9 Maintenance Parts FEB./2003 Exterior , etc 5 1 3 2 4 No . Part No. Part Name Q'ty Remarks Rank 1 KGN-M4570-00X I/O BOARD HEAD ASSY 1 P2 1 B 2 KG7-M530H-01X FLOPPY DISK DRIVE 1 A14(FD-235HG-C304) B 3 KW3-M5150-00(1…
7
Maintenance Parts
FEB./2003
Main Stopper
4
3
2
1
Push-Up Unit
A
A
B
B
1
2
No. Part No. Part Name Q'ty Remarks Rank
1 LC2-M653G-00X SENSOR ASSY 1 B
2 LC2-M9209-00X CYLINDER 1 B
No. Part No. Part Name Q'ty Remarks Rank
1 LC2-M9162-01X CYLINDER 1 B
2 LC2-M9161-00X STOPPER 1 B
3 LC2-M653F-00X SENSOR, 3 ASSY 1 B
4 LC2-M653K-00X SENSOR, SET POSITION 1 B
8
Maintenance Parts
FEB./2003
ANC Station
1
2
Controller
2
1
No. Part No. Part Name Q'ty Remarks Rank
1 LC2-M960A-00X SENSOR ASSY 1 B
2 LC2-M9603-00X CYLINDER 1 BDAS10x5 B
No. Part No. Part Name Q'ty Remarks Rank
1 KGA-M6522-20X SPARE RELAY 1 IF Board A
2 KGN-M4255-00X FLASH DISK 1 B
9
Maintenance Parts
FEB./2003
Exterior, etc
5
1
3
2
4
No. Part No. Part Name Q'ty Remarks Rank
1 KGN-M4570-00X I/O BOARD HEAD ASSY 1 P21 B
2 KG7-M530H-01X FLOPPY DISK DRIVE 1 A14(FD-235HG-C304) B
3 KW3-M5150-00(10)X KEY BOARD J(E) 1 A10(Japanese/English) C
4 KW3-M5169-00X MOUSE 1 A12 C
5 KH4-M668R-00X HARNESS, 6-11(SW COVER) 2 J198, J199 C
