1Introduction
Please read chapters 2 through 4 before you install SIPLACE Setup Center. Chapter 5 describes the
installation sequence for SIPLACE Setup Center as well as the related setup types and important
information regarding the installation.
See also:
J
2 Scope of Delivery [
J
9]
J
3 Navigation Guide for Installation [
J
11]
J
5 System components and configurations [
J
17]
J
6 Installation [
J
23]
1.1 Explanation of symbols
Various symbols and notes are used for making this document easier to read.
Words in bold These are dialog boxes and menu commands.
Step … An installation step includes all the actions relating to a specific dialog box. An
installation step may be composed of several actions.
X
Requires an action (e.g. mouse click, open file)
WARNING:
Corresponds to a warning. The information is critical to the success of the installation process.
The installation will be cancelled if you do not comply with the warning.
NOTE:
Explanatory information about the installation sequence.
Introduction
Explanation of symbols
8 Installation Manual SIPLACE Setup Center V3.0
Scope of Delivery
Software package Setup Center Basic Package
Installation Manual SIPLACE Setup Center V3.0
9
2 Scope of Delivery
2.1 Setup Center Basic Package
2.1.1 Software package
The basic software package SIPLACE Setup Center (Item No. 00116918-01) contains the following
components:
1 CD-ROM “SIPLACE Setup Center” with the following contents:
– SIPLACE Setup Center 3.0 Setup
– Activation of Forced Setup Verification and Component Level Indicator at the station
– SIPLACE Setup Selection Assistant Setup (valid for SIPLACE Pro 3.x, 4.1 and 5.0)
– SIPLACE Trace Config Assistant Setup (valid for SIPLACE Pro 3.x, 4.1 and 5.0)
– XML Import Server
– Sontheim PCI CAN driver version
Basic documents:
– "Getting Started with SIPLACE Setup Center 3.0"
(Item No. 00195644-01 [German], 00195645-01[English])
– "Software Version Description SIPLACE Setup Center 3.0"
(Item No. 0095643-01 [English, German])
– "Installation Manual SIPLACE Setup Center 3.0"
(Item No. 00195642-01 [English])
– "User Guide SIPLACE Setup Center 3.0"
(Item No. 00195646-01 [German], 00195647-01[English])
– "Installation Manual SIPLACE Setup Center 3.0 SIPLACE Setup Selection Assistant"
(Item No. 00195649-01 [English])
– "Installation Manual SIPLACE Setup Center 3.0 SIPLACE Trace Config Assistant"
(Item No. 00195650-01 [English])
– "XML-Import SIPLACE Setup Center 3.0”
(Item No. 00195651-01 [English])
– "Installation Manual WLAN Infrastructure"
(Item No. 00195607-01 [German], 00195606-01 [English])
