System Requirements Computers Installation Manual SIPLACE Setup Center V3.0 13 4 System Requirement s You can u se SIPLACE Setup Center on a regular PC with the English language version of Windows XP SP2 or Windows Serve…
Navigation Guide for Installation
SIPLACE Setup Center
12 Installation Manual SIPLACE Setup Center V3.0
System Requirements
Computers
Installation Manual SIPLACE Setup Center V3.0
13
4 System Requirements
You can use SIPLACE Setup Center on a regular PC with the English language version of Windows XP
SP2 or Windows Server 2003 and optionally with a multi-language pack. These requirements apply only
to the SIPLACE Setup Center software.
4.1 Computers
Database server
Setup Center GUI Computer
Complete System (for SIPLACE Pro Single Computer Configuration)
NOTE:
SIPLACE Setup Center requires a NTFS partitioning for installation. FAT or FAT32 file systems
are not supported. Installation of SIPLACE Setup Center onto a FAT partitioning will be
interrupted by the setup program.
Software (required) Hardware (recommended)
Preferred: Windows Server 2003 SP2, Windows XP
SP3 or Windows Vista SP1
Compatible: Windows Server 2003 SP1, Windows
Server 2003 R2 or Windows XP SP2
Preferred: Microsoft SQL Server 2005 SP2/Express
Edition SP2
Compatible: Microsoft SQL Server 2000 SP4/ MSDE
SP4
Microsoft .NET Framework 2.0 SP1
Pentium 4 with 3.0 GHz or higher
2x 160 GB hard drive
2048 MB main memory (minimum 1024 MB),
depending on the complexity of the file content.
Optional: data backup drive (e.g. DVD, DAT)
21” screen (minimum 19”)
Optional: SR-USV
Software (required) Hardware (recommended)
Preferred: Windows Server 2003 SP2, Windows XP
SP3 or Windows Vista SP1
Compatible: Windows Server 2003 SP1, Windows
Server 2003 R2 or Windows XP SP2
SIPLACE Pro Interface
SIPLACE Setup Center Station Package
Microsoft .NET Framework 2.0 SP1
Pentium 4 2.4 GHz (minimum Pentium III, 1 GHz)
4 GB hard drive
1 GB main memory, depending on the complexity of
the file content
21” screen (minimum 19”), minimum resolution 1280
x 1024 pixels (small fonts)
Black and white laser printer with 300 dpi (configured
in operating system)
Optional: Zebra Stripe 400 label printer (configured
for the operating system)
Software (required) Hardware (recommended)
Preferred: Windows Server 2003 SP2, Windows XP
SP3 or Windows Vista SP1
Compatible: Windows Server 2003 SP1, Windows
Server 2003 R2 or Windows XP SP2
Preferred: Microsoft SQL Server 2005 SP2/Express
Edition SP2
Compatible: Microsoft SQL Server 2000 SP4/ MSDE
SP4
Microsoft .NET Framework 2.0 SP1
SIPLACE Pro Interface
SIPLACE Setup Center Station Package
Pentium 4 with 3.0 GHz or higher
2x 160 GB hard drive
2048 MB main memory (minimum 1024 MB)
Data backup drive (e.g. DVD, DAT)
21” screen (minimum 19” screen)
Optional: SR-USV
Black and white laser printer with 300 dpi (configured
in operating system)
Optional: Zebra Stripe 400 label printer (configured
for the operating system)
System Requirements
System Requirements
14 Installation Manual SIPLACE Setup Center V3.0
4.2 System Requirements
4.3 Supported Software
Programming system
SIPLACE Setup Center supports the following version in online and offline mode:
Stations software
SIPLACE Setup Center requires in online mode with forced setup verification the SIPLACE Setup Center
Station Package. This is used for installing the appropriate interface with the stations software:
Pre-Setup Unit for X-Tables
The pre-setup unit for X-tables (docking station) requires the following:
NOTE:
A hard disk with 500 MB or more free space should be used for installation.
Hard disk Main memory
Approx. 2500 MB for Windows
Approx. 90 MB for program files
Database = number of recorded packaging units x 1
KB
Approx. 200 MB for Windows
Approx. 150 MB for SQL server with Setup Center
database
Approx. 100 MB for Setup Center GUI
SIPLACE Pro Interface Version SIPLACE Pro Desk Version
3.2 SP1, 4.1 SP1, 5.0 SP1 or 5.2 3.2 SP1, 4.1 SP1, 5.0 SP1 or 5.2
Forced Setup Verification Unforced Setup Verification
SC Station Interface:
407.05, 505.05, 604.01 SP1, 605.01 and 701.02
10x, 40x, 50x, 60x, 70x
NOTE:
SMV Interface is not supported any more for forced setup verification from Setup Centr 3.0.
CAN-Bus PCI card X-FCU X feeder.
Sontheim PCI CAN driver 6.0.0.xy or
higher version (on the product CD)
Firmware 0.5.04.17 or higher
version,
BIOS 02.00
Firmware A.1.01.47 or higher,
BIOS 01.02
NOTE:
The CAN driver for the Docking stations, which are based on current CAN driver, are not
supported by Windows Vista.
