57.MULTI-CODEREADER&BOTTOMVIEWTYPEMULTI-CODEREADER
3 4
3 6
3 3
3 7
3 5
4 0
4 1
2
5
6
8
7
4
3
1
5 4
5 7
4 2
4 3
5 0
4 8
5 4
5 3
5 5
5 4
5 1
5 4
5 4
5 4
5 6
5 8
4 7
4 9
5 2
3 2
3 8
4 4
4 6
4 5
3 9
4 6
3 1
1 5 1 6
2 4
2 6
2 5
2 4
2 3
2 3
2 2
2 2
2 2
2 2
2 2
2 8
2 8
1 7 1 8
9
2 9
3 0
2 1
1 9
2 0
1 9
2 0
1 9
2 1
1 9
1 4
1 3
1 2
1 1
1 0
2 7
2 7
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1
#01
401-22928 2DCODEREADERASMHEAD 1
2 401-40671 BCRD_HEAD_CAMERA_ASM (1)
3 401-40672 BCRD_HEAD_BR_ASM (1)
4 EA-9500B01-00 CABLEBAND (1)
5 401-41016 2DCR_G6G10_H_BRKT (1)
6 401-41017 2DCR_G10_H_HOLDER (1)
7 SL-6030892-TN SCREWM3L=8 (2)
8 SL-6030692-TN SCREWM3L=6 (2)
9 401-40667 BCRD_CONV_CAMERA_ASM 1
10 401-39312 BARCODEREADER (1)
11 401-40930 MCR_BASE (1)
12 400-28300 ROTARYSUPPORTPLATE (1)
13 SL-6030892-TN SCREWM3L=8 (2)
14 SL-6030692-TN SCREWM3L=6 (2)
15
#01
401-40668 BCRD_CONV_BR_ASM_M 1
16
#02
401-40669 BCRD_CONV_BR_ASM_L 1
17
#01
401-11844 SLIDE_RAIL_M (1)
18
#02
401-11851 SLIDE_RAIL_L (1)
19 WP-0430801-SC WASHERM4 (4)
20 400-00912 SENSORADJUSTSPRING (2)
21 SM-6041802-TN SCREWM4X0.7L=18 (2)
22 400-28302 SLIDENUT (9)
23 SL-6041092-TN SCREWM4L=10 (4)
24 SL-6040892-TN SCREWM4L=8 (2)
25 HX-0029400-00 FIXEDBASE (3)
26 SL-4030691-SC SCREWM3L=6 (3)
27 400-28301 ENDCAP (2)
28 401-40929 SLIDE_RAIL_BR (2)
29 G6518-880-000 SETPICK-UP (1)
30 400-58815 SPACER (1)
31
#01
401-47645 BCRD_CONV_COVER_ASM_M 1
32 401-47183 CONVEYORCOVERISM300 (1)
33 E5721-729-000 LABEL (1)
34 400-01490 TAPE (1.5)
35 SM-0040601-SC SCREWM4X0.7L=6 (2)
36 SM-0041001-SC SCREWM4L=10 (2)
37 400-98346 RETAININGWASHERM4 (2)
38 401-47184 CONVEYORSIDECOVERISM300 (1)
39 SM-0040601-SC SCREWM4X0.7L=6 (4)
40 401-47185 CONVEYORUPPERCOVERISM300 (1)
41 SM-0040601-SC SCREWM4X0.7L=6 (2)
42 401-47192 CONVEYOR_COVER_STOPPER_200 (1)
43 SM-0040601-SC SCREWM4X0.7L=6 (2)
44 400-01484 CONVEYORSHUTTERU(L,EN) (1)
45 400-01485 CONVEYORSHUTTERB(L,EN) (1)
46 SM-0040601-SC SCREWM4X0.7L=6 (8)
47
#02
401-47646 BCRD_CONV_COVER_ASM_L 1
48 400-98346 RETAININGWASHERM4 (2)
49
#02
400-01484 CONVEYORSHUTTERU(L,EN) (1)
50
#02
401-47187 CONVEYORSIDECOVERISL300 (1)
51
#02
401-47188 CONVEYORUPPERCOVERISL300 (1)
52
#02
400-01485 CONVEYORSHUTTERB(L,EN) (1)
53 SM-0041001-SC SCREWM4L=10 (2)
54
#02
SM-0040601-SC SCREWM4X0.7L=6 (18)
55
#02
401-47186 CONVEYORCOVERISL300 (1)
56
#02
400-01490 TAPE (1.5)
57 401-47192 CONVEYOR_COVER_STOPPER_200 (1)
58 E5721-729-000 LABEL (1)
- -
