KE-3010A_KE-3020VA_KE-3020VRA-Rev15 - 第74页

- - 34. PWBCONVEY ORCOMPONENTS (7) 4 7 3 5 1 4 2 5 1 2 4 4 8 6 4 6 4 5 2 7 4 4 1 3 1 4 2 4 1 2 1 7 2 1 1 7 1 6 1 5 1 4 1 3 1 2 2 4 2 2 2 0 6 8 8 7 1 9 1 8 1 1 1 0 9 2 6 2 3 2 3 2 5

100%1 / 198
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1
#02
401-47006 RAIL_SUPPORT_L 1
2
#01
401-47005 RAIL_SUPPORT_M 1
3 400-93940 CONVEYORMOTORASML 1
4 400-93941 CONVEYORMOTORCASML (1)
5 400-00870 MOTORPULLEYC (1)
6 SM-8030602-TP SCREWM3X0.5L=6 (3)
7 400-00869 MOTORADJUSTPLATE (1)
8 400-48074 CENTERMOTORASM (1)
9 SL-6041242-TN BOLT (4)
10 400-01009 MOTORBRAKETC(L) (1)
11 SL-6051292-TN SCREWM5L=12 (2)
12 400-93942 CONVEYORMOTORLRASML (2)
13 400-48074 CENTERMOTORASM (2)
14 SM-4054501-SC SCREWM5X0.8L=45 (4)
15 400-00870 MOTORPULLEYC (1)
16 SM-8030602-TP SCREWM3X0.5L=6 (3)
17 400-46034 MOTORBRACKETS(6) (1)
18 WS-0510002-KN SPRINGWASHERM5 (4)
19 SL-6051492-TN BOLT (2)
20 SL-6051092-TN SCREWM5L=10 (8)
21 SL-6041092-TN SCREWM4L=10 2
22 SL-6051092-TN SCREWM5L=10 2
- -
34.PWBCONVEYORCOMPONENTS(7)
4 7
3
5
1
4
2
5
1
2
4
4 8
6
4 6
4 5
2 7 4 4
1 3
1 4
2 4
1 2
1 7
2 1
1 7
1 6
1 5
1 4
1 3
1 2
2 4
2 2
2 0
6
8
8
7
1 9
1 8
1 1
1 0
9
2 6
2 3
2 3
2 5
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 400-00887 GUIDEBLOCKAASM 2
2
#03
SM-6031002-TN SCREWM3L=10 6
3
#03
401-10735 LINEARWAYCP 1
4 400-00877 GUIDEBLOCKCLAMP 2
5 SM-6041602-TN SCREWM4X16 2
6
#03
400-15793 LOCKSPRING 2
7
#03
L1792-721-000 DAMPERBLOCKR 1
8
#03
SL-6030892-TN SCREWM3L=8 4
9
#03
400-00891 STOPERSLIDELEVERL 1
10
#03
400-00897 STOPERSLIDELEVERR 1
11
#03
L179E-621-000 DAMPERBLOCKL 1
12
#03
400-00978 DAMPERLOCKLINK 2
13
#03
400-00950 DAMPERSPRING 2
14
#03
RE-0300000-K0 E-RING3 6
15
#03
EA-9500B00-00 CABLEBAND 1
16
#03
HX-0031400-00 SPIRALTABE 0.3
17
#03
400-01081 CENTERINGPIN4.0 2
18
#03
400-15791 DAMPERPLATEL 1
19
#03
400-15792 DAMPERPLATER 1
20
#03
400-92576 T.PINSENSASM 1
21
#03
SL-6030692-TN SCREWM3L=6 1
22
#03
SL-4031091-SC SCREWM3L=10 2
23
#03
RE-0300000-K0 E-RING3 2
24
#03
400-00896 DAMPERLOCKPIN 2
25
#01
E2148-721-000 SENSORBRACKETR 1
26
#02
E2147-721-000 SENSORBRACKETL 1
27
#03
400-01087 CENTERINGPIN3.4 1
28
#03
400-01088 CENTERINGPIN3.3 1
29
#03
400-01089 CENTERINGPIN3.2 1
30
#03
400-01090 CENTERINGPIN3.1 1
31
#03
400-01091 CENTERINGPIN3.0 1
32
#03
400-01092 CENTERINGPIN2.9 1
33
#03
400-01093 CENTERINGPIN2.8 1
34
#03
400-01094 CENTERINGPIN2.7 1
35
#03
400-01095 CENTERINGPIN2.6 1
36
#03
400-01096 CENTERINGPIN2.5 1
37
#03
400-01097 CENTERINGPIN2.0 1
38
#03
400-01098 CENTERINGPIN1.9 1
39
#03
400-01099 CENTERINGPIN1.8 1
40
#03
400-01082 CENTERINGPIN3.9 1
41
#03
400-01083 CENTERINGPIN3.8 1
42
#03
400-01084 CENTERINGPIN3.7 1
43
#03
400-01085 CENTERINGPIN3.6 1
44
#03
400-01086 CENTERINGPIN3.5 1
45
#03
E2141-725-000 BUHANDKNOBS 1
46
#03
E2076-721-000 BUHANDKNOB 1
47
#03
SM-6030802-TN SCREW 14
48
#03
EA-9500B01-00 CABLEBAND 8
