A- 18 A8 架台 ASSY -5 Base frame assy - 5 ｲﾗｽﾄ番号 Ref.No. 品番 Part Number Description 品名 個数 Q'ty 備考 Remarks 1 EZ4- 455 - 714 - 02 COVER BOX (R) ｶﾊﾞ - BOX (R) 1 2 EZ4- 455 - 712 - 02 BASE ﾍﾞ - ｽ 2 3 EZA- 191 -678- 0A CON…
A-17
A8
架台 ASSY-5
Base frame assy - 5
A-18
A8
架台 ASSY-5
Base frame assy - 5
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
EZ4-455-714-02
COVER BOX (R)
ｶﾊﾞ- BOX (R)
1
2
EZ4-455-712-02
BASE
ﾍﾞ-ｽ
2
3
EZA-191-678-0A
CONVEYOR CONT COMPL
ｺﾝﾍﾞｱ CONT COMPL
3
4
EZ4-705-584-51
SPACER (SQ-50)
ｽﾍﾟ-ｻ (SQ-50)
12
5
EZ4-705-584-11
SPACER (SQ-10)
ｽﾍﾟ-ｻ (SQ-10)
18
6
EZ1-492-150-11
DRIVER, PULSE MOTOR
ﾊﾟﾙｽ ﾓ-ﾀ ﾄﾞﾗｲﾊﾞ (A8349-0407Y)
1
7
EZ1-492-151-11
DRIVER, PULSE MOTOR
ﾊﾟﾙｽ ﾓ-ﾀ ﾄﾞﾗｲﾊﾞ (A8350-0414Y)
1
8
EZ1-492-152-11
DRIVER, PULSE MOTOR
ﾊﾟﾙｽ ﾓ-ﾀ ﾄﾞﾗｲﾊﾞ (A8351-0407Y)
1
9
EZ1-755-544-11
RELAY (RU2S-D-D24)
ﾘﾚ- (RU2S-D-D24)
2
10
EZ1-755-545-11
SOCKET, RELAY (SM2S-05B)
ﾘﾚ- ｿｹｯﾄ (SM2S-05B)
2
11
EZ4-461-731-01
SHAFT, CABLE HOLD
ｹ-ﾌﾞﾙ ﾎ-ﾙﾄﾞ ｼｬﾌﾄ
4
12
EZ4-461-727-01
BRACKET, MECHANICAL VALVE
ﾒｶﾆｶﾙ ﾊﾞﾙﾌﾞ ﾌﾞﾗｹｯﾄ
2
13
EZ4-457-358-01
VALVE (MVP63-J), MECHANICAL
ﾒｶﾆｶﾙ ﾊﾞﾙﾌﾞ (MVP63-J)
2
14
EZ7-682-948-01
SCREW +PSW 3X8
+PSW 3X8
18
15
EZ7-683-418-04
BOLT,HEXAGON SOCKET 4X6
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X6
8
16
EZ7-683-427-04
BOLT,HEXAGON SOCKET 4X25
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X25
4
17
EZ7-683-435-04
BOLT,HEXAGON SOCKET 5X10
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X10
2
18
EZ7-683-403-04
BOLT,HEXAGON SOCKET 3X6
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6
8
19
EZ4-455-714-11
COVER BOX (L)
ｶﾊﾞ- BOX (L)
1
20
EZ4-486-935-01
FINGER GUARDS (109-059)
ﾌｨﾝｶﾞ- ｶﾞ-ﾄﾞ (109-059)
1
21
EZ1-492-200-31
FAN ASSY (DRV)
FAN ASSY (DRV)
1
22
EZ7-682-955-01
SCREW +PSW 3X30
+PSW 3X30
4
23
EZ4-718-724-04
NUT (1TYPE) HEXAGON(M3X0.5SUS)
ﾛﾂｶｸ ﾅﾂﾄ (1 ｼﾕ) (M3X0.5SUS)
4
EZ2-149-018-01
BRACKET HOLDING (SFA-101)
ﾎｼﾞ ｶﾅｸﾞ (SFA-101)
4
RELAY HOLDER
A-19
A9
架台 ASSY-6
Base frame assy - 6
