A- 81 A26 電装 BOX -2 Electrical box - 2 ｲﾗｽﾄ 番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 1 1- 492 - 145 - 11 ｻ - ﾎﾞ ｱﾝﾌﾟ ( MR - J 4W 2 - 22B - MK019) AMPLIFIER, SERVO 1 2 1- 492 …
A-80
A26
電装
BOX-2
Electrical box - 2
34
17
40
33
30
29
15
39
14
12
12
12
30
34
41
38
30
32
5
39
29
12
12
14
15
14
14
30
41
38
4
4
3
21
13
13
16
19
14
43
44
31
39
11
11
11
10
10
10
39
20
7
6
6
6
23
40
35
37
35
37
39
13
13
8
39
9
37
9
37
39
18
16
16
27
16
26
39
28
42
35
37
35
40
39
37
35
37
35
37
39
17
17
39
33
25
24
33
36
36
2
1
39
22
40
44
A-81
A26
電装
BOX-2
Electrical box - 2
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-492-145-11
ｻ
-
ﾎﾞ
ｱﾝﾌﾟ
(MR-J4W2-22B-MK019)
AMPLIFIER, SERVO
1
2 1-492-146-11
ｻ
-
ﾎﾞ
ｱﾝﾌﾟ
(MR-J3W-1010B-MK016)
AMPLIFIER, SERVO
1
3 1-492-147-11
ｻ
-
ﾎﾞ
ｱﾝﾌﾟ
(MR-MD202-S016)
AMPLIFIER, SERVO
1
4 1-492-148-11
ｻ
-
ﾎﾞ
ｱﾝﾌﾟ
(MR-MD212-S016)
AMPLIFIER, SERVO
2
5 1-492-155-11
ｱﾝﾌﾟ
ﾕﾆﾂﾄ
(ZX2-LDA11)
AMPLIFIER UNIT
2
6 1-755-536-11
ｺﾝﾀｸﾀ
(SD-N12 DC24V 1A1B)
CONTACTOR (SD-N12 DC24V 1A1B)
3
7 1-755-537-11
ﾃﾞﾝｼﾞ
ｶｲﾍｲｷ
(MSOD-N11KP)
SWITCH, ELECTROMAGNETIC
(MSOD*)
1
8 1-755-627-11
ﾊﾟﾜ
-
ﾘﾚ
- (G7J-4A-B DC24)
RELAY, POWER (G7J-4A-B DC24)
1
9 1-755-683-11
RELAY, POWER (G7Z-4A DC24)
RELAY, POWER (G7Z-4A DC24)
2
10 1-755-690-11
RELAY, POWER (RJ1S-CLD-D24)
RELAY, POWER (RJ1S-CLD-D24)
3
11 1-755-691-11
SOCKET, RELAY (SJ1S-05B)
SOCKET, RELAY (SJ1S-05B)
3
12 1-854-018-12
ﾀﾝｼ
ﾀﾞｲ
(PT2, 5-QUATTRO BU)
TERMINAL BLOCK
12
13 1-854-021-11
ﾌﾞﾘﾂｼﾞ
ﾊﾞ
- (FBS3-5)
FERRITE-ROD, BRIDGE
4
14 1-854-025-12
ﾀﾝｼﾀﾞｲ
(PT2, 5-QUATTRO)
TERMINAL BLOCK
13
15 1-854-026-12
ﾀﾝｼﾀﾞｲ
(PT2, 5-QUATTRO-PE)
TERMINAL BLOCK
6
16 1-854-027-11
ﾌﾞﾘﾂｼﾞ
ﾊﾞ
- (FBS2-5)
FERRITE-ROD, BRIDGE
4
17 2-580-608-01
SCREW, +PSW M5X16
SCREW, +PSW M5X16
3
18 4-104-008-01
ｺﾃｲ
ｶﾅｸﾞ
(R99-04 FOR G5F)
BRACKET (R99-04 FOR G5F),FIXED
1
19 4-453-715-01
DIN
ﾚ
-
ﾙ
(NS35/7,5PERF100MM/Z)
RAIL (NS35/7,5PERF100MM/Z),DIN
1
20 4-453-718-01
DIN
ﾚ
-
ﾙ
(NS35/7,5PERF300MM/Z)
RAIL (NS35/7,5PERF300MM/Z),DIN
1
21 4-453-728-02
ﾀｼﾞｸ
ｱﾝﾌﾟ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET, AMPLIFIER FITTING
1
22 4-453-738-02
ｻ
-
ﾎﾞ
ﾊﾟﾂｸ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
(Y, X)
BRACKET (Y, X), PACK FITTING
1
23 4-453-739-05
ｾｲｷﾞﾖ
ｷﾊﾞﾝ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET,
PC BOARD FITTING
1
24 4-453-740-01
DIN
ﾚ
-
ﾙ
ｺﾃｲ
ﾌﾞﾗｹﾂﾄ
L
BRACKET (L), DIN RAIL FIXED
1
25 4-453-741-01
DIN
ﾚ
-
ﾙ
ｺﾃｲ
ﾌﾞﾗｹﾂﾄ
R
BRACKET (R), DIN RAIL FIXED
1
26 4-453-742-02
DIN
ﾚ
-
ﾙ
ｳﾗ
ﾌﾞﾗｹﾂﾄ
BRACKET, DIN RAIL (REAR)
1
27 4-453-743-01
DIN
ﾚ
-
ﾙ
ｺﾃｲ
ﾎｷﾖｳ
ﾌﾞﾗｹﾂﾄ
BRACKET, FIXED REINFORCEMENT
1
28 4-453-745-01
ADDA
ｷﾊﾞﾝ
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET, ADDA PC BOARD
FITTING
1
29 4-453-765-01
ｼﾕｳﾀﾝﾊﾞﾝ
(D-ST2.5-QUATTRO)
PLATE (D-ST2.5-QUATTRO)
2
A-82
A26
電装
BOX-2
Electrical box - 2
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
30 4-453-766-01
ｼﾕｳﾀﾝ
ﾄﾞﾒ
(CLIPFIX 35-5)
STOPPER (CLIPFIX 35-5)
4
31 4-453-970-01
ﾊｲｾﾝ
ﾀﾞｸﾄ
(AD-262
ｾﾞﾝﾁﾖｳ
1M)
DUCT (AD-262), WIRING
1
32 4-455-723-01
DIN
ﾚ
-
ﾙ
(NS35/7, 5PERF180MM/Z)
RAIL, DIN
1
33 4-459-135-01
ｼﾞﾕｼ
ｶﾗ
- (CLJGJ14-5-6-TC2)
COLLAR
3
34 4-472-389-01
ｽﾍﾟ
-
ｻ
- (4SQ-30)
SPACER (4SQ-30)
5
35 4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
6
36 7-628-000-07
+PSW M5X12
SCREW +PSW M5X12
6
37 7-682-160-01
+P 4X6
SCREW +P 4X6
10
38 7-682-161-01
+P 4X8
SCREW +P 4X8
14
39 7-682-961-01
+PSW 4X8
SCREW +PSW 4X8
26
40 7-682-973-11
+PSW 5X10
SCREW +PSW 5X10
5
41 7-688-004-01
W 4, SMALL
W 4, SMALL
14
42 A-1911-473-A
CAN ADDA COMPL
CAN ADDA COMPL
1
43 A-1916-779-A
SDIO CONT COMPL
SDIO CONT COMPL
1
44 7-682-948-01
+PSW 3X8
SCREW +PSW 3X8
13
