System components and co nfigurations System configuration Recommended Installation Scenarios 22 Installation Manual SIPLACE Setup Center V3.0
System components and configurations
Recommended Installation Scenarios System configuration
Installation Manual SIPLACE Setup Center V3.0
21
5.2.6.2 Central Database
5-1: System configuration Central Database
Usually the system configuration "Central Database" is for manufacturing facility with more than one
production line. Prerequisites for the configuration is
the SIPLACE Pro database is also installed centrally, or
the SIPALCE EDM product is deployed, or
a pre setup area with Setup Center is planned, or
packaging units often moves between different placement lines.
The Setup Center GUIs are connected to the local SIPLACE Pro and to the central Setup Center
Database. The docking stations are connected via CAN-Bus to the SC Computer. The pre setup unit is
the reason, why a central Setup Center Database is necessary.
System components and configurations
System configuration Recommended Installation Scenarios
22 Installation Manual SIPLACE Setup Center V3.0
Installation
Operation System Installation Important Preparations
Installation Manual SIPLACE Setup Center V3.0
23
6 Installation
6.1 Important Preparations
All computers must have been set up and prepared appropriately in advance of the complete installation
of SIPLACE Setup Center to function correctly.
These preparatory measures demand knowledge about the administrative functions of Windows and
SQL Server. Please contact your system administrator for assistance if required.
6.1.1 Operation System Installation
The following steps are essential before conducting the installation of SIPLACE Setup Center:
Installation of operation system Windows
Furthermore, you require Windows administrative rights and write rights for all computers on which
you are installing SIPLACE Setup Center.
See also:
J
4.1 Computers [
J
13]
6.1.2 Database Installation
If the database decision of SIPLACE Setup Center Database is made to use SQL Express or a MSDE
installation, this must be done prior installing SIPLACE Setup Center.
The prerequisite product SQL Express and MSDE are available on the Support Media DVD.
This installer of MSDE creates a MSDE instance with the name SIPLACE_MSDE.
6.2 Hardware Installation
We recommend performing the installation in the specified order:
1. Installation of hardware
2. Installation of software
This chapter describes the hardware installation procedure.
NOTE:
Always exit the running setup verification via task manager/process before the installation or
uninstallation of Setup Center.
NOTE:
If during the installation a note appears, that Microsoft Data Access Components (MDAC) must
be installed. Accept this note.
