B-3 B2 電装 BOX 配線 -1 Electrical box w iring diagram - 1
B-2
B1
主電源・タッチパネル配線図
Main power supply wiring diagram
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
400-48032
PANEL LINK CABLE 4.5M
ﾊﾟﾈﾙﾘﾝｸｹｰﾌﾞﾙ 4.5M
1
2
EZ1-970-005-11
HARNESS (PC232CX-TP232CX)
ﾊ-ﾈｽ (PC232CX-TP232CX)
1
3
EZ1-970-004-12
HARNESS (LCDPW1T-LCDPW2T)
ﾊ-ﾈｽ (LCDPW1T-LCDPW2T)
1
4
EZ1-969-357-12
HARNESS (MAIN POWER1)
ﾊ-ﾈｽ (MAIN POWER1)
1
200V
EZ1-969-361-11
HARNESS (MAINPOWER UL/CE TB-NF)
ﾊ-ﾈｽ (MAIN POWER UL/CE TB-NF)
1
208-430V
5
EZ1-492-743-11
ABSORBER ASSY SURGE
ABSORBER ASSY SURGE
1
6
EZ1-969-358-13
HARNESS (MAIN POWER2)
ﾊ-ﾈｽ (MAIN POWER2)
1
200V
EZ1-969-364-11
HARNESS (MAIN POWER UL/CE T-MB)
ﾊ-ﾈｽ (MAIN POWER UL/CE T-MB)
1
208-430V
7
EZ1-969-359-13
HARNESS (MAIN POWER3)
ﾊ-ﾈｽ (MAIN POWER3)
1
8
EZ1-969-363-11
HARNESS (MAIN POWER UL/CE CB-T)
ﾊ-ﾈｽ (MAIN POWER UL/CE CB-T)
1
208-430V ONLY
9
EZ1-969-362-12
HARNESS (MAIN POWER UL/CE NF-CB
ﾊ-ﾈｽ (MAIN POWER UL/CE NF-CB)
1
208-430V ONLY
10
EZ1-523-276-11
BREAKER NO FUSE 15A
ﾉ-ﾌﾕ-ｽﾞ遮断機(NF100-SRU 15A)(380V-430V)
1
380-430V
EZ1-523-276-21
BREAKER NO FUSE 20A
ﾉ-ﾌﾕ-ｽﾞ遮断機(NF100-SRU 20A)(208V-240V)
1
208-240V
B-3
B2
電装 BOX 配線-1
Electrical box wiring diagram - 1
B-4
B2
電装 BOX 配線-1
Electrical box wiring diagram - 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
EZ1-969-065-12
HARNESS (ACIN-TB1)
ﾊ-ﾈｽ (ACIN-TB1)
1
2
EZ1-969-066-12
HARNESS (TB1-MC1)
ﾊ-ﾈｽ (TB1-MC1)
1
3
EZ1-969-067-13
HARNESS (TB1-PS1)
ﾊ-ﾈｽ (TB1-PS1)
1
4
EZ1-969-068-13
HARNESS (TB1-CP1)
ﾊ-ﾈｽ (TB1-CP1)
1
5
EZ1-969-069-12
HARNESS (CP1-ATX)
ﾊ-ﾈｽ (CP1-ATX)
1
6
EZ1-969-070-13
HARNESS (TB1-CP2)
ﾊ-ﾈｽ (TB1-CP2)
1
7
EZ1-969-071-13
HARNESS (CP2-TB3)
ﾊ-ﾈｽ (CP2-TB3)
1
8
EZ1-969-072-12
HARNESS (TB3-FAN1)
ﾊ-ﾈｽ (TB3-FAN1)
1
9
EZ1-969-072-22
HARNESS (TB3-FAN2)
ﾊ-ﾈｽ (TB3-FAN2)
1
10
EZ1-969-072-32
HARNESS (TB3-FAN3)
ﾊ-ﾈｽ (TB3-FAN3)
1
11
EZ1-969-072-42
HARNESS (TB3-FAN4)
ﾊ-ﾈｽ (TB3-FAN4)
1
12
EZ1-969-073-12
HARNESS (MC1-MC2, TB2)
ﾊ-ﾈｽ (MC1-MC2, TB2)
1
13
EZ1-969-074-11
HARNESS (MC2-MC3)
ﾊ-ﾈｽ (MC2-MC3)
1
14
EZ1-969-691-13
HARNESS (MC3-PS2 CP5)
ﾊ-ﾈｽ (MC3-PS2，CP5)
1
15
EZ1-969-063-12
HARNESS (TB2-PS4)
ﾊ-ﾈｽ (TB2-PS4)
1
16
EZ1-969-689-11
HARNESS (TB2-PS3)
ﾊ-ﾈｽ (TB2-PS3)
1
17
EZ1-969-064-13
HARNESS (TB2-CP4)
ﾊ-ﾈｽ (TB2-CP4)
1
18
EZ1-969-077-12
HARNESS (TB2-SV1)
ﾊ-ﾈｽ (TB2-SV1)
1
19
EZ1-969-077-22
HARNESS (TB2-SV2)
ﾊ-ﾈｽ (TB2-SV2)
1
20
EZ1-969-078-13
HARNESS (CP5-SV1 SV2)
ﾊ-ﾈｽ (CP5-SV1 SV2)
1
21
EZ1-969-079-13
HARNESS (CP4-SV1 SV2)
ﾊ-ﾈｽ (CP4-SV1 SV2)
1
22
EZ1-969-080-13
HARNESS (TB2-MR1)
ﾊ-ﾈｽ (TB2-MR1)
1
23
EZ1-969-081-13
HARNESS (MR1-CP3)
ﾊ-ﾈｽ (MR1-CP3)
1
24
EZ1-969-092-12
HARNESS (CP3-VAC)
ﾊ-ﾈｽ (CP3-VAC)
1
25
EZ1-969-690-11
HARNESS (PS2-CP9)
ﾊ-ﾈｽ (PS2-CP9)
1
26
EZ1-969-094-13
HARNESS (CP9-SV3, 4, 5)
ﾊ-ﾈｽ (CP9-SV3, 4, 5)
1
27
EZ1-969-777-11
HARNESS (PS3, 4-CP6, CR3)
ﾊ-ﾈｽ (PS3, 4-CP6, CR3)
1
28
EZ1-969-778-11
HARNESS (PS4-CP6,7,8,CR2,TB5)
ﾊ-ﾈｽ (PS4-CP6,7,8,CR2,TB5)
1
29
EZ1-969-711-11
HARNESS (CP7, 8-TB5, 6)
ﾊ-ﾈｽ (CP7, 8-TB5, 6)
1
30
EZ1-969-798-11
HARNESS (CR2 2-4)
ﾊ-ﾈｽ (CR2 2-4)
1
31
EZ1-969-798-21
HARNESS (CR3 2-4)
ﾊ-ﾈｽ (CR3 2-4)
1
32
EZ1-969-520-11
HARNESS (TB3-EX FAN(F))
ﾊ-ﾈｽ (TB3-EX FAN(F))
1
33
EZ1-969-521-12
HARNESS (BOX FAN (F)-FAN)
ﾊ-ﾈｽ (BOX FAN (F)-FAN)
1
34
EZ1-969-387-12
HARNESS (TB3-EX FAN1)
ﾊ-ﾈｽ (TB3-EX FAN1)
1
35
EZ1-969-387-22
HARNESS (TB3-EX FAN2)
ﾊ-ﾈｽ (TB3-EX FAN2)
1
36
EZ1-969-994-11
HARNESS (TB3-EX FAN (CF))
ﾊ-ﾈｽ (TB3-EX FAN (CF))
1
37
EZ1-969-994-21
HARNESS (TB3-EX FAN (CR))
ﾊ-ﾈｽ (TB3-EX FAN (CR))
1
38
EZ1-969-989-11
HARNESS (BOX FAN (CF)-FAN)
ﾊ-ﾈｽ (BOX FAN (CF)-FAN)
1
39
EZ1-969-989-21
HARNESS (BOX FAN (CR)-FAN)
ﾊ-ﾈｽ (BOX FAN (CR)-FAN)
1
