A- 103 A 43 基板ストッパー ＡＳＳＹ PWB stopper a ssy 3 4 5 6 8 8 9 1 1 1 1 1 0 1 0 1 2 1 3 1 4 1 5 1 6 1 7 1 8 1 8 1 9 2 0 2 1 2 1 2 2 2 3 2 3 2 3 2 5 2 4 2 6 2 7 2 8 2 9 2 9 3 0 3 1 3 1 3 2 3 3 3 3 3 4 3 5 3 6 3 7 3 8 7 3 9 4 0 2…
A-103
A43
基板ストッパー ＡＳＳＹ
PWB stopper assy
3
4
5
6
8
8
9
1 1
1 1
1 0
1 0
1 2
1 3
1 4
1 5
1 6
1 7
1 8
1 8
1 9
2 0
2 1
2 1
2 2
2 3
2 3
2 3
2 5
2 4
2 6
2 7
2 8
2 9
2 9
3 0
3 1
3 1
3 2
3 3
3 3
3 4
3 5
3 6
3 7
3 8
7
3 9
4 0
2
4 2
4 3
4 8
5 2
4 4
4 5
4 6
6 0
5 0
5 1
5 1
5 0
4 8
4 9
5 3
5 4
5 5
5 6
6 5
6 4
6 8
5 8
5 8
5 7
6 9
6 9
7 0
5 9
7 5
7 4
6 1
6 1
6 2
4 7
6 3
6 3
6 3
6 6
6 7
7 1
7 1
7 2
7 3
7 3
7 6
7 7
7 8
7 9
8 0
1
C ON V E Y A N C E D I R E C T I ON R I GH T - L E F T
-
C ON V E Y A N C E D I R E C T I ON L E F T - R I GH T
-
4 1
A-104
A43
基板ストッパー ASSY
PWB stopper assy
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
401-61170
ST_ASSY
ｽﾄｯﾊﾟｰ ASSY
4
2
401-61110
STTOPER_BLACET(RLC)
ｽﾄｯﾊﾟｰ ﾌﾞﾗｹｯﾄ(RLC)
(1)
3
401-61111
STTOPER_FIX BLOCK(RLC)
ｽﾄｯﾊﾟｰ ｺﾃｲ ﾌﾞﾛｯｸ(RLC)
(1)
4
401-61112
STTOPER_BLOCK
ｽﾄｯﾊﾟｰﾌﾞﾛｯｸ
(1)
5
401-61117
STTOPER_ JYOINT
ｽﾄｯﾊﾟｰ ｼﾞﾖｲﾝﾄ
(1)
6
401-61118
STTOPER_LEVER
ｽﾄｯﾊﾟｰ ﾚﾊﾞ-
(1)
7
401-61119
STTOPER_LEVER_TOP
ｽﾄｯﾊﾟｰﾚﾊﾞ-ﾄｯﾌﾟ
(1)
8
401-61120
PIN_STOPPER HINGE
ｽﾄｯﾊﾟｰ ﾋﾝｼﾞ ﾋﾟﾝ
(2)
9
401-61121
PLATE_STOPPER
ｽﾄｯﾊﾟ ﾌﾟﾚｰﾄ
(1)
10
401-61122
LINK_SPACER
ﾘﾝｸｽﾍﾟｰｻｰ
(2)
11
401-61123
LINK_COLLAR
ﾘﾝｸｶﾗｰ
(2)
12
401-61124
STTOPER_BLOCK_SPACER
ｽﾄｯﾊﾟｰﾌﾞﾛｯｸｽﾍﾟｰｻｰ
(1)
13
401-61125
BLACET_ST_HARNESS_A(RLC)
ｽﾄｯﾊﾟｰ ﾌﾞﾗｹｯﾄ A(RLC)
(1)
14
EZ4-454-328-01
STOPPER CLAMP
ｸﾗﾝﾌﾟ ｽﾄｯﾊﾟ
(1)
15
401-61130
LM_GUIDE(LWL9C1R160BH/MN)
LM ｶﾞｲﾄﾞ (LWL9C1R160BH/MN)
(1)
16
401-61131
STOPPER_BOLT(SSC-M4-20)
ｽﾄｯﾊﾟﾎﾞﾙﾄ (SSC-M4-20)
(1)
17
401-61132
CYLINDER(CDUJB8-15D)
ｼﾘﾝﾀﾞ (CDUJB8-15D)
(1)
18
401-61133
ELBOW_UNION(M-3ALU-2)
ｴﾙﾎﾞﾕﾆｵﾝ (M-3ALU-2)
(2)
19
EZ4-454-519-01
SOLENOID (SBP5) BALL
ﾎﾞ-ﾙ ﾌﾟﾗﾝｼﾞﾔ (SBP5)
(3)
20
RE-0200000-K0
E-RING 2
E 形止め輪 2
(1)
21
401-61135
STOPPER_BOLT(SUB-M4-20)
ｳﾚﾀﾝﾂｷｽﾄｯﾊﾟﾎﾞﾙﾄ(SUB-M4-20)
(1)
22
SM-1040852-TP
DISH SCREW
ｻﾗﾈｼﾞ M4 L=8
(2)
23
SM-6030802-TN
SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
(11)
24
WP-0320500-SF
WASHER 3.2X7X0.5
ﾋﾗｻﾞｶﾞﾈ ｺｶﾞﾀﾏﾙ M3
(2)
25
WS-0310702-KS
SPRING WASHER
ﾊﾞﾈｻﾞｶﾞﾈ 3.1X5.9X0.7
(2)
26
SM-1030552-TN
PLATE SCREW M3 L=5
ｻﾗﾈｼﾞ M3 L=5
(2)
27
401-61176
CAP BOLT(M3X38 SUS)
ﾎﾞﾙﾄ (M3X38)
(2)
28
401-61482
SENSOR ASSY(ST)
ｾﾝｻｰ ASSY(ST)
(1)
29
BT-0200121-EB
URETHANE TUBE BLACK 2X1.2
ﾎﾟﾘｳﾚﾀﾝ ﾁｭｰﾌﾞ 黒 2X1.2
(1.4)
30
EZ2-595-270-01
HOLDER WIRE
ﾎﾙﾀﾞｰﾜｲﾔｰ
(1)
31
EZ4-701-529-01
TIE MOUNT (MB1)
ﾀｲﾏｳﾝﾄ (MB1)
(2)
32
SM-1040601-SC
SCREW M4X0.7 L=6
ｻﾗｺﾈｼﾞ M4X0.7 L=6
(2)
33
SM-1030601-SA
SCREW M3 L=6
ｻﾗｺﾈｼﾞ M3 L=6
(2)
34
EZ4-716-434-11
TIE INSULOCK(AB100 BLACK)
ｲﾝｼﾕﾛｯｸ ﾀｲ(AB100 ｸﾛ)
(9)
35
HX-0040900-0D
TUBE
ｽﾐﾁｭｰﾌﾞ
(0.04)
36
SM-6030602-TN
SCREW M3X6
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3X6
(4)
37
SM-6030402-TN
SCREW M3X4
ﾛｯｶｸｱﾅﾂｷ ﾎﾞﾙﾄ M3X4
(2)
38
401-66475
STOPPER TOP
ｽﾄｯﾊﾟｰﾄｯﾌﾟ
(1)
39
SM-1030501-SC
SCREW M3 L=5
ｻﾗｺﾈｼﾞ M3 L=5
(3)
40
401-61126
BLACET_ST_HARNESS_B(RLC)
ｽﾄｯﾊﾟ- ﾌﾞﾗｹｯﾄ B(RLC)
(1)
41
401-61170
ST_ASSY
ｽﾄｯﾊﾟｰ ASSY
4
42
401-61110
STTOPER_BLACET(RLC)
ｽﾄｯﾊﾟｰ ﾌﾞﾗｹｯﾄ(RLC)
(1)
43
401-61111
STTOPER_FIX BLOCK(RLC)
ｽﾄｯﾊﾟｰ ｺﾃｲ ﾌﾞﾛｯｸ(RLC)
(1)
44
401-61112
STTOPER_BLOCK
ｽﾄｯﾊﾟｰﾌﾞﾛｯｸ
(1)
45
401-61117
STTOPER_ JYOINT
ｽﾄｯﾊﾟｰ ｼﾞﾖｲﾝﾄ
(1)
46
401-61118
STTOPER_LEVER
ｽﾄｯﾊﾟｰ ﾚﾊﾞ-
(1)
47
401-61119
STTOPER_LEVER_TOP
ｽﾄｯﾊﾟｰﾚﾊﾞ-ﾄｯﾌﾟ
(1)
48
401-61120
PIN_STOPPER HINGE
ｽﾄｯﾊﾟｰ ﾋﾝｼﾞ ﾋﾟﾝ
(2)
49
401-61121
PLATE_STOPPER
ｽﾄｯﾊﾟ ﾌﾟﾚｰﾄ
(1)
50
401-61122
LINK_SPACER
ﾘﾝｸｽﾍﾟｰｻｰ
(2)
51
401-61123
LINK_COLLAR
ﾘﾝｸｶﾗｰ
(2)
52
401-61124
STTOPER_BLOCK_SPACER
ｽﾄｯﾊﾟｰﾌﾞﾛｯｸｽﾍﾟｰｻｰ
(1)
53
401-61125
BLACET_ST_HARNESS_A(RLC)
ｽﾄｯﾊﾟｰ ﾌﾞﾗｹｯﾄ A(RLC)
(1)
54
EZ4-454-328-01
STOPPER CLAMP
ｸﾗﾝﾌﾟ ｽﾄｯﾊﾟ
(1)
