B- 47 B23 コンベア配線 -4 Wiring diagram Co nvey or - 4 C - C N T 3 C N 1 4 0 6 C - C N T 3 C N 1 4 0 0 C N 1 4 0 1 C - D R V 3 C N 2 C N 2 C - D R V 3 C - C N T 3 C N 1 4 0 2 C N 1 4 0 3 C - D R V 3 C N 2 C - D R V 3 C N 2 C …
B-46
B22
コンベア配線-3
Wiring diagram Conveyor - 3
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
EZ1-969-347-13
HARNESS (C CNT2-RAIL OT,NZL OT)
ﾊ-ﾈｽ (C CNT2-RAIL OT, NZL OT)
1
2
EZ1-969-349-12
HARNESS (C CNT2-RY)
ﾊ-ﾈｽ (C CNT2-RY)
1
3
EZ1-969-350-12
HARNESS (C CNT3-BACKUP)
ﾊ-ﾈｽ (C CNT3-BACKUP)
1
4
EZ1-969-352-11
HARNESS (C CNT3-CLAMP CS)
ﾊ-ﾈｽ (C CNT3-CLAMP CS)
1
B-47
B23
コンベア配線-4
Wiring diagram Conveyor - 4
C - C N T 3
C N 1 4 0 6
C - C N T 3
C N 1 4 0 0
C N 1 4 0 1
C - D R V 3
C N 2
C N 2
C - D R V 3
C - C N T 3
C N 1 4 0 2
C N 1 4 0 3
C - D R V 3
C N 2
C - D R V 3
C N 2
C L P 1 M V
C L P 2 M V
C L P 3 M V
C L P 4 M V
C L A M P 1 M V
( F R )
C L A M P 2 M V
( F L )
C L A M P 1 M V
( R R )
C L A M P 1 M V
( R L )
1
2
2
2
2
B-48
B23
コンベア配線-4
Wiring diagram Conveyor - 4
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
EZ1-969-353-11
HARNESS (C CNT3-CLAMP MV)
ﾊ-ﾈｽ (C CNT3-CLAMP MV)
1
2
EZ1-969-346-12
HARNESS (C DRV3-C CNT3)
ﾊ-ﾈｽ (C DRV3-C CNT3)
1
