A- 40 A17 P8 ヘッド ASSY -2 P8 Head assy-2 55 401 -56612 RET AINING RING CURICENT TYPE(5103- 46) ｸﾘｾﾝﾄﾄﾒﾜ (5103-46) 8 56 401 -56640 HEXAGON SOCKET SCR EW(M2 .52.5)_FLA T TYPE ﾛｯｶｸｱﾅﾂｷﾄﾒﾈｼ ﾞ (M2.5x2.5) ﾋﾗｻｷ 16 57 EZ3- 278 - …
A-39
A17
P8 ヘッド ASSY-2
P8 Head assy-2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
401-55912
HOLDER(2)_BEARING
ﾍﾞｱﾘﾝｸﾞﾎﾙﾀﾞ(2)
1
2
401-56141
COLLAR(3)_BEARING
ﾍﾞｱﾘﾝｸﾞｶﾗｰ(3)
1
3
401-56142
HOLDER_SHAFT
ｼｬﾌﾄﾎﾙﾀﾞｰ
1
4
401-56400
MAIN SHAFT COVER
ﾒｲﾝｼｬﾌﾄｶﾊﾞｰ
1
5
401-56410
BEARING(7905UCDB)
ﾍﾞｱﾘﾝｸﾞ(7905UCDB)
1
6
401-56458
LOW HEAD CAP SCREW(M3X12)_HEX SOCKET
ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳﾎﾞﾙﾄ(M3x12)
1
7
401-56624
RETAINER(2)_BEARING
ﾍﾞｱﾘﾝｸﾞｵｻｴ(2)
1
8
401-60283
NUT_BEARING
ﾍﾞｱﾘﾝｸﾞﾅｯﾄ
1
9
401-60284
COLLAR_BEARING NUT
ﾍﾞｱﾘﾝｸﾞﾅｯﾄｶﾗｰ
1
10
EZ3-170-255-01
SCREW (M3X3)
ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M3X3)
2
11
EZ4-454-723-01
LOW HEAD SCREW (M3X8)
ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M3X8)
6
12
EZ7-683-405-04
BOLT HEXAGON SOCKET 3X10
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X10
3
13
401-55921
SPACER_RT GEAR
RT ｷﾞｱｰｽﾍﾟｰｻｰ
6
14
401-56134
POST(1)_RT SPRING
RT ｽﾌﾟﾘﾝｸﾞﾎﾟｽﾄ(1)
6
15
401-56135
POST(2)_RT SPRING
RT ｽﾌﾟﾘﾝｸﾞﾎﾟｽﾄ(2)
6
16
401-56163
HOLDER_GEAR RT
RT ｷﾞｱｰﾎﾙﾀﾞｰ
1
17
401-56293
GEAR_RT(1)
ｷﾞｱｰ RT(1)
1
18
401-56294
GEAR_RT(2)
ｷﾞｱｰ RT(2)
1
19
EZ3-681-308-02
BOLT (M2X6) HOLE HEXAGON
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ M2X6
14
20
401-55891
SHAFT_MAIN
ﾒｲﾝｼｬﾌﾄ
1
21
401-55892
PLATE_MASK
ﾏｽｸﾌﾟﾚｰﾄ
1
22
401-55893
HOLDER_BEARING
ﾍﾞｱﾘﾝｸﾞﾎﾙﾀﾞ
1
23
401-55895
RETAINER_BEARING
ﾍﾞｱﾘﾝｸﾞｵｻｴ
1
24
401-55909
RETAINER(1)_SEAL
ｼｰﾙｵｻｴ(1)
1
25
401-55915
COLLAR_INNER SPLINE
ｲﾝﾅｰｽﾌﾟﾗｲﾝｶﾗｰ
8
26
401-55916
COLLAR_BEARING
ﾍﾞｱﾘﾝｸﾞｶﾗｰ
1
27
401-56130
HEAD_P8
P8 ﾍｯﾄ
1
28
401-56137
SHAFT_SECOND
ｾｶﾝﾄﾞｼｬﾌﾄ
1
29
401-56138
GUIDE_SPOOL
ｽﾌﾟｰﾙｶﾞｲﾄﾞ
8
30
401-56181
RETAINER_FILTER
ﾌｨﾙﾀｰｵｻｴ
8
31
401-56412
BEARING(6705HW2RUC0)
ﾍﾞｱﾘﾝｸﾞ(6705HW2RUC0)
1
32
401-56415
BEARING(S679HWZZSMC3)
ﾍﾞｱﾘﾝｸﾞ(S679HWZZSMC3)
16
33
401-56424
MECHANICAL VALVE(MDV23-Z12-0304)
ﾒｶﾊﾞﾙﾌﾞ(MDV23-Z12-0304)
8
34
401-56437
O_RING(P20)
O ｰﾘﾝｸﾞ(P20)
1
35
401-56438
O_RING(P15)
O-ﾘﾝｸﾞ(P15)
1
36
401-56439
O_RING(S28)
O-ﾘﾝｸﾞ(S28)
1
37
401-56444
O RING(SOP22)_CAP
ｷｬｯﾌﾟ O-ﾘﾝｸﾞ(SOP22)
1
38
401-56445
MINI Y PACKING(MYN-9)
ﾐﾆ Y ﾊﾟｯｷﾝ(MYN-9)
1
39
401-56456
SMALL HEAD CAP SCREW(M3X8)_HEX SOCKET
ﾛｯｶｸｱﾅﾂｷｼｮｳｱﾀﾏﾎﾞﾙﾄ(M3X8)
10
40
401-56457
LOW HEAD SCREW(M1.4X3)_PRECISION INST
ﾃｲﾄｳｾｲﾐﾂｺﾈｼﾞ(M1.4x3)
16
41
401-56459
LOW HEAD CAP SCREW(M3X6)_HEX SOCKET
ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳﾎﾞﾙﾄ(M3x6)
8
42
401-56540
COLLAR_INNER
ｲﾝﾅｰｶﾗｰ
1
43
401-56627
LOW_SMALL HEAD CAP SCREW(M3X6)_HEAXGON S
ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳｼｮｳｱﾀﾏﾎﾞﾙﾄ(M3x6)
4
44
401-56639
HEXAGON SOCKET SCREW(M1.6X2)_FLAT TYPE
ﾛｯｶｸｱﾅﾂｷﾄﾒﾈｼﾞ(M1.6x2)ﾋﾗｻｷ
2
45
401-56641
-SET SCREW(M2.3X1.6)_FLAT TYPE
ｽﾘﾜﾘﾂｷﾄﾒﾈｼﾞ(M2.3x16)ﾋﾗｻｷ
16
46
401-56647
PAN HEAD SCREW(M1.4X2)_PRECISION INST
ｾｲﾐﾂｷｷﾖｳﾅﾍﾞｺﾈｼﾞ(M1.4x2)
16
47
EZ7-683-481-04
BOLT HEXAGON SOCKET 2.5X4
6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2.5X4
8
48
EZ7-683-403-04
BOLT HEXAGON SOCKET 3X6
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6
8
49
EZ3-278-109-01
SPRING INNER SPLIN
ｲﾝﾅ- ｽﾌﾟﾗｲﾝ ﾊﾞﾈ
8
50
EZ3-278-945-01
RETAINER (B) NOZZLE SPRING
ﾉｽﾞﾙ ﾊﾞﾈ ｵｻｴ (B)
8
51
EZ3-681-308-02
BOLT (M2X6) HOLE HEXAGON
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ M2X6
2
52
401-55919
SPRINNG(1)_TORSION
ﾄｰｼｮﾝﾊﾞﾈ(1)
8
53
401-56290
GEAR_RN(4)
ｷﾞｱｰ RN(4)
8
54
401-56291
GEAR_RN(5)
ｷﾞｱｰ RN(5)
8
A-40
A17
P8 ヘッド ASSY-2
P8 Head assy-2
55
401-56612
RETAINING RING CURICENT TYPE(5103-46)
ｸﾘｾﾝﾄﾄﾒﾜ(5103-46)
8
56
401-56640
HEXAGON SOCKET SCREW(M2.52.5)_FLAT TYPE
ﾛｯｶｸｱﾅﾂｷﾄﾒﾈｼﾞ(M2.5x2.5)ﾋﾗｻｷ
16
57
EZ3-278-152-01
SHOE SET
ｾﾂﾄ ｼﾕ-
16
58
401-56148
HOLDER_SPLINE NUT
ｽﾌﾟﾗｲﾝﾅｯﾄﾎﾙﾀﾞｰ
1
59
401-56149
NUT_SPLINE
ｽﾌﾟﾗｲﾝﾅｯﾄ
1
60
401-56150
SHAFT_SPLINE
ｽﾌﾟﾗｲﾝｼｬﾌﾄ
1
61
401-56168
STOPPER_SHAFT
ｼｬﾌﾄｽﾄｯﾊﾟｰ
1
62
401-56425
CYLINDER_SPECIAL(SPC1-4-7.5-Z14-007)
ﾄｸｼｭｼﾘﾝﾀﾞ(SPC1-4-6.5-Z14-007)
1
63
401-56637
NUT 2TYPE(M2SUS)_HEXAGON
ﾛｯｶｸﾅｯﾄ 2TYPE(M2SUS)
1
64
401-56744
BARB FITTING(M-3ALU-2)
ﾊﾞｰﾌﾞﾂｷﾞﾃ(M-3ALU-2)
1
65
401-56422
SPLINE_INNER(LT4XUS+88.5LPF)
ｲﾝﾅｰｽﾌﾟﾗｲﾝ(LT4XUS+88.5LPF)
2
66
401-56421
SPLINE_INNER(LT4XUS+88.0LPF)
ｲﾝﾅｰｽﾌﾟﾗｲﾝ(LT4XUS+88.0LPF)
2
67
401-56420
SPLINE_INNER(LT4XUS+87.5LPF)
ｲﾝﾅｰｽﾌﾟﾗｲﾝ(LT4XUS+87.5LPF)
4
68
EZ3-279-059-02
SPRING (O RING -D#) O RING
ﾉｽﾞﾙ O ﾘﾝｸﾞ ﾊﾞﾈ (O ﾘﾝｸﾞ -D*)
8
69
EZ4-719-920-01
BALL ROPE (DIA 2+-0 MICRONE)
ｺｳｷﾕｳ (ﾏﾙ 2+-0 ﾐｸﾛﾝ.JIS B1501*)
16
70
401-56412
BEARING(6705HW2RUC0)
ﾍﾞｱﾘﾝｸﾞ(6705HW2RUC0)
1
71
401-56458
LOW HEAD CAP SCREW(M3X12)_HEX SOCKET
ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳﾎﾞﾙﾄ(M3x12)
6
72
401-56604
SHAFT OUTER ASSY
ｱｳﾀｰｼｬﾌﾄ ASSY
1
73
SM-6044002-TN
SCREW M4X0.7 L=40
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=40
2
74
401-55917
POST_RN SPRING
RN ｽﾌﾟﾘﾝｸﾞﾎﾟｽﾄ
4
75
401-55920
SPACER_RN GEAR
RN ｷﾞｱｰｽﾍﾟｰｻｰ
4
76
401-56287
GEAR_RN(1)
ｷﾞｱｰ RN(1)
1
77
401-56288
GEAR_RN(2)
ｷﾞｱｰ RN(2)
1
78
EZ4-454-723-01
LOW HEAD SCREW (M3X8)
ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M3X8)
4
79
401-55888
COLLAR(2)_BEARING
ﾍﾞｱﾘﾝｸﾞｶﾗｰ(2)
1
80
401-56136
SHAFT_CENTER
ｾﾝﾀｰｼｬﾌﾄ
1
81
401-56413
BEARING(6704-H-ZZS)
ﾍﾞｱﾘﾝｸﾞ(6704-H-ZZS)
1
82
RC-1850001-KP
C-RING 20 (18.5)
C 形止め輪 20 (18.5)
1
83
WP-0280500-SC
WASHER
ﾋﾗｻﾞｶﾞﾈ ｺｶﾞﾀﾏﾙ M2.5
8
84
401-56164
BLOCK_MANIFOLD
ﾏﾆﾎｰﾙﾄﾞﾌﾞﾛｯｸ
1
85
401-56413
BEARING(6704-H-ZZS)
ﾍﾞｱﾘﾝｸﾞ(6704-H-ZZS)
1
86
401-56414
BEARING(6702-H-ZZ)
ﾍﾞｱﾘﾝｸﾞ(6702-H-ZZ)
1
87
401-56442
O RING(SOP15)_CAP
ｷｬｯﾌﾟ O-ﾘﾝｸﾞ(SOP15)
2
88
401-56443
O RING(SOP20)_CAP
ｷｬｯﾌﾟ O-ﾘﾝｸﾞ(SOP20)
1
