A- 19 A5 架台 ASSY -2 Base frame ass y - 2 ｲﾗｽﾄ 番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 30 A- 1944 - 227 -A TROLLEY CONT ACT(M)B MOUNT TROLLEY CONT ACT(M)B MOUNT 2 31 1 - 771 …

100%1 / 204
A-18
A5
架台
ASSY-2
Base frame assy - 2
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 4-138-825-02
ｽｸﾘﾕ
-
ﾌﾟﾗｸﾞ
(M10X1.5)
PLUG (M10X1.5), SCREW
4
2 4-294-534-01
ｽﾋﾟ
-
ﾄﾞ
ｺﾝﾄﾛ
-
ﾗ
(AS2002F-06)
CONTROLLER (AS2002F-06), SPEED
4
3 4-447-063-21
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L06-01AS)
UNION (KQ2L06-01AS), ELBOW
4
4 4-454-729-01
ﾃﾞﾕｱﾙ
ﾛﾂﾄﾞ
ｼﾘﾝﾀﾞ
(CXSM32-100)
CYLINDER(CXSM32-100), DUAL
ROD
4
5 4-454-743-01
ｽﾋﾟ
-
ﾄﾞ
ｺﾝﾄﾛ
-
ﾗ
(AS2201F-01-06SA
CONTROLLER (AS2201F-01-06SA)
4
6 4-454-745-02
LM
ｶﾞｲﾄﾞ
(SHS15V1UU)
LM GUIDE (SHS15V1UU)
8
7 4-454-941-01
ﾚ
-
ﾙ
ｶﾞｲﾄﾞ
1 (L)
RAIL GUIDE 1 (L)
2
8 4-454-941-11
ﾚ
-
ﾙ
ｶﾞｲﾄﾞ
1 (R)
RAIL GUIDE 1 (R)
2
9 4-454-942-02
ﾚ
-
ﾙ
ｶﾞｲﾄﾞ
2
RAIL GUIDE 2
4
10 4-454-942-12
ﾚ
-
ﾙ
ｶﾞｲﾄﾞ
2
RAIL GUIDE 2
4
11 4-454-943-01
ﾃ
-
ﾌﾞﾙ
ｲﾁｷﾞﾒ
ﾌﾞﾛﾂｸ
BLOCK, TABLE POSITIONING
4
12 4-454-944-02
ｻｲﾄﾞ
ﾌﾟﾚ
-
ﾄ
(R)
SIDE PLATE (R)
1
13 4-454-944-12
ｻｲﾄﾞ
ﾌﾟﾚ
-
ﾄ
(L)
SIDE PLATE (L)
1
14 4-454-945-01
ｼﾘﾝﾀﾞ
-
ﾌﾟﾚ
-
ﾄ
CYLINDER PLATE
4
15 4-458-991-01
ｶﾗ
- (8-6-3), Y
ｼﾞｸ
COLLAR (8-6-3), Y AXIS
4
16 4-705-547-11
ﾍｲｺｳ
ﾋﾟﾝ
(A4X10)
PIN, PARALLEL (A4X10)
12
17 4-719-971-01
ﾂｷﾞﾃ
ﾆﾂﾌﾟﾙ
(KQ2N06-99)
NIPPLE, JOINT (KQ2N06-99)
4
18 7-683-408-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X16
BOLT,HEXAGON SOCKET 3X16
8
19 7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
32
20 7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
24
21 7-683-423-04
6
ｶｸｱﾅﾂｷ
ﾎﾞﾙﾄ
4X16
BOLT,HEXAGON SOCKET 4X16
48
22 7-683-452-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X10
BOLT,HEXAGON SOCKET 6X10
4
23 7-683-457-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X20BOLT,HEXAGON
SOCKET 6X20
12
24 7-683-465-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X40
BOLT,HEXAGON SOCKET 6X40
8
25 7-683-472-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
8X16
BOLT,HEXAGON SOCKET 8X16
4
26 A-1921-158-A
ﾀﾞｲｼﾔ
ｼﾞﾖｳｼﾖｳ
ｾﾝｻ
(B) ASSY
SENSOR (B) ASSY, FLATCAR RISE
1
27 1-492-199-22
SAFETY SW ASSY (
ﾀﾞｲｼﾔ
) R
SAFETY SW ASSY
1
28 1-492-199-32
SAFETY SW ASSY (
ﾀﾞｲｼﾔ
) L
SAFETY SW ASSY
1
29 A-1944-226-A
TROLLEY CONTACT(M)A MOUNT
TROLLEY CONTACT(M)A MOUNT
2
A-19
A5
架台
ASSY-2
Base frame assy - 2
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
30 A-1944-227-A
TROLLEY CONTACT(M)B MOUNT
TROLLEY CONTACT(M)B MOUNT
2
31 1-771-841-11
ﾃﾞﾝｹﾞﾝ
ｽｲﾂﾁ
(D2D-2000)
SWITCH, POWER (D2D-2000)
2
32 2-580-594-01
ﾈｼﾞ
+PSW M3X12
SCREW, +PSW M3X12
8
33 2-580-600-01
SCREW, +PSW M4X8
SCREW, +PSW M4X8
8
34 3-719-601-61
0
ﾊﾞﾝ
P3
ｼﾕ
ﾀﾂﾋﾟﾝ
B2X5
SCREW (B2X5), TAPPING
16
35 4-113-099-01
ｳﾚﾀﾝ
ｸﾂｼﾖﾝ
(1)
CUSHION (1), URETHANE
4
36 4-447-109-11
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L06-M5A)
UNION (KQ2L06-M5A), ELBOW
2
37 4-453-566-01
ｶﾗ
-
COLLAR
4
38 4-455-626-02
ｲﾁｷﾞﾒ
ﾌﾞﾂｼﾕ
(
ｷｼﾞﾕﾝ
)
POSITIONING BUSH (MASTR)
4
39 4-455-627-01
ｲﾁｷﾞﾒ
ﾌﾞﾂｼﾕ
(
ｼﾞﾕｳｿﾞｸ
)
POSITIONING BUSH (SLAVE)
4
40 4-455-637-01
ｾﾝｻ
-
ﾌﾞﾗｹﾂﾄ
SENSOR BRACKET
2
41 4-455-638-01
ｺﾈｸﾀ
-
ﾌﾞﾗｹﾂﾄ
ｱﾂﾊﾟ
-
CONNECTOR BRACKET UPPER
2
42 4-455-639-01
ｺﾈｸﾀ
-
ﾌﾞﾗｹﾂﾄ
ﾎﾞﾄﾑ
CONNECTOR BRACKET BOTTOM
2
43 4-455-640-01
ｺﾈｸﾀ
-
ﾌﾞﾗｹﾂﾄ
ｽﾍﾟ
-
ｻ
CONNECTOR BRACKET SPACER
2
44 4-463-737-01
ｺﾈｸﾀ
-
ﾌﾞﾗｹﾂﾄ
R
ｱﾂﾊﾟ
-
CONNECTOR BRACKET R, UPPER
2
45 4-463-738-01
ｺﾈｸﾀ
-
ﾌﾞﾗｹﾂﾄ
R
ﾎﾞﾄﾑ
CONNECTOR
BRACKET R, BOTTOM
2
46 4-463-739-01
ｺﾈｸﾀ
-
ﾌﾞﾗｹﾂﾄ
R
ｽﾍﾟ
-
ｻ
CONNECTOR BRACKET R, SPACER
2
47 4-471-872-01
ｽﾄﾂﾊﾟ
-
ｽﾍﾟ
-
ｻ
-
STOPPER SPACER
2
48 4-472-320-01
ｺﾈｸﾀ
-
ｶﾊﾞ
-
CONNECTOR COVER
2
49 4-705-597-41
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｱｲ
5)
PIN (DIA. 5), PARALLEL
8
50 7-683-403-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X6
BOLT,HEXAGON SOCKET 3X6
8
51 7-683-422-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X14
BOLT,HEXAGON SOCKET 4X14
4
52 7-683-425-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X20
BOLT,HEXAGON SOCKET 4X20
4
53 7-683-435-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X10
BOLT,HEXAGON SOCKET 5X10
8
54 7-683-437-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X14
BOLT,HEXAGON SOCKET 5X14
16
55 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
12
56 7-688-005-11
W 5, MIDDLE
W 5, MIDDLE
4
57 4-454-899-02
GDI-F
ｲﾝﾅ
-
ｶﾊﾞ
- (L)
COVER INNER (L), GDI-F
1
58 4-454-899-12
GDI-F
ｲﾝﾅ
-
ｶﾊﾞ
- (R)
COVER INNER (R), GDI-F
1
59 7-684-024-04
N 4, TYPE 2
N 4, TYPE 2
32
A-20
A5
架台
ASSY-2
Base frame assy - 2
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
60 7-683-421-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X12
BOLT,HEXAGON SOCKET 4X12
16
61 7-682-265-04
+K 4X16
SCREW +K 4X16
16
62 7-682-561-09
+B 4X8
SCREW +B 4X8
8
63 4-720-311-01
ﾌｱﾝ
ｶﾞ
-
ﾄﾞ
(PG-47-02)
GUARD, FAN (PG-47-02)
4
64 2-672-385-01
ﾌｱﾝ
ﾖｳ
ﾌｲﾙﾀ
- (FL12)
FILTER (FL12), FAN
4
65 1-763-987-11
ﾌｱﾝ
(4715MS-20T-B5A-B01)
FAN (4715MS-20T-B5A-B01)
4
66 4-447-250-11
ｲｹｲ
ｽﾄﾚ
-
ﾄ
(KQ2H06-08A)
STRAIGHT (KQ2H06-08A)
2
