A- 80 A2 6 電装 BOX -2 Electrical box - 2 34 17 40 33 30 29 15 39 14 12 12 12 30 34 41 38 30 32 5 39 29 12 12 14 15 14 14 30 41 38 4 4 3 21 13 13 16 19 14 43 44 31 39 1 1 1 1 1 1 10 10 10 39 20 7 6 6 6 23 40 35 37 35 37 39…
A-79
A25
電装
BOX-1
Electrical box - 1
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
28 4-472-227-01
ﾌｱﾝ
ﾌﾞﾗｹﾂﾄ
BRACKET, FAN
2
29 4-705-232-11
ｶｸｶﾞﾀ
3
ｺﾞｳ
ﾄﾂﾃ
(A165-4)
HANDLE 3, SQUARE (165-4)
1
30 4-720-311-01
ﾌｱﾝ
ｶﾞ
-
ﾄﾞ
(PG-47-02)
GUARD, FAN (PG-47-02)
4
31 7-682-150-01
+P 3X12
SCREW +P 3X12
4
32 7-682-172-01
+P 4X50
SCREW +P 4X50
16
33 7-682-961-01
+PSW 4X8
SCREW +PSW 4X8
28
34 7-682-973-11
+PSW 5X10
SCREW +PSW 5X10
37
35 7-684-023-04
N 3, TYPE 2
N 3, TYPE 2
4
36 1-969-094-13
ﾊ
-
ﾈｽ
(CP9-SV3, 4, 5)
HARNESS
1
37 1-969-085-12
ﾊ
-
ﾈｽ
(SDIO CN2701-IO1)
HARNESS
1
38 1-969-084-12
ﾊ
-
ﾈｽ
(SDIO CN2903-H-IO)
HARNESS
1
39 1-969-084-22
ﾊ
-
ﾈｽ
(SDIO CN2904-H-IO)
HARNESS
1
40 1-969-102-11
ﾊ
-
ﾈｽ
(ATX-TP, POW)
HARNESS
1
41 1-969-779-11
HARNESS (TB5-BOX CN3)
HARNESS (TB5-BOX CN3)
1
42 1-969-780-11
HARNESS (TB5-BOX CN4)
HARNESS (TB5-BOX CN4)
1
43 1-969-083-13
ﾊ
-
ﾈｽ
(TB5-CONV, POW3)
HARNESS
1
44 1-969-098-13
ﾊ
-
ﾈｽ
(CR2, 3-TROLLY, POW)
HARNESS
1
45 1-969-099-12
ﾊ
-
ﾈｽ
(SDIO CN2800-2 ECT-IF)
HARNESS
1
46 1-969-092-12
ﾊ
-
ﾈｽ
(CP3-VAC)
HARNESS
1
47 1-969-065-12
ﾊ
-
ﾈｽ
(ACIN-TB1)
HARNESS
1
48 7-682-947-01
+PSW 3X6
SCREW +PSW 3X6
18
49 7-682-948-01
+PSW 3X8
SCREW +PSW 3X8
16
A-80
A26
電装
BOX-2
Electrical box - 2
34
17
40
33
30
29
15
39
14
12
12
12
30
34
41
38
30
32
5
39
29
12
12
14
15
14
14
30
41
38
4
4
3
21
13
13
16
19
14
43
44
31
39
11
11
11
10
10
10
39
20
7
6
6
6
23
40
35
37
35
37
39
13
13
8
39
9
37
9
37
39
18
16
16
27
16
26
39
28
42
35
37
35
40
39
37
35
37
35
37
39
17
17
39
33
25
24
33
36
36
2
1
39
22
40
44
A-81
A26
電装
BOX-2
Electrical box - 2
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-492-145-11
ｻ
-
ﾎﾞ
ｱﾝﾌﾟ
(MR-J4W2-22B-MK019)
AMPLIFIER, SERVO
1
2 1-492-146-11
ｻ
-
ﾎﾞ
ｱﾝﾌﾟ
(MR-J3W-1010B-MK016)
AMPLIFIER, SERVO
1
3 1-492-147-11
ｻ
-
ﾎﾞ
ｱﾝﾌﾟ
(MR-MD202-S016)
AMPLIFIER, SERVO
1
4 1-492-148-11
ｻ
-
ﾎﾞ
ｱﾝﾌﾟ
(MR-MD212-S016)
AMPLIFIER, SERVO
2
5 1-492-155-11
ｱﾝﾌﾟ
ﾕﾆﾂﾄ
(ZX2-LDA11)
AMPLIFIER UNIT
2
6 1-755-536-11
ｺﾝﾀｸﾀ
(SD-N12 DC24V 1A1B)
CONTACTOR (SD-N12 DC24V 1A1B)
3
7 1-755-537-11
ﾃﾞﾝｼﾞ
ｶｲﾍｲｷ
(MSOD-N11KP)
SWITCH, ELECTROMAGNETIC
(MSOD*)
1
8 1-755-627-11
ﾊﾟﾜ
-
ﾘﾚ
- (G7J-4A-B DC24)
RELAY, POWER (G7J-4A-B DC24)
1
9 1-755-683-11
RELAY, POWER (G7Z-4A DC24)
RELAY, POWER (G7Z-4A DC24)
2
10 1-755-690-11
RELAY, POWER (RJ1S-CLD-D24)
RELAY, POWER (RJ1S-CLD-D24)
3
11 1-755-691-11
SOCKET, RELAY (SJ1S-05B)
SOCKET, RELAY (SJ1S-05B)
3
12 1-854-018-12
ﾀﾝｼ
ﾀﾞｲ
(PT2, 5-QUATTRO BU)
TERMINAL BLOCK
12
13 1-854-021-11
ﾌﾞﾘﾂｼﾞ
ﾊﾞ
- (FBS3-5)
FERRITE-ROD, BRIDGE
4
14 1-854-025-12
ﾀﾝｼﾀﾞｲ
(PT2, 5-QUATTRO)
TERMINAL BLOCK
13
15 1-854-026-12
ﾀﾝｼﾀﾞｲ
(PT2, 5-QUATTRO-PE)
TERMINAL BLOCK
6
16 1-854-027-11
ﾌﾞﾘﾂｼﾞ
ﾊﾞ
- (FBS2-5)
FERRITE-ROD, BRIDGE
4
17 2-580-608-01
SCREW, +PSW M5X16
SCREW, +PSW M5X16
3
18 4-104-008-01
ｺﾃｲ
ｶﾅｸﾞ
(R99-04 FOR G5F)
BRACKET (R99-04 FOR G5F),FIXED
1
19 4-453-715-01
DIN
ﾚ
-
ﾙ
(NS35/7,5PERF100MM/Z)
RAIL (NS35/7,5PERF100MM/Z),DIN
1
20 4-453-718-01
DIN
ﾚ
-
ﾙ
(NS35/7,5PERF300MM/Z)
RAIL (NS35/7,5PERF300MM/Z),DIN
1
21 4-453-728-02
ﾀｼﾞｸ
ｱﾝﾌﾟ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET, AMPLIFIER FITTING
1
22 4-453-738-02
ｻ
-
ﾎﾞ
ﾊﾟﾂｸ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
(Y, X)
BRACKET (Y, X), PACK FITTING
1
23 4-453-739-05
ｾｲｷﾞﾖ
ｷﾊﾞﾝ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET,
PC BOARD FITTING
1
24 4-453-740-01
DIN
ﾚ
-
ﾙ
ｺﾃｲ
ﾌﾞﾗｹﾂﾄ
L
BRACKET (L), DIN RAIL FIXED
1
25 4-453-741-01
DIN
ﾚ
-
ﾙ
ｺﾃｲ
ﾌﾞﾗｹﾂﾄ
R
BRACKET (R), DIN RAIL FIXED
1
26 4-453-742-02
DIN
ﾚ
-
ﾙ
ｳﾗ
ﾌﾞﾗｹﾂﾄ
BRACKET, DIN RAIL (REAR)
1
27 4-453-743-01
DIN
ﾚ
-
ﾙ
ｺﾃｲ
ﾎｷﾖｳ
ﾌﾞﾗｹﾂﾄ
BRACKET, FIXED REINFORCEMENT
1
28 4-453-745-01
ADDA
ｷﾊﾞﾝ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET, ADDA PC BOARD
FITTING
1
29 4-453-765-01
ｼﾕｳﾀﾝﾊﾞﾝ
(D-ST2.5-QUATTRO)
PLATE (D-ST2.5-QUATTRO)
2
