A-72
A23
ノズルチェンジャー
Nozzle changer
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 4-454-437-01
ﾁｴﾝｼﾞﾔ
-
ﾌﾞﾗｹﾂﾄ
BRACKET, CHANGER
2
2 4-457-032-01
ﾌﾞﾛﾂｸ
ﾁｴﾝｼﾞﾔ
- B
CHANGER (B), BLOCK
4
3 4-457-031-01
ﾌﾞﾛﾂｸ
ﾁｴﾝｼﾞﾔ
- A
CHANGER (A), BLOCK
2
4 4-454-407-01
ﾁｴﾝｼﾞﾔ
-
ﾍﾞ
-
ｽ
BASE, CHANGER
4
5 4-454-413-01
ｺﾃｲ
ﾌﾞﾛﾂｸ
(DR)
BLOCK (DR), FIXED
4
6 4-454-438-01
ｵｼ
ﾋﾟﾝ
PIN, PUSH
8
7 4-454-406-01
ﾌﾛ
-
ﾃｲﾝｸﾞ
ｼﾞﾖｲﾝﾄ
JOINT, FLOATING
4
8 4-454-412-01
ｺﾃｲ
ﾌﾞﾛﾂｸ
(DL)
BLOCK (DL), FIXED
4
9 4-454-549-11
ﾍｲｺｳ
ﾋﾟﾝ
(B3X14)
PIN (B3X14), PARALLEL
4
10 4-454-549-41
ﾍｲｺｳ
ﾋﾟﾝ
(B3X28)
PIN (B3X28), PARALLEL
8
11 4-453-817-01
ｼﾘﾝﾀﾞ
(SMG-L-10-10)
CYLINDER (SMG-L-10-10)
4
12 4-455-734-01
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KJL02-M5)
UNION (KJL02-M5), ELBOW
8
13 4-722-778-01
LM
ｶﾞｲﾄﾞ
(C/V
ｸﾗﾝﾌﾟ
)
GUIDE (C/V CLAMP), LM
4
14 4-454-414-01
ｽﾗｲﾄﾞ
ﾌﾟﾚ
-
ﾄ
PLATE, SLIDE
4
15 4-454-405-01
ｽﾗｲﾄﾞ
ｼﾞﾖｲﾝﾄ
JOINT, SLIDE
4
16 4-454-435-01
ｼﾘﾝﾀﾞ
ｼﾞﾖｲﾝﾄ
JOINT, CYLINDER
4
17 4-454-436-01
ｽﾄﾂﾊﾟ
-
ﾌﾞﾗｹﾂﾄ
BRACKET, STOPPER
4
18 4-454-546-01
ｽﾄﾂﾊﾟ
ﾎﾞﾙﾄ
(SUB-4MX20)
BOLT (SUB-M4X20), STOPPER
4
19 7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
32
20 7-683-402-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X5
BOLT,HEXAGON SOCKET 3X5
16
21 7-683-408-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X16
BOLT,HEXAGON SOCKET 3X16
8
22 4-293-429-01
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｱｲ
3X5)
PIN (DIA. 3X5), PARALLEL
8
23 7-682-246-09
+K 3X5
SCREW +K 3X5
8
24 7-683-403-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X6
BOLT,HEXAGON SOCKET 3X6
16
25 4-454-764-01
ｱﾂｼﾕｸ
ﾊﾞﾈ
(WL5-15)
SPRING (WL5-15), COMPRESSION
8
26 7-682-248-09
+K 3X8
SCREW +K 3X8
12
27 1-492-211-11
ｷﾝｾﾂ
ｾﾝｻ
(GX-F8A)
SENSOR, APPROACH (GX-F8A)
4
28 4-455-782-21
ﾃｲﾄｳ
ﾎﾞﾙﾄ
(CBSA3-8)
LOW HEAD BOLT (CBSA3-8)
4
29 4-454-408-02
ｶ
-
ﾄﾘﾂｼﾞ
(
ﾎﾝﾀｲ
)
CARTRIDGE (MAIN)
4
30 4-454-434-01
ｼﾞﾕｼ
ﾋﾟ
-
ｽ
PIECE, RESIN
8
A-73
A23
ノズルチェンジャー
Nozzle changer
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
31 4-454-431-02
ｼﾞﾕｼ
ﾋﾟ
-
ｽ
(
ｼｶｸ
)
PIECE (SQUARE), RESIN
16
32 2-919-160-01
ﾍｲｺｳ
ﾋﾟﾝ
(B2X6 SUS)
PIN (B2X6 SUS)
16
33 4-454-432-01
ﾊﾞﾈ
ｶｹ
(
ﾌｱｲ
4)
HOOK (DIA.4), SPRING
8
34 4-454-411-01
ｺﾃｲ
ﾌﾞﾛﾂｸ
(UR)
BLOCK (UR), FIXED
4
35 3-703-360-02
ﾍｲｺｳﾋﾟﾝ
(
ﾌｱｲ
3X8)
PIN, PARALLEL (DIA. 3X8)
4
36 4-454-410-01
ｺﾃｲ
ﾌﾞﾛﾂｸ
(UL)
BLOCK (UL), FIXED
4
37 4-454-409-01
ｼﾔﾂﾀ
- (SUS304)
SHUTTER (SUS304)
4
38 4-454-433-02
ﾁｴﾝｼﾞﾔ
-
ｶﾗ
-
COLLAR, CHANGEA
12
39 4-453-818-01
ﾁﾖｳ
ｺﾞｸ
ﾃｲﾄｳ
ﾎﾞﾙﾄ
(CBSTSR3-5)
BOLT (CBSTSR3-5)
36
40 4-454-441-01
ｼﾔﾂﾀ
-
ﾌﾟﾚ
-
ﾄ
PLATE, SHUTTER
4
41 4-454-430-01
ｼﾔﾂﾀ
-
ｼﾞﾖｲﾝﾄ
(
ｱﾅ
ｼﾖｳ
)
JOINT (HOLE SMALL), SHUTTER
4
42 4-454-548-01
ﾍｲｺｳ
ﾋﾟﾝ
(B0.8X3)
PIN (B0.8X3), PARALLEL
80
43 7-683-406-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X12
BOLT,HEXAGON SOCKET 3X12
16
44 7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
8
45 4-701-529-01
ﾀｲﾏｳﾝﾄ
(MB1)
TIE MOUNT (MB1)
8
A-74
A24
搬送部 バックアップユニット
Backup unit
50
51
49
50
51
53
53
35
52
52
46
47
48
44
45
43
43
42
47
47
47
46
47
45
47
29
40
46
35
35
28
35
35
38
12
40
11
18
32
15
8
37
31
22
31
24
21
20
36
27
2
41
16
14
7
7
23
9
23
6
5
37
37
37
4
37
37
6
23
10
31
24
36
36
31
36
37
31
33
3
17
31
13
41
23
22
38
21
20
38
21
36
19
36
21
19
38
38
36
36
31
31
36
36
37
25
26
39
31
37
30
34
30
34
30
34
31
31
31
31
39
31
40
39
40
1
39
