7 Maintenance Parts FEB./2003 Main Stopper 4 3 2 1 Push-Up Unit A A B B 1 2 No . Part No. Part Name Q'ty Remarks Rank 1 LC2-M653G-00X SENSOR ASSY 1 B 2 LC2-M9209-00X CYLINDER 1 B No . Part No. Part Name Q'ty Re…
6
Maintenance Parts
FEB./2003
Main Conveyor-1
4
3
5
1
8
1
2
7
4
4
4
6
No. Part No. Part Name Q'ty Remarks Rank
1 LC2-M911M-00X BELT 2 Conveyor Belt A
2 LC2-M911N-00X BELT(255-3GT-9) 1 A
3 LC2-M911P-00X BELT(B150S3M219) 1 A
4 LC2-M911R-00X BELT(B150S3M789) 2 A
5 90K61-001500 AC SERVO MOTOR 1 W1 B
6 LC2-M9121-40X VALVE 1 Spare B
7 LC2-M9131-00X MOTOR 1 1 Conv. Motor B
8 LC2-M9132-00X GEAR HEAD 1 1 Conv. Motor B
Main Conveyor-2
1
1
No. Part No. Part Name Q'ty Remarks Rank
1 KU0-M655F-20X SENSOR 2 Ent. & Exit Spare B
7
Maintenance Parts
FEB./2003
Main Stopper
4
3
2
1
Push-Up Unit
A
A
B
B
1
2
No. Part No. Part Name Q'ty Remarks Rank
1 LC2-M653G-00X SENSOR ASSY 1 B
2 LC2-M9209-00X CYLINDER 1 B
No. Part No. Part Name Q'ty Remarks Rank
1 LC2-M9162-01X CYLINDER 1 B
2 LC2-M9161-00X STOPPER 1 B
3 LC2-M653F-00X SENSOR, 3 ASSY 1 B
4 LC2-M653K-00X SENSOR, SET POSITION 1 B
8
Maintenance Parts
FEB./2003
ANC Station
1
2
Controller
2
1
No. Part No. Part Name Q'ty Remarks Rank
1 LC2-M960A-00X SENSOR ASSY 1 B
2 LC2-M9603-00X CYLINDER 1 BDAS10x5 B
No. Part No. Part Name Q'ty Remarks Rank
1 KGA-M6522-20X SPARE RELAY 1 IF Board A
2 KGN-M4255-00X FLASH DISK 1 B
