A- 100 A 42 CVS ユニット CVS UNIT 8 9 3 2 4 4 5 5 6 6 1 3 1 2 1 0 1 0 1 0 1 1 1 0 1 4 1 6 1 5 2 1 1 5 1 6 1 7 1 8 1 8 1 9 2 0 7 1 2 4 2 5 2 6 2 7 2 8 2 9 3 0 2 2 3 1 3 2 3 3 3 5 3 6 3 7 3 8 3 9 4 0 4 6 5 5 5 4 6 0 5 4 5 5 5 …
A-99
A41
梱包添付品
Accessories
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
401-44555
EF ARRANGE CBL BLACKET ASM
EF ARRANGE CBL BLACKET ASM
1
2
EZ1-846-577-12
CABLE BEFORE AND BEHIDN I/F
前後 I/F ｹｰﾌﾞﾙ
1
3
EZ4-454-592-01
DUST CAP (DL-P-D/C)
ﾀﾞｽﾄ ｷｬｯﾌﾟ (DL-P-D/C)
2
4
EZ4-456-308-01
SHEET (S) FOOT
ｱｼ ﾖｳ ｼ-ﾄ (S)
2
5
EZ4-456-309-01
BRACKET JOINT
ﾚﾝｹﾂ ﾌﾞﾗｹｯﾄ
2
6
EZ4-761-958-01
SHEET (LEG)
ｱｼ ﾖｳ ｼ-ﾄ
4
7
EZ4-761-962-01
CAP BOLT (CP-30-BC-20)
ﾎﾞﾙﾄ ｷﾔﾂﾌﾟ (CP-30-BC-20)
4
8
EZ7-683-473-04
BOLT HEXAGON SOCKET 8X20
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 8X20
8
9
EZ7-688-007-12
W8 MIDDLE
W8 MIDDLE
8
10
EZ1-845-148-11
MEMORY USB
USB ﾒﾓﾘ (USM4GR B)
1
11
401-46085
RX-7 INSTRUCTION MANUAL(ST)
RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(ST)
1
12
401-46086
RX-7 INSTRUCTION MANUAL(EN)
RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(EN)
1
13
401-46087
RX-7 INSTRUCTION MANUAL(CH)
RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(CH)
1
A-100
A42
CVS ユニット
CVS UNIT
8
9
3
2
4
4
5
5
6
6
1 3
1 2
1 0
1 0
1 0
1 1
1 0
1 4
1 6
1 5
2 1
1 5
1 6
1 7
1 8
1 8
1 9
2 0
7
1
2 4
2 5
2 6
2 7
2 8
2 9
3 0
2 2
3 1
3 2
3 3 3 5
3 6
3 7
3 8
3 9
4 0
4 6
5 5
5 4
6 0
5 4
5 5
5 3
6 0
4 9
5 0
4 9
4 9
4 9
5 1
5 2
4 5
4 5
4 4
4 4
4 3
4 3
4 1
4 2
4 8
4 7
6 9
6 8
6 7
5 8
5 7
5 7
5 6
5 9
6 2
6 3
6 4
6 5
6 6
6 1
7 0
2 3
3 9
A
A
2 1
A-101
A42
ＣＶＳユニット
CVS UNIT
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
401-54477
CVS PROBE UNIT(R)
CVS PROBE UNIT(R)
1
2
401-53441
CVS_BR_A
CVS_ﾌﾞﾗｹｯﾄ A
(1)
3
400-94686
INSULATION_SHEET
ｲﾝｼｭﾚｰｼｮﾝｼｰﾄ
(1)
4
400-94688
CVS_WASHER
CVS_ﾜｯｼｬｰ
(4)
5
401-42109
BUSH
BUSH
(4)
6
401-03174
SPRING_0.34N
SPRING_0.34N
(2)
7
EZ7-300-011-84
BUSHING UNIVERSAL(GEE62F-A-C)
ｼﾞｻﾞｲ ﾌﾞﾂｼﾕ (GEE62F-A-C)30.48M
(0.04)
8
401-03176
CONTACT_BASE_A
CONTACT_BASE_A
(1)
9
401-03177
CONTACT_BASE_B
CONTACT_BASE_B
(1)
10
401-03178
CONTACT_SH
CONTACT_SH
(4)
11
SL-4030681-SC
SCREW M3 L=6
座金付きなべ小ねじ M3 L=6
(2)
12
401-03180
CVS CONTACT CABLE(+) ASM
CVS ｺﾝﾀｸﾄｹｰﾌﾞﾙ(+)ｸﾐ
(1)
13
401-05380
CVS CONTACT CABLE(-) ASM
CVS ｺﾝﾀｸﾄｹｰﾌﾞﾙ(-)ｸﾐ
(1)
14
SL-4031281-SC
SCREW M3 L=12
座金付きなべ小ねじ M3 L=12
(2)
15
WS-0310002-KN
SPRING WASHER M3
ﾊﾞﾈｻﾞｶﾞﾈ M3
(2)
16
NM-6030001-SC
NUT M3X0.5 TYPE1
六角ﾅｯﾄ M3X0.5 1 種
(2)
17
401-53442
CVS_BR_B_R
CVS_ﾌﾞﾗｹｯﾄ B_R
(1)
18
SL-6030592-TN
SCREW M3 L=5
座金付き六角穴ボルト M3 L=5
(3)
19
SL-6030592-TN
SCREW M3 L=5
座金付き六角穴ボルト M3 L=5
(1)
20
SL-6041092-TN
SCREW M4 L=10
座金付き六角穴ボルト M4 L=10
(2)
21
401-54486
CVS PROBE CABLE ASM
CVS PROBE CABLE ASM
1
22
401-54473
CVS_PWB_UNIT_R
CVS_基板ﾕﾆｯﾄ R
1
23
401-53444
CVS_PWB_BR_R
CVS_基板ﾌﾞﾗｹｯﾄ_R
(1)
24
400-95117
CVS PCB ASM
CVS 基板組
(1)
25
HX-0035400-00
SPACER
スペーサ
(6)
26
401-53446
CVS_PWB_COVER
CVS_基板ｶﾊﾞｰ
(1)
27
SL-6030592-TN
SCREW M3 L=5
座金付き六角穴ボルト M3 L=5
(6)
28
401-53448
GUIDE_ROLLER_DR-30-H6W1
ｶﾞｲﾄﾞﾛｰﾗ_DR-30H61W
(2)
29
SL-6063092-TN
SCREW M6 L=30
座金付き六角穴ボルト M6 L=30
(2)
30
WP-0641600-SC
WASHEW 6.4X12.5X1.6
ﾋﾗｻﾞｶﾞﾈ
(4)
31
401-53447
CVS_CABLE_BR
CVS_ｹｰﾌﾞﾙﾌﾞﾗｹｯﾄ
1
32
EZ4-457-931-11
TAPE(40) FIXED
ｺﾃｲ ﾃ-ﾌﾟ(40)
2
33
EZ4-716-434-11
TIE INSULOCK(AB100 BLACK)
ｲﾝｼﾕﾛﾂｸ ﾀｲ(AB100 ｸﾛ)
8
34
EZ4-716-434-21
TIE INSULOCK (AB150 BLACK)
ｲﾝｼﾕﾛﾂｸ ﾀｲ (AB150 ｸﾛ)
6
35
EZ4-716-434-31
TIE INSULOCK (AB200 BLACK)
ｲﾝｼﾕﾛﾂｸ ﾀｲ (AB200 ｸﾛ)
12
36
EZ7-300-011-85
BUSHING UNIVERSAL(GEE99F-A-C)
ｼﾞｻﾞｲ ﾌﾞﾂｼﾕ (GEE99F-A-C)30.48M
0.61
37
EZ7-300-011-84
BUSHING UNIVERSAL(GEE62F-A-C)
ｼﾞｻﾞｲ ﾌﾞﾂｼﾕ (GEE62F-A-C)30.48M
0.08
38
HX-0070600-0A
MOUNT BASE
ﾏｳﾝﾄﾍﾞｰｽ
4
39
SL-6051092-TN
SCREW M5 L=10
座金付き六角穴ボルト M5 L=10
4
40
401-54478
CVS PROBE UNIT(L)
CVS PROBE UNIT(L)
1
41
401-53441
CVS_BR_A
CVS_ﾌﾞﾗｹｯﾄ A
(1)
42
400-94686
INSULATION_SHEET
ｲﾝｼｭﾚｰｼｮﾝｼｰﾄ
(1)
43
400-94688
CVS_WASHER
CVS_ﾜｯｼｬｰ
(4)
44
401-42109
BUSH
BUSH
(4)
45
401-03174
SPRING_0.34N
SPRING_0.34N
(2)
46
EZ7-300-011-84
BUSHING UNIVERSAL(GEE62F-A-C)
ｼﾞｻﾞｲ ﾌﾞﾂｼﾕ (GEE62F-A-C)30.48M
(0.04)
47
401-03176
CONTACT_BASE_A
CONTACT_BASE_A
(1)
48
401-03177
CONTACT_BASE_B
CONTACT_BASE_B
(1)
49
401-03178
CONTACT_SH
CONTACT_SH
(4)
50
SL-4030681-SC
SCREW M3 L=6
座金付きなべ小ねじ M3 L=6
(2)
51
401-03180
CVS CONTACT CABLE(+) ASM
CVS ｺﾝﾀｸﾄｹｰﾌﾞﾙ(+)ｸﾐ
(1)
52
401-05380
CVS CONTACT CABLE(-) ASM
CVS ｺﾝﾀｸﾄｹｰﾌﾞﾙ(-)ｸﾐ
(1)
53
SL-4031281-SC
SCREW M3 L=12
座金付きなべ小ねじ M3 L=12
(2)
54
WS-0310002-KN
SPRING WASHER M3
ﾊﾞﾈｻﾞｶﾞﾈ M3
(2)
