C-5 C1 全体配管図 Pipe diagram ｲﾗｽﾄ 番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 31 4- 447 - 248 - 61 ﾊ - ﾌ ﾕﾆｵﾝ (KQ2H12-02AS) UNION (KQ2H12 - 02 AS), HALF 1 32 4 - 447 - 250 - 11 ｲｹｲ…
C-4
C1
全体配管図
Pipe diagram
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-492-203-11
ｼﾝｸｳ
ﾎﾟﾝﾌﾟ
ASSY
VACUUM PUMP ASSY
1
2 1-492-241-12
ｿﾚﾉｲﾄﾞ
ASSY (
ﾀﾞｲｼﾔ
ﾛﾂｸ
)
SOLENOID ASSY (TROLLEY LOCK)
1
3 1-492-242-13
ｿﾚﾉｲﾄﾞ
ASSY (AIR SUPPLY)
SOLENOID ASSY (AIR SUPPLY)
1
4 1-492-357-11
ﾃﾞﾝｼﾞﾍﾞﾝ
ASSY (
ﾄﾞｱ
ﾛﾂｸ
)
ELECTROMAGNETIC ASSY
1
5 1-492-358-11
ﾃﾞﾝｼﾞﾍﾞﾝ
ASSY (
ｳﾁ
ｶﾊﾞ
-
ｶｲﾍｲ
)
ELECTROMAGNETIC ASSY
1
6 1-798-472-11
ｱﾂﾘﾖｸ
ｽｲﾂﾁ
(ISE30A-C6H)
SWITCH, PRESSURE (ISE30A-C6H)
1
7 1-798-473-11
ｱﾂﾘﾖｸ
ｽｲﾂﾁ
(ZSE30A-C6H)
SWITCH, PRESSURE (ZSE30A-C6H)
1
8 2-023-682-31
ｾｲﾐﾂ
ﾚｷﾞﾕﾚ
-
ﾀ
(IR1010-01-BG)
REGULATOR, PRECISION (IR1010-*
2
9 2-108-828-01
ﾏﾆﾎ
-
ﾙﾄﾞ
(VVQ2000-FPG-02-X9)
MANIFOLD (VVQ2000-FPG-02-X9)
1
10 2-672-089-31
ﾌﾞﾗﾝｷﾝｸﾞ
ﾌﾟﾗｸﾞ
(KQ2P-08)
PLUG (KQ2P-08), BLANKING
2
11 4-271-381-01
ｴｱ
ｼﾘﾝﾀﾞ
(SSD-X-20-10)
CYLINDER (SSD-X-20-10), AIR
2
12 4-294-534-01
ｽﾋﾟ
-
ﾄﾞ
ｺﾝﾄﾛ
-
ﾗ
(AS2002F-06)
CONTROLLER (AS2002F-06), SPEED
6
13 4-436-830-11
ｻｲﾚﾝｻ
(AN15-02)
SILENCER (AN15-02)
3
14 4-446-715-21
ﾚｼﾞﾕ
-
ｻ
(KQ2R06-08A)
REJUICER (KQ2R06-08A)
6
15 4-446-715-51
ﾚｼﾞﾕ
-
ｻ
(KQ2R08-12A)
REJUICER (KQ2R08-12A)
2
16 4-447-053-11
ﾊ
-
ﾌ
ﾕﾆｵﾝ
(KQ2H06-M5N)
UNION (KQ2H06-M5N), HALF
7
17 4-447-063-21
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L06-01AS)
UNION (KQ2L06-01AS), ELBOW
8
18 4-447-063-31
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L06-02AS)
UNION (KQ2L06-02AS), ELBOW
1
19 4-447-063-51
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L08-02AS)
UNION (KQ2L08-02AS), ELBOW
1
20 4-447-063-71
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L12-02AS)
UNION (KQ2L12-02AS), ELBOW
3
21 4-447-063-91
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L12-04AS)
UNION (KQ2L12-04AS), ELBOW
1
22 4-447-107-21
ｽﾄﾘ
-
ﾄ
ｴﾙﾎﾞ
(KQ2L12-99A)
ELBOW (KQ2L12-99A), STREET
2
23 4-447-109-11
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L06-M5A)
UNION (KQ2L06-M5A), ELBOW
4
24 4-447-063-41
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L08-01AS)
UNION (KQ2L08-01AS), ELBOW
2
25 1-482-181-11
FERRITE CLAMP (GRFC-13)
FERRITE CLAMP (GRFC-13)
2
26 4-447-182-11
ﾁ
-
ｽﾞ
(KQ2T06-00A)
JOINT (KQ2T06-00A), TEE
4
27 4-447-186-11
ﾕﾆｵﾝ
ﾜｲ
(KQ2U06-00A)
WYE (KQ2U06-00A), UNION
2
28 4-447-213-21
ｲｹｲ
ﾕﾆｵﾝ
ﾜｲ
(KQ2U06-08A)
WYE (KQ2U06-08A), UNION
6
29 4-447-247-21
ｽﾄﾚ
-
ﾄ
(KQ2H08-00A)
STRAIGHT (KQ2H08-00A)
2
30 4-447-247-41
ｽﾄﾚ
-
ﾄ
(KQ2H12-00A)
STRAIGHT (KQ2H12-00A)
2
C-5
C1
全体配管図
Pipe diagram
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
31 4-447-248-61
ﾊ
-
ﾌ
ﾕﾆｵﾝ
(KQ2H12-02AS)
UNION (KQ2H12-02AS), HALF
1
32 4-447-250-11
ｲｹｲ
ｽﾄﾚ
-
ﾄ
(KQ2H06-08A)
STRAIGHT (KQ2H06-08A)
6
33 4-453-569-01
ﾌﾟﾗｸﾞ
(CYP025-08B29449)
PLUG (CYP025-08B29449)
4
34 4-454-729-01
ﾃﾞﾕｱﾙ
ﾛﾂﾄﾞ
ｼﾘﾝﾀﾞ
(CXSM32-100)
CYLINDER(CXSM32-100), DUAL
ROD
4
35 4-454-742-01
ｻｲﾚﾝｻ
(ANA1-03)
SILENCER (ANA1-03)
1
36 4-454-743-01
ｽﾋﾟ
-
ﾄﾞ
ｺﾝﾄﾛ
-
ﾗ
(AS2201F-01-06SA
CONTROLLER (AS2201F-01-06SA)
4
37 4-455-483-01
ｽﾄﾘ
-
ﾄ
ｴﾙﾎﾞ
(3/8)
ELBOW (3/8), STREET
1
38 4-457-358-01
ﾒｶﾆｶﾙ
ﾊﾞﾙﾌﾞ
(MVP63-J)
VALVE (MVP63-J), MECHANICAL
2
39 4-458-430-01
ｴｱ
ｺﾝﾋﾞﾈ
-
ｼﾖﾝ
(AC30D-02DG-R-A)
AIRCOMBINATION(AC30D-02DG-R-
A)
1
40 4-460-696-01
ｼﾘﾝﾀﾞ
(CJ2D16-150A)
CYLINDER (CJ2D16-150A)
2
41 4-462-965-01
ﾏｲｸﾛ
ｶﾌﾟﾗ
(MC-04SHB)
COUPLER (MC-04SHB), MICRO
2
42 4-463-167-01
ｻｲﾚﾝｻ
(AN05-M5)
SILENCER (AN05-M5)
2
43 4-701-316-01
ｽﾄﾘ
-
ﾄ
ｴﾙﾎﾞ
ELBOW, STREET
1
44 4-702-324-11
ﾎ
-
ｽ
ｴﾙﾎﾞ
(M-5HL-6)
ELBO (M-5HL-6), HOSE
4
45 4-703-607-02
ﾊｲ
ｶﾌﾟﾗ
- (20PM)
COUPLER, HIGH (20PM)
1
46 4-703-619-01
ﾊｲ
ｶﾌﾟﾗ
- (20SH)
SOCKET
1
47 4-705-238-11
ﾏﾆﾎ
-
ﾙﾄﾞ
(KM11-08-12-10)
MANIFOLD (KM11-08-12-10)
1
48 4-707-030-21
ﾊｲｶﾝﾖｳ
ﾃ
-
ﾊﾟ
-
ｽｸﾘﾕ
-
ﾌﾟﾗｸﾞ
(MSWT2)
PLUG, TAPER SCREW (MSWT2)
2
49 4-719-971-01
ﾂｷﾞﾃ
ﾆﾂﾌﾟﾙ
(KQ2N06-99)
NIPPLE, JOINT (KQ2N06-99)
4
C-6
C2
ヘッド部配管図
Head pipe diagram
