    3    3    4 2.3 Replacing the cleaning blow valve 5- 5 3. Conveyor belt 5- 6 Appendi x 1. Specifications A- 1 1.1 Air regula…

  7

2.2.1 Cleaning and greasing the ball screw 3-8

2.2.2 Cleaning and greasing the guides 3-11

2.3 Conveyor 3-13

2.3.1 Inspecting and cleaning the conveyor belt 3-13

2.3.2 Cleaning and greasing the hexagon spline 3-14

2.3.3

Inspecting, cleaning and greasing the PU (push-up) shaft (option) 3-15

3. Three-month inspection 3-17

3.1 Head 3-17

3.1.1 Cleaning and replacing the ejector filter 3-17

3.1.2 Checking the ejector vacuum pressure 3-18

3.1.3 Checking the blow valve operation (each head) 3-19

3.1.4 Checking the cleaning blow valve operation (for all heads) 3-19

3.1.5 Cleaning the inside of the spline shaft 3-20

3.1.6 Checking the negative pressure 3-22

3.1.7 Cleaning and greasing the Z and CZ axis ball screws 3-23

  4

3.2.1 Inspecting and cleaning the air/mist filters 3-24

4. Six-month or one-year inspection 3-26

  6

4.1.1 Cleaning the camera lighting units 3-26

  7

4.2.1 Checking the R-axis spline belt 3-27

Chapter 4 Lubrication points

1. Lubrication points and applicable grease 4-1

1.1 Applicable grease 4-1

1.2 Grease gun 4-1

2. Surface mounter 4-2

2.1 Head 4-2

2.1.1 Z, CZ-axis 4-2

2.2 Each axis 4-3

2.2.1 X-axis guide and ball screw 4-3

2.2.2 Y-axis guide and ball screw 4-4

2.2.3 W-axis guide and ball screw 4-5

2.2.4 PU-axis ball guide and ball screw 4-6

Chapter 5 How to replace consumable parts

1. Nozzle leaf springs and roller lock 5-1

1.1 Replacing the nozzle leaf springs 5-1

1.2 Replacing the roller lock 5-2

   3

  3

  4

2.3 Replacing the cleaning blow valve 5-5

3. Conveyor belt 5-6

Appendix

1. Specifications A-1

1.1 Air regulator unit A-1

1.2 Power connection terminals A-2

1.3 Connection between machines A-3

1.3.1 PREVIOUS INTERFACE connector A-3

1.3.2 NEXT INTERFACE connector A-4

2. Warranty A-5

The instruction manual of this machine is written for those who operate

this machine.

Please read this manual carefully for correct operations and pay

special attention to safety precautions.

After reading through this manual, please use this manual as an

occasional reference and keep it within reach.

Introduction

Contents

1. About this manual i

2. Maintenance list ii
