-01
+P 3X25
SCREW +P 3X25
2
A-11
A3
XYZ
フレーム
-2
XYZ frame - 2
25
30
22
23
1
33
32
3
11
4
27
20
19
18
9
5
28
2
26
30
30
17
13
12
17
29
16
24
6
31
21
7
30
31
4
31
30
4
10
30
30
8
21
26
26
21
26
30
30
15
14
15
31
A-12
A3
XYZ
フレーム
-2
XYZ frame - 2
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-798-475-11
ｽｲﾂﾁ
(AV630564)
SWITCH (AV630564)
2
2 2-022-865-01
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｱｲ
3M6X10)
PIN, PARALLEL (DIA. 3M6X10)
2
3 3-879-759-01
ﾛ
-
ﾗ
ﾌｵﾛｱ
(NART6-VR)
FOLLOWER (NART6-VR), ROLLER
2
4 4-152-940-11
ﾐﾆﾁﾕｱ
ｶﾑ
ﾌｵﾛｱ
(CFS4)
FOLLOWER (CFS4), MINIATURE
CAM
8
5 4-474-883-01
ｴﾙﾎﾞｶﾝ
ﾂｷﾞﾃ
(KQ2K08-01AS)
JOINT, ELBOW (KQ2K08-01AS)
2
6 4-442-207-01
ｴﾙﾎﾞｶﾝ
ﾂｷﾞﾃ
(KQ2K06-M5N)
JOINT, ELBOW (KQ2K06-M5N)
2
7 4-455-643-01
ﾛ
-
ﾗ
-
ﾌﾞﾗｹﾂﾄ
BRACKET, ROLLER
2
8 4-455-644-01
ﾛ
-
ﾗ
-
ｼﾔﾌﾄ
SHAFT, ROLLER
2
9 4-455-646-04
ﾍﾞ
-
ｽ
ﾌﾟﾚ
-
ﾄ
PLATE, BASE
2
10 4-455-649-01
Z
ｼﾞｸｶﾞﾜ
ﾍﾂﾄﾞ
ｳｹ
ﾌﾞﾛﾂｸ
HEAD RETAINER BLOCK, Z AXIS
2
11 4-455-650-02
ｶﾑ
ﾌｵﾛﾜ
ﾌﾞﾗｹﾂﾄ
BRACKET, CAM FOLLOWER
2
12 4-455-652-02
ｶﾑ
ｼﾔﾌﾄ
SHAFT, CAM
2
13 4-455-653-02
ｶﾑ
CAM
2
14 4-455-654-02
ｶﾑ
ﾌﾞﾗｹﾂﾄ
BRACKET, CAM
2
15 4-455-655-01
ｻｲﾄﾞ
ﾌﾟﾚ
-
ﾄ
PLATE, SIDE
4
16 4-455-656-01
ﾊﾝﾄﾞﾙ
HANDLE
2
17 4-455-665-01
ﾌﾗﾝｼﾞ
ﾌﾞﾂｼﾕ
(30F-0810)
BUSHING (30F-0810), FLANGE
4
18 4-455-698-01
ﾊﾟﾂｷﾝ
(
ﾊﾞｷﾕ
-
ﾑ
)
PACKING (VACUME)
2
19 4-455-699-01
ﾊﾟﾂｷﾝ
(
ﾌﾞﾛ
-)
PACKING (BLOW)
2
20 4-455-700-01
ﾊﾟﾂｷﾝ
ﾎﾙﾀﾞ
-
HOLDER, PACKING
2
21 4-457-189-01
ﾅｲﾛﾝ
ｸﾘﾂﾌﾟ
(AB-2N)
CLIP (AB-2N9, NYLON
6
22 4-459-059-01
ｾﾝｻ
-
ﾌﾞﾗｹﾂﾂﾄ
BRACKET, SENSOR
2
23 4-459-060-01
ｲﾀﾅﾂﾄ
(Z
ｼﾞｸ
)
NUT PLATE (Z AXIS)
2
24 4-459-186-01
ｲﾝﾃﾞﾂｸｽ
ﾌﾟﾗﾝｼﾞﾔ
(PMX-4-A)
INDEX PLUNGER (PMX-4-A)
2
25 4-459-203-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
2.3X10BOLT,
HEXAGON SOCKET 2.3X10
4
26 4-716-688-01
ｷﾖｸ
ﾃｲﾄｳ
ｷﾔﾂﾌﾟ
ｽｸﾘﾕ
- (M4X6)
SCREW, CAP (M4X6)
12
27 7-621-555-39
+K 2X5
SCREW +K 2X5
4
28 7-626-317-31
ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
2.5X16
PIN, SPRING 2.5X16
2
29 7-626-320-71
ｽﾌﾟﾘﾝｸﾞ
ﾋﾟﾝ
3X20
PIN, SPRING 3X20
2
