Samsung Component Placer CP45NEO Series Maintenance Guide
7.9. Motor troubleshooting
Upon occurrence of error, alarms are generated by blinking the 7 segment LED of the
motor drive. In this case, take necessary actions based on the following table.
Table 7-1. Motor Troubleshooting
Alarm
Code No.
Alarms Causes Countermeasures
Control voltage is too low. Raise voltage.
Insufficient control voltage
capacity
Increase power source capacity.
11
Control Voltage
Abnormal
Damage of servo amp
circuit
Replace servo amp.
Disconnecting of
regenerative resistor.
Replace the regenerative resistance
if the resistance measured by the
tester is infinite (∞).
External regenerative
resistor inadequate.
Replace with the regenerative
resistor complying with the
specification.
12
Prevention of
Overvoltage
Damage of servo amp
circuit.
Replace servo amp.
Voltage is too low Raise the voltage.
Insufficient power source
capacity
Increase power source capacity.
Loss of one phase in the 3
phase servo amp.
Accurately connect L1, L2 and L3.
13
Main Power
Source Voltage
Abnormal
Damage of servo amp
circuit
Replace servo amp
Damage of servo amp. Replace servo amp.
Phase to phase short
circuit fault of motor cables
Correct the motor cable connection.
1 phase ground fault of
motor cable.
Correct the motor cable connection.
Motor burnt. Replace motor.
Contact fault of motor
cable.
Fix cable connection securely.
Relay for dynamic brake
has melted down.
Replace servo amp.
Motor and servo amp do
not match with each other.
Replace with the servo amp suitable
for motor.
14
Prevention of
Over Current
Pulse input arrives earlier
than servo-on.
Set the pulse input to reach 100ms
after servo-on.
Servo amp temperature is
higher than rating.
Improve the servo amp cooling
condition.
15
Overheat
Prevention
Overload of servo amp.
Decrease load by increasing the
capacities of servo amp and motor.
7-28
Inspection of the Controller
7-29
Alarm
Code No.
Alarms Causes Countermeasures
Long time operation of
motor under overload
condition.
Decrease load by increasing the
capacities of servo amp and motor.
Gain setting error. Set gain again.
Wiring error of motor
cables.
Correct wiring.
There is a hindrance in
the motor operation path.
Remove the hindrance and decrease
load.
Self brake is on. Release self brake terminal.
16
Overload
Prevention
Motor cable connection is
changed between the
motors.
Correct wiring.
PCB fault Replace servo amp
Power source voltage drop
Adjust power source voltage within
the value of specification
Rectifier damaged Replace servo amp
Excessive variation of
Input power voltage
Adjust to within the power source
voltage of the specification.
18
Regeneration
Overload
PCB fault Replace servo amp.
20
Protection of A
phase & B
phase of
Encoder
Missing encoder pulses of
A/B phases
Encoder fault.
21
Encoder
Communicatio
n Error
Communication
interference due to
encoder cable
disconnection.
Check encoder wiring and correct
wiring mistakes.
22
Encoder Wiring
Error
Encoder is not connected
to the servo amp.
23
Encoder
Communicatio
n Error
Damage of encoder
communication data due to
noise
Check if encoder power is
5VDC(4.75~5.25V), and install the
motor cable and encoder cable
separately.
Shield the encoder cable.
24
Position Limit
Exceeding
Error
Motor does not move in
accordance with the
command pulse.
Adjust gain.
Reduce load.
Samsung Component Placer CP45NEO Series Maintenance Guide
Alarm
Code No.
Alarms Causes Countermeasures
Setting value for Pr.63 is
too low.
Increase setting value for Pr.63.
25
Hybrid Limit
Exceeding
Error
Pulse value defined in
Pr.73 and load position
value by external scale is
different.
Check connection between motor
and load.
Raise the setting value for Pr.73.
26
Overspeed
Error
Motor speed is above rated
value.
Check input frequency of command
pulse.
Check connection of encoder cable.
27
Command
Pulse Range
Error
Scale ratio defined in
Pr.46~Pr.4B is abnormal.
Check and adjust the Pr.46~Pr.4B
setting value.
28
External Scale
Error
Input of scale error is “off
“when Pr.77 value is zero,
Check the cause of external scale
error.
29
Error Counter
Overflow
Value of error count
exceeds 2^27
Check torque.
Adjust gain.
35
External Scale
Connection
Error
External scale connection
is not good or damaged.
Check external scale power source.
Check external scale connection.
36
EEPROM
Parameter
Error
Parameter data damaged. Set parameter again.
37
EEPROM
Check Code
Error
Check data damaged. Replace servo amp.
38
Overtravel
Error
CW/CCW Overtravel input
is off.
Check CW/CCW Overtravel input
cable and connector.
40
Absolute Value
System
Shutdown
Error
Encoder power is off.
Connect battery and clear the
absolute value encoder.
41
Absolute Value
Counter
Overflow Error
Counter value of multi-
revolution counter exceeds
rated value.
Setup Pr.0B correctly.
42
Absolute Value
Encoder
Overspeed
Error
Encoder revolution by
battery power exceeds the
rated value.
Check X4 connector.
Check encoder power.(5V DC)
44
Absolute Value
Encoder
Single-
Revolution
Counter Error
Detect single-revolution
counter error.
Replace motor.
