Inspection of the Contr oller 7-13 7.3.3. Conveyor Control Board Receives the sensor input of the conveyor , ANC and operation panel switch and transm its them to the CAN Master Board. It also receives the command from t…
Samsung Component Placer CP45NEO Series Maintenance Guide
LED information for board status diagnosis
LED ON DESCRIPTION REMARK LED ON DESCRIPTION REMARK
LED1 Can transmission LED17 H2 Blow Sol Output
LED2 Error Occurrence LED18 H3 Blow Sol Output
LED3 Receiving Can LED19 H4 Blow Sol Output
LED4 CPU Operation LED20 H5 Blow Sol Output
LED5 IO RESET LED21 H6 Blow Sol Output
LED6
Board Output
Power LED22 Side U/D Sol Output
LED7
Board Operation
Power LED23 Dummy Out Put Output
LED8 H1 Vac Sol Output LED24
Nozzle Check Sensor
Input Input
LED9 H2 Vac Sol Output LED25
Nozzle Check Sensor
Enable Input
LED10 H3 Vac Sol Output LED26 Bed Mark Sensor Input
LED11 H4 Vac Sol Output LED27 Dummy Input Input
LED12 H5 Vac Sol Output LED28 Height Sensor Enable Input
LED13 H6 Vac Sol Output LED29 Side ILL Up Sensor Input
LED14 Height Sensor Off Output LED30 Side ILL Down Sensor Input
LED15 Nozzle sensor Off Output LED31 Mirror Safety Sensor Input
LED16 H1 Blow Sol Output
7-12
Inspection of the Controller
7-13
7.3.3. Conveyor Control Board
Receives the sensor input of the conveyor, ANC and operation panel switch and transmits
them to the CAN Master Board. It also receives the command from the CAN Master
Board to operate the conveyor and ANC related solenoid valve and signal light.
Required power supply
External power input: +24V DC
Internal power required: +5V DC / +24V DC
Description of major functions
INPUT
PIN NO. DEF. DESCRIPTION REMARK
1 CANH CAN communication signal
2 CANL
Connection with CAN communication signal
of other nodes
3
/IO-
RES
RESET Signal FROM CAN MASTER
CN2/
CN3
6 +12V +12V for A/D FROM CAN MASTER
1 24VP DC+24V for OUTPUT PORT Apply after inputting the READY SW
2 24V DC+24V for INPUT PORT then DC+5V for BOARD is generated
CN4
3/4 24G DC+24V GROUND -
3 IN1.0 PCB INPUT SENSOR
4 IN1.1 PCB WAIT SENSOR
9 IN1.2 WAIT STOPPER UP SENSOR
10 IN1.3 WAIT STOPPER DOWN SENSOR
15 IN1.4 PCB PLACE SENSOR
CN14
16 IN1.5 PLACE STOPPER UP SENSOR
24PIN CONNECTOR
(WAIT STOPPER UP/DOWN SENSOR is
not used for 3rd stage C/V)
Samsung Component Placer CP45NEO Series Maintenance Guide
PIN NO. DEF. DESCRIPTION REMARK
21 IN1.6 PLACE STOPPER DOWN SENSOR
22 IN1.7 SECOND PLACE SENSOR
3 IN2.0 BUT UP SENSOR
4 IN2.1 BUT DOWN SENSOR
9 IN2.2 HOLE FIXER RIGHT SENSOR
10 IN2.3 HOLE FIXER LEFT SENSOR
15 IN2.4 EDGE PUSHER FORWARD SENSOR
16 IN2.5 EDGE PUSHER BACKWARD SENSOR
21 IN2.6 RESERVED INPUT PORT
CN15
22 IN2.7 RESERVED INPUT PORT
24PIN CONNECTOR
3 IN3.0 PCB OUT SENSOR
4 IN3.1 OUT STOPPER UP SENSOR
9 IN3.2 OUT STOPPER DOWN SENSOR
10 IN3.3 ANC1 SHUTTER CLOSE SENSOR
15 IN3.4 ANC1 SHUTTER OPEN SENSOR
16 IN3.5 ANC2 SHUTTER CLOSE SENSOR
21 IN3.6 ANC2 SHUTTER OPEN SENSOR
CN16
22 IN3.7 RESERVED INPUT PORT
24PIN CONNECTOR
(OUT STOPPER UP/DOWN SENSOR is not
used for 3rd stage C/V)
3 IN4.0 FRONT EMERGENCY INPUT
4 IN4.1 FRONT DOOR INPUT
9 IN4.2 FFEEDER CHANGE SW. INPUT
10 IN4.3 READY SW. INPUT
15 IN4.4 START SW. INPUT
16 IN4.5 STOP SW. INPUT
21 IN4.6 RESET SW. INPUT
CN17
22 IN4.7 I/O SW. INPUT
24PIN CONNECTOR
3 IN5.0 REAR EMERGENCY INPUT
4 IN5.1 REAR DOOR INPUT
9 IN5.2 RFEEDER CHANGE SW. INPUT
10 IN5.3 REAR FEEDER Unlock SENSOR
15 IN5.4 RESERVED INPUT PORT
16 IN5.5 MAIN AIR PRESSURE SENSOR
21 IN5.6 RESERVED INPUT PORT
CN18
22 IN5.7 RESERVED INPUT PORT
24PIN CONNECTOR
3 OUT1.0 WAIT STOPPER SOL
OUT1.1 PLACE STOPPER SOL
9 OUT1.2 BUT SOL
10 OUT1.3 HOLE FIXER SOL
15 OUT1.4 EDGE PUSHER SOL
16 OUT1.5 OUT STOPPER SOL
21 OUT1.6 ANC1 SHUTTER SOL
CN5
22 OUT1.7 ANC2 SHUTTER SOL
24PIN CONNECTOR
(WAIT /OUT STOPPER SOL is not used for
3rd stage C/V)
3 OUT2.0 RESERVED OUTPUT PORT
4 OUT2.1 READY SW. LAMP OUT
9 OUT2.2 START SW. LAMP OUT
CN6
10 OUT2.3 STOP SW. LAMP OUT
24PIN CONNECTOR
