Nachrüstanleitung Kurze Pinole Ausgabe 05/2003 16
Nachrüstanleitung Kurze Pinole
Ausgabe 05/2003
15
2.3.2 Rüstungswechsel / STOP Produktion
2
2
Produktions Ende
hoher Bauteile
Letzte LP
bestückt?
Weitere Bestückung
JA
NEIN
STOP
der Station auf der hohe Bauteile bestückt werden
Manuelles wechseln
der kurzen Pinolen gegen standard Pinolen mit Pipetten
Zuücksetzen
des aktuellen Auftrags am Linienrechner
Vorgabe
des Nachfolgeauftrages
Automatisch
werden jetzt an der Station bzw. der ganzen Linie die
Pipetten gewechselt
Automatisch
werden alle Refernzläufe durch geführt
Produktion
des Nachfolgeproduktes
Manuell an der Station in die Portalfunktion / Pipttenkonfiguration
am RV Kopf wechseln
Nachrüstanleitung Kurze Pinole
Ausgabe 05/2003
16
Retrofit instructions Short Sleeve
05/2004 Edition
17
3 High Components up to 10.7mm on SIPLACE
Revolver Heads
3.1 Overview
Due to the very high demand, to place higher components than 6 or 8.5mm on SIPLACE revolver
heads, a new project within SD EA 1 was started. 3
After the first test, there was clear message that we will have a possibility to place high compon-
ents on the existing revolver heads. The restriction to the existing max. height was give due to the
space under the gantry. That means, that we have enough space inside the heads. The restriction
to 6 or 8.5mm is caused when a high component is already placed on the board and the gantry
has also on the down segment a high component. 3
The goal was to find a solution to get more space under gantry, to expand the space between gan-
try and board top side. Therefore the nozzle was shortened to maximum, that means that the
nozzle was shortened until the seat of the nozzle changer!
As well the segment was shortened by 2mm. With these modification the complete seat is moving
2mm deeper. 3
3.2 Surroundings
3.2.1 Restrictions
Through the testing the following restrictions were found: 3
12 Segment revolverhead: 3
– The maximum component height is 10.7 mm.
– To be able to place this 10.7mm high components, the GF editor has to be manipulated.
– The benchmark performance is about 9% lower.
– The PCB diameter incl. arch is limited to 2,55 mm. Thicker PCBs up to maximum 2,9 mm incl.
arch only on request to SD EA Munich.
– The maximal components size is reduced to 10mm, comparing to 18.7mm
– The segment has to be changed manually by the operator, there is no special message which
tells the operator to change now the segment.
– It is possible to mix standard with short sleeves.
– The 24/32mm feeder has to be lifted by 2mm.
