42.ACCESSORIESPARTCOMPONENTS
1 4
1 7
6
8
3
2
4
5
3 1
2 1
3 3
2 0
1 0
1
2 8
1 5
3 2
3 0
1 1
2 7
2 5
2 4
1 9
1 2
1 3
2 9
9
2 3
2 2
2 6
7
1 8
1 6
- -
REF.NO NOTE PARTNO DESCRIPTION Qty
1 400-72349 HANDKNOBASM 1
2 400-72363 HANDKNOB (1)
3 400-72364 HANDKNOBARM (1)
4 NM-6050001-SC NUTM5X0.8TYPE1 (1)
5 WS-0510002-KN SPRINGWASHERM5 (1)
6 400-34506 BACKUPPINASSEMBLY 12
7 SL-6041092-TN SCREWM4L=10 2
8 400-94361 NSLGREASE 1
9
#01
E5190-729-0A0 CALPIECE 1
10 SL-6030892-TN SCREWM3L=8 7
11 MDF-RX1001L0-9 DEFRIXOILNO1 1
12 J1067-000-000 OILER 1
13 400-32449 6459GREASEN 1
14 SL-3061232-TN SCREWM6L=12 8
15 400-46644 ZMRUBBER 1
16 401-46952 X_FIX_BR 1
17 401-06051 Y_FIX_BR_V2 1
18 E2424-725-000 STOPPERRUBBERR 2
19 J1080-000-000 BOLLSCREWDRIVER 1
20 288-46400 BOLT 4
21 288-46509 WASHER 4
22 400-45985 CHIPBOX 1
23 400-45986 CHIPBOXCUSHION 1
24 PJ-0700000-01 SOCKET 1
25 161-21907 HOSEBAND 1
26 SM-6083002-TN SCREWM8L=30 12
27 NM-6080002-SC NUTM8X1.25TYPE2 12
28 400-46643 CG2GREASE 1
29 EA-9500B02-00 CABLEBAND150 10
30
#01
400-46529 ICZMSTOPPER 1
31 400-46528 ZMSTOPPER 6
32 HF-0110025-S0 SLO-BLOFUSE 3
33 288-46608 SPRINGWASHER 4
- -
OPTION
43.AWCCOMPONENTS
3 7
3 6
3 5
3 4
3 4
3 3
3 2
3 2
3 1
2 9
1 8
2 7
1 7
6
3
1 0
2 8
2 2
1
3 0
2 3
1 6
9
8
5
7
2 0
4
1 9
2 6
2
2 5
1 1
1 2
1 5
1 4
1 3
1 2
1 5
3 8
2 4
2 1
1 1
