A-11
A5
架台 ASSY-2
Base frame assy - 2
A-12
A5
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
EZ4-138-825-02
PLUG (M10X1.5), SCREW
ｽｸﾘﾕ- ﾌﾟﾗｸﾞ (M10X1.5)
4
2
EZ4-294-534-01
CONTROLLER (AS2002F-06) SPEED
ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ (AS2002F-06)
4
3
EZ4-447-063-21
UNION (KQ2L06-01AS), ELBOW
ｴﾙﾎﾞ ﾕﾆｵﾝ (KQ2L06-01AS)
4
4
EZ4-454-729-01
CYLINDER(CXSM32-100), DUAL ROD
ﾃﾞﾕｱﾙ ﾛﾂﾄﾞ ｼﾘﾝﾀﾞ (CXSM32-100)
4
5
EZ4-454-743-01
CONTROLLER (AS2201F-01-06SA)
ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ (AS2201F-01-06SA
4
6
EZ4-454-745-02
LM GUIDE (SHS15V1UU)
LM ｶﾞｲﾄﾞ (SHS15V1UU)
8
7
EZ4-454-941-01
RAIL GUIDE 1 (L)
ﾚ-ﾙ ｶﾞｲﾄﾞ 1 (L)
2
8
EZ4-454-941-11
RAIL GUIDE 1 (R)
ﾚ-ﾙ ｶﾞｲﾄﾞ 1 (R)
2
9
EZ4-454-942-02
RAIL GUIDE 2
ﾚ-ﾙ ｶﾞｲﾄﾞ 2
4
10
EZ4-454-942-12
RAIL GUIDE 2
ﾚ-ﾙ ｶﾞｲﾄﾞ 2
4
11
EZ4-454-943-01
BLOCK, TABLE POSITIONING
ﾃ-ﾌﾞﾙ ｲﾁｷﾞﾒ ﾌﾞﾛﾂｸ
4
12
EZ4-454-944-02
SIDE PLATE (R)
ｻｲﾄﾞ ﾌﾟﾚ-ﾄ (R)
1
13
EZ4-454-944-12
SIDE PLATE (L)
ｻｲﾄﾞ ﾌﾟﾚ-ﾄ (L)
1
14
EZ4-454-945-01
CYLINDER PLATE
ｼﾘﾝﾀﾞ- ﾌﾟﾚ-ﾄ
4
15
EZ4-458-991-01
COLLAR (8-6-3), Y AXIS
ｶﾗ- (8-6-3), Y ｼﾞｸ
4
16
EZ4-705-547-11
PIN, PARALLEL (A4X10)
ﾍｲｺｳ ﾋﾟﾝ (A4X10)
12
17
EZ4-719-971-01
NIPPLE, JOINT (KQ2N06-99)
ﾂｷﾞﾃ ﾆﾂﾌﾟﾙ (KQ2N06-99)
4
18
EZ7-683-408-04
BOLT,HEXAGON SOCKET 3X16
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X16
8
19
EZ7-683-419-04
BOLT HEXAGON SOCKET 4X8
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X8
32
20
EZ7-683-420-04
BOLT,HEXAGON SOCKET 4X10
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X10
24
21
EZ7-683-423-04
BOLT,HEXAGON SOCKET 4X16
6 ｶｸｱﾅﾂｷ ﾎﾞﾙﾄ 4X16
48
22
EZ7-683-452-04
BOLT,HEXAGON SOCKET 6X10
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 6X10
4
23
EZ7-683-457-04
SOCKET 6X20
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 6X20
12
24
EZ7-683-465-04
BOLT,HEXAGON SOCKET 6X40
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 6X40
8
25
EZ7-683-472-04
BOLT,HEXAGON SOCKET 8X16
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 8X16
4
26
EZA-192-115-8A
SENSOR (B) ASSY, FLATCAR RISE
ﾀﾞｲｼﾔ ｼﾞﾖｳｼﾖｳ ｾﾝｻ (B) ASSY
1
27
EZ4-463-738-01
BRACKET R, BOTTOM
ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ R ﾎﾞﾄﾑ
2
28
EZ4-463-739-01
CONNECTOR BRACKET R, SPACER
ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ R ｽﾍﾟ-ｻ
2
29
EZA-1944-226-B
TROLLEY CONTACT(M)A MOUNT
ﾄﾛﾘｰ CONTACT(M)A MOUNT
2
30
EZA-1944-227-B
TROLLEY CONTACT(M)B MOUNT
ﾄﾛﾘｰ CONTACT(M)B MOUNT
2
31
EZ4-472-320-01
CONNECTOR COVER
ｺﾈｸﾀ- ｶﾊﾞ-
2
32
EZ2-580-594-01
SCREW, +PSW M3X12
ﾈｼﾞ +PSW M3X12
8
33
EZ2-580-600-01
SCREW, +PSW M4X8
SCREW, +PSW M4X8
8
34
EZ3-719-601-61
SCREW (B2X5), TAPPING
0 ﾊﾞﾝ P3 ｼﾕ ﾀﾂﾋﾟﾝ B2X5
16
35
EZ7-683-403-04
BOLT,HEXAGON SOCKET 3X6
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6
8
36
EZ4-447-109-11
UNION (KQ2L06-M5A), ELBOW
ｴﾙﾎﾞ ﾕﾆｵﾝ (KQ2L06-M5A)
2
37
EZ7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
12
38
EZ4-455-626-02
POSITIONING BUSH (MASTR)
ｲﾁｷﾞﾒ ﾌﾞﾂｼﾕ (ｷｼﾞﾕﾝ)
4
39
EZ4-455-627-01
POSITIONING BUSH (SLAVE)
ｲﾁｷﾞﾒ ﾌﾞﾂｼﾕ (ｼﾞﾕｳｿﾞｸ)
4
40
EZ4-447-250-11
STRAIGHT (KQ2H06-08A)
ｲｹｲ ｽﾄﾚ-ﾄ (KQ2H06-08A)
2
41
EZ4-455-638-01
CONNECTOR BRACKET UPPER
ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ ｱﾂﾊﾟ-
2
42
EZ4-455-639-01
CONNECTOR BRACKET BOTTOM
ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ ﾎﾞﾄﾑ
2
43
EZ4-455-640-01
CONNECTOR BRACKET SPACER
ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ ｽﾍﾟ-ｻ
2
44
EZ4-463-737-01
CONNECTOR BRACKET R, UPPER
ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ R ｱﾂﾊﾟ-
2
A-13
A6
架台 ASSY-3
Base frame assy - 3
