Inspection of the Contr oller 7-15 PIN NO. DEF . DESCRIPTION REMARK 15 OUT2.4 BUZZER OUT 16 OUT2.5 FFEEDER CHANGE SW. LAMP OUT 21 OUT2.6 RESET SW. LAMP OUT 22 OUT2.7 RESERVED OUTPUT PORT 1 OUT3.0 RED LAMP OUTPUT 2 OUT3.1…
Samsung Component Placer CP45NEO Series Maintenance Guide
PIN NO. DEF. DESCRIPTION REMARK
21 IN1.6 PLACE STOPPER DOWN SENSOR
22 IN1.7 SECOND PLACE SENSOR
3 IN2.0 BUT UP SENSOR
4 IN2.1 BUT DOWN SENSOR
9 IN2.2 HOLE FIXER RIGHT SENSOR
10 IN2.3 HOLE FIXER LEFT SENSOR
15 IN2.4 EDGE PUSHER FORWARD SENSOR
16 IN2.5 EDGE PUSHER BACKWARD SENSOR
21 IN2.6 RESERVED INPUT PORT
CN15
22 IN2.7 RESERVED INPUT PORT
24PIN CONNECTOR
3 IN3.0 PCB OUT SENSOR
4 IN3.1 OUT STOPPER UP SENSOR
9 IN3.2 OUT STOPPER DOWN SENSOR
10 IN3.3 ANC1 SHUTTER CLOSE SENSOR
15 IN3.4 ANC1 SHUTTER OPEN SENSOR
16 IN3.5 ANC2 SHUTTER CLOSE SENSOR
21 IN3.6 ANC2 SHUTTER OPEN SENSOR
CN16
22 IN3.7 RESERVED INPUT PORT
24PIN CONNECTOR
(OUT STOPPER UP/DOWN SENSOR is not
used for 3rd stage C/V)
3 IN4.0 FRONT EMERGENCY INPUT
4 IN4.1 FRONT DOOR INPUT
9 IN4.2 FFEEDER CHANGE SW. INPUT
10 IN4.3 READY SW. INPUT
15 IN4.4 START SW. INPUT
16 IN4.5 STOP SW. INPUT
21 IN4.6 RESET SW. INPUT
CN17
22 IN4.7 I/O SW. INPUT
24PIN CONNECTOR
3 IN5.0 REAR EMERGENCY INPUT
4 IN5.1 REAR DOOR INPUT
9 IN5.2 RFEEDER CHANGE SW. INPUT
10 IN5.3 REAR FEEDER Unlock SENSOR
15 IN5.4 RESERVED INPUT PORT
16 IN5.5 MAIN AIR PRESSURE SENSOR
21 IN5.6 RESERVED INPUT PORT
CN18
22 IN5.7 RESERVED INPUT PORT
24PIN CONNECTOR
3 OUT1.0 WAIT STOPPER SOL
OUT1.1 PLACE STOPPER SOL
9 OUT1.2 BUT SOL
10 OUT1.3 HOLE FIXER SOL
15 OUT1.4 EDGE PUSHER SOL
16 OUT1.5 OUT STOPPER SOL
21 OUT1.6 ANC1 SHUTTER SOL
CN5
22 OUT1.7 ANC2 SHUTTER SOL
24PIN CONNECTOR
(WAIT /OUT STOPPER SOL is not used for
3rd stage C/V)
3 OUT2.0 RESERVED OUTPUT PORT
4 OUT2.1 READY SW. LAMP OUT
9 OUT2.2 START SW. LAMP OUT
CN6
10 OUT2.3 STOP SW. LAMP OUT
24PIN CONNECTOR
4
7-14
Inspection of the Controller
7-15
PIN NO. DEF. DESCRIPTION REMARK
15 OUT2.4 BUZZER OUT
16 OUT2.5 FFEEDER CHANGE SW. LAMP OUT
21 OUT2.6 RESET SW. LAMP OUT
22 OUT2.7 RESERVED OUTPUT PORT
1 OUT3.0 RED LAMP OUTPUT
2 OUT3.1 BLUE LAMP OUTPUT
3 OUT3.2 GREEN LAMP OUTPUT
CN7
4 OUT3.3 YELLOW LAMP OUTPUT
6PIN CONNECTOR
1/3 OUT3.4 FRONT BELT CONTROL
CN8
2/4 OUT3.5 REAR BELT CONTROL
6PIN CONNECTOR
1/3 OUT3.6 Previous stage machine I/F OUT
CN9
2/4 OUT3.7 Next stage machine I/F OUT
6PIN CONNECTOR
3 IN6.0 FRONT FEEDER Unlock SENSOR
CN19
4 IN6.1 RESERVED INPUT PORT
6PIN CONNECTOR
3 IN6.2 Previous stage machine I/F IN
CN20
4 IN6.3 Next stage machine I/F IN
6PIN CONNECTOR
3 IN7.0 RESERVED INPUT PORT
CN21
4 IN7.1 UPS IN POWER DROP INPUT
6PIN CONNECTOR
3 IN7.2 RESERVED INPUT PORT
CN22
4 IN7.3 RESERVED INPUT PORT
6PIN CONNECTOR
3 IN7.4 RESERVED INPUT PORT
CN23
4 IN7.5 RESERVED INPUT PORT
6PIN CONNECTOR
3 IN7.6 RESERVED INPUT PORT
CN24
4 IN7.7 RESERVED INPUT PORT
6PIN CONNECTOR
CN25 2 AN0 RESERVED ANALOG INPUT PORT 6PIN CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
3 IN6.4 FRONT_KEYPAD_USED
4 IN6.6 FRONT_KEYPAD_EMG
5 +12V +12V for JOGBOX
CN26
6 GND GROUND
FROM FRONT JOGBOX CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
3 IN6.5 REAR_KEYPAD_USED
4 IN6.7 REAR_KEYPAD_EMG
5 +12V +12V for JOGBOX
CN27
6 GND GROUND
FROM REAR JOGBOX CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
CN28
3 GND GROUND
TO MVME162 BOARD
OUTPUT
PIN NO. DEF. DESCRIPTION REMARK
3 OUT4.0 READY RELAY OUTPUT
CN10
4 OUT4.1 RESERVED OUTPUT PORT
6PIN CONNECTOR
CN11
3 OUT4.2 RFEEDER CHANGE SW. LAMP OUT
6PIN CONNECTOR
Samsung Component Placer CP45NEO Series Maintenance Guide
PIN NO. DEF. DESCRIPTION REMARK
4 OUT4.3 RESERVED OUTPUT PORT
3 OUT4.4 RESERVED OUTPUT PORT
CN12
4 OUT4.5 RESERVED OUTPUT PORT
6PIN CONNECTOR
3 OUT4.6 RESERVED OUTPUT PORT
CN13
4 OUT4.7 RESERVED OUTPUT PORT
6PIN CONNECTOR
LED information for board status diagnosis
LED ON DESCRIPTION REMARK LED ON DESCRIPTION REMARK
LED1 Can transmission LED65 ANC1 Shutter Open Sensor Input 2
LED2 Error Occurrence LED66 Stop Sw. Input Input 2
LED3 Receiving Can LED67 ANC 2 Shutter Close Sensor Input 2
LED4 CPU Operation LED68 Reset Sw. Input Input 2
LED5 IO RESET LED69 ANC2 Shutter Open Sensor Input 2
LED6 Board Output Power LED70 I/O Sw. Input Input 2
LED7 Board Operation Power LED71 Dummy Input Input 2
LED40 PCB Input Sensor Input 1 LED72 Front Feeder Unlock Sensor Input 3
LED41 BUT Up Sensor Input 1 LED73 RearEmergency Input/CN-IN5 Input 3
LED42 PCB Wait Sensor Input 1 LED74
Front Feeder Alarm for
replacement Sensor
Input 3
LED43 BUT Down Sensor Input 1 LED75 Rear Door Input Input 3
LED44 Wait Stopper Up Sensor Input 1 LED76 Previous stage machine I/F In Input 3
LED45 Hole Fixer Right Sensor Input 1 LED77 RFeeder Change Sw. Input Input 3
LED46 Wait Stopper Down Sensor Input 1 LED78 Next stage machine I/F In Input 3
LED47 Hole Fixer Left Sensor Input 1 LED79 Rear Feeder Unlock Sensor Input 3
LED48 PCB Place Sensor Input 1 LED80 Front_Key_Pad_Used Input 3
LED49 Edge Pusher Forward Sensor Input 1 LED81
Rear Feeder Alarm for
replacement Sensor
Input 3
LED50 Place Stopper Up Sensor Input 1 LED82 Rear_Key_Pad_Used Input 3
LED51 Edge Pusher Backward Sensor Input 1 LED83
Main Pneumatic pressure
measurement Sensor
Input 3
LED52 Place Stopper Down Sensor Input 1 LED84 Front Key Pad Emg. Input 3
LED53 Back Pusher Sensor Input 1 LED85 Pressure Sensor Enable Input 3
LED54 Dummy Input Input 1 LED86 Rear Key Pad Emg. Input 3
LED55 Back Pusher Sensor Input 1 LED87 Dummy Input Input 3
LED56 Front Emergency Input Input 2 LED88 I/O Power Drop Input Input 4
LED57 PCB Out Sensor Input 2 LED89 USP In Power Drop Input Input 4
LED58 Front Door Input Input 2 LED90 220V Main Power Drop Input Input 4
LED59 Out Stopper Up Sensor Input 2 LED91 110V Main Power Drop Input Input 4
LED60 Feeder Change Sw. Input Input 2 LED92 220V Sub Power Drop Input Input 4
LED61 Out Stopper Down Sensor Input 2 LED93 110V Sub Power Drop Input Input 4
LED62 Ready Sw. Input Input 2 LED94 Drmmy Input Input 4
LED63 ANC1 Shutter Close Sensor Input 2 LED95 Drmmy Input Input 4
LED64 Start Sw. Input Input 2
7-16
