A- 47 A20 搬送部ユニット - 幅調整 1 Conveyor uni t – 1 ｲﾗｽﾄ番号 Ref.No. 品番 Part Number Description 品名 個数 Q'ty 備考 Remarks 1 EZ4- 454 - 259 - 02 BASE, CONVEYOR ｺﾝﾍﾞｱ ﾍﾞ - ｽ 1 2 EZ4- 454 - 254 - 01 SUPPORT (L), FIXED ｺﾃｲ ｼﾁﾕｳ (L) …
A-46
A20
搬送部ユニット-幅調整 1
Conveyor unit – 1
A-47
A20
搬送部ユニット-幅調整 1
Conveyor unit – 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
EZ4-454-259-02
BASE, CONVEYOR
ｺﾝﾍﾞｱ ﾍﾞ-ｽ
1
2
EZ4-454-254-01
SUPPORT (L), FIXED
ｺﾃｲ ｼﾁﾕｳ (L)
1
3
EZ4-454-255-01
BRACKET, FIXED SUPPORT
ｺﾃｲ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ
1
4
EZ4-454-254-11
SUPPORT (R), FIXED
ｺﾃｲ ｼﾁﾕｳ (R)
1
5
EZ4-454-255-01
BRACKET, FIXED SUPPORT
ｺﾃｲ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ
1
6
EZ4-454-260-02
BRACKET, RAIL
ﾚ-ﾙ ﾌﾞﾗｹﾂﾄ
1
7
EZ4-454-502-01
GUIDE (MHS15C3R640S2ET213)
ｶﾞｲﾄﾞ (MHS15C3R640S2ET213)
3
8
EZ4-454-256-01
SUPPORT (LR), MOVABLE
ｶﾄﾞｳ ｼﾁﾕｳ (LR)
1
9
EZ4-454-258-01
BRACKET, MOVABLE SUPPORT
ｶﾄﾞｳ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ
1
10
EZ4-454-257-01
SUPPORT (C), MOVABLE
ｶﾄﾞｳ ｼﾁﾕｳ (C)
1
11
EZ4-454-258-01
BRACKET, MOVABLE SUPPORT
ｶﾄﾞｳ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ
1
12
EZ4-454-256-01
SUPPORT (LR), MOVABLE
ｶﾄﾞｳ ｼﾁﾕｳ (LR)
1
13
EZ4-454-258-01
BRACKET, MOVABLE SUPPORT
ｶﾄﾞｳ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ
1
14
EZ4-454-257-01
SUPPORT (C), MOVABLE
ｶﾄﾞｳ ｼﾁﾕｳ (C)
1
15
EZ4-454-258-01
BRACKET, MOVABLE SUPPORT
ｶﾄﾞｳ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ
1
16
EZ4-700-061-01
BEARING (6000ZZ)
ﾍﾞｱﾘﾝｸﾞ (6000ZZ)
18
17
EZ4-453-827-01
SCREW (TMR14-RX739/TNBC)
ﾀﾞｲｹｲﾈｼﾞ(TMR14-RX739/TNBC-AT*)
6
18
EZ4-761-803-11
NUT, FINE U (TREATMENT HAVE)
ﾌｱｲﾝ U ﾅﾂﾄ (ｼﾖﾘ ｱﾘ) (FU00SS)
6
19
EZ4-453-831-01
BEARING (626ZZ1)
ﾍﾞｱﾘﾝｸﾞ (626ZZ1)
12
20
EZ4-454-515-01
WASHER (FWSSA-D19-V16.0-T4.0)
ｷﾝｿﾞｸﾜﾂｼﾔ(FWSSA-D19-V16.0-T4.0)
4
21
EZ4-455-705-01
COLLAR (D10-D6.2-L2.8)
ｶﾗ- (D10-D6.2-L2.8)
4
22
EZ4-455-481-01
SPLIN (HTS7P-2+HTP7SX730)
ﾛﾂｶｸ ｽﾌﾟﾗｲﾝ(HTS7P-2+HTP7SX730)
2
23
EZ4-455-480-01
SPLIN (HTS7P-2+HTP7SX717)
ﾛﾂｶｸ ｽﾌﾟﾗｲﾝ(HTS7P-2+HTP7SX717)
2
24
EZ4-454-288-02
BRACKET, CABLE BARE
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ
1
25
EZ1-492-229-31
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾊﾞ ﾘﾐﾂﾄ RL4)
1
26
EZ4-454-292-01
DOG (3RR), SENSOR
ｾﾝｻ- ﾄﾞｸﾞ (3RR)
1
27
EZ4-454-370-01
DOG (4RR), SENSOR
ｾﾝｻ- ﾄﾞｸﾞ (4RR)
1
28
EZ4-454-365-02
PLATE L2-3 (LR), SENSOR
ｾﾝｻ ﾌﾟﾚ-ﾄ L2-3 (LR)
4
29
EZ4-454-366-12
PLATE L4 (R), SENSOR
ｾﾝｻ ﾌﾟﾚ-ﾄ L4 (R)
1
30
EZ4-454-368-02
BRACKET (2R), CABLE BARE
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ (2R)
1
31
EZ4-454-369-02
BRACKET (4RL), CABLE BARE
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ (4RL)
1
32
EZ4-454-366-02
PLATE L4 (L), SENSOR
ｾﾝｻ ﾌﾟﾚ-ﾄ L4 (L)
1
33
EZ4-454-364-02
BRACKET (3R), CABLE BARE
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ (3R)
1
34
EZ4-454-290-01
DOG (2R), SENSOR
ｾﾝｻ- ﾄﾞｸﾞ (2R)
1
35
EZ4-454-372-01
DOG (4R-A2), SENSOR
ｾﾝｻ ﾄﾞｸﾞ (4R-A2)
1
36
EZ4-455-707-01
PLATE SENCER 4R-A2
ﾌﾟﾚ-ﾄ ｾﾝｻ (4R-A2)
1
37
EZ4-454-371-01
BRACKET (L), DUCT
ﾀﾞｸﾄ ﾌﾞﾗｹﾂﾄ L
2
38
EZ4-455-708-01
BRACKET (C), DUCT
ﾀﾞｸﾄ ﾌﾞﾗｹﾂﾄ (C)
1
39
EZ4-454-503-01
BARE (TKP0130W15R20), CABLE
ｹ-ﾌﾞﾙ ﾍﾞｱ (TKP0130W15R20)
4
40
EZ1-492-217-14
SOLENOID VALVE ASSY
ｿﾚﾉｲﾄﾞ ﾊﾞﾙﾌﾞ ASSY
1
41
EZ4-453-569-01
PLUG (CYP025-08B29449)
ﾌﾟﾗｸﾞ (CYP025-08B29449)
3
42
EZ4-426-151-01
SILENCER(AN10-01)
ｻｲﾚﾝｻ(AN10-01)
2
43
EZ4-447-063-41
UNION (KQ2L08-01AS), ELBOW
ｴﾙﾎﾞ ﾕﾆｵﾝ (KQ2L08-01AS)
2
44
EZ4-457-146-31
CONTROLLER (AS1211F-M5-02A)
ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ-(AS1211F-M5-02A)
16
45
EZ1-492-215-21
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾊﾞ ｹﾞﾝﾃﾝ RL4)
1
46
EZ4-453-764-01
RAIL, DIN(5PERF60MM/Z)
DIN ﾚ-ﾙ (NS35/7, 5PERF60MM/Z)
2
47
EZ4-453-826-01
PULLEY (P1110-015) (E), TIMING
ﾀｲﾐﾝｸﾞ ﾌﾟ-ﾘ (P1110-015) E
6
48
EZ4-453-823-01
PULLEY (P1110-010-1) (B)
ﾀｲﾐﾝｸﾞ ﾌﾟ-ﾘ (P1110-010-1) B
4
49
EZ2-177-403-01
BELT, TIMING (234-3GT-9)
ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ (234-3GT-9)
4
50
EZ4-453-828-21
BELT (1947-3GT-9), TIMING
ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ (1947-3GT-9)
3
A-48
A20
搬送部ユニット-幅調整 1
Conveyor unit – 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
51
EZ4-473-489-01
BRACKET, HARNESS GUIDE
ﾊ-ﾈｽ ｶﾞｲﾄﾞ ﾌﾞﾗｹﾂﾄ
2
52
EZ4-431-981-31
PIN (DIA. 4), PARALLEL
ﾍｲｺｳ ﾋﾟﾝ ﾌｱｲ 4 ｼﾘ-ｽﾞ
26
53
EZ7-683-423-04
BOLT,HEXAGON SOCKET 4X16
6 ｶｸｱﾅﾂｷ ﾎﾞﾙﾄ 4X16
77
54
EZ7-683-420-04
BOLT,HEXAGON SOCKET 4X10
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X10
50
55
EZ7-683-436-04
BOLT,HEXAGON SOCKET 5X12
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X12
24
56
EZ7-683-401-04
BOLT,HEXAGON SOCKET 3X4
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X4
12
57
EZ7-683-403-04
BOLT,HEXAGON SOCKET 3X6
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6
54
58
EZ7-683-427-04
BOLT,HEXAGON SOCKET 4X25
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X25
6
59
EZ4-718-766-02
SET-SCREW (M3X5 SUS), HEAD
ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M3X5 SUS)
8
60
EZ2-915-937-11
BOLT (M4 SUS), SOCKET BUTTON
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾀﾝ ﾎﾞﾙﾄ (M4 SUS)
20
61
EZ7-624-198-21
STOP RING 10, TYPE C
C ｶﾞﾀ ﾄﾒﾜ 10 (ｼﾞｸ ﾖｳ)
6
62
EZ4-701-529-01
TIE MOUNT (MB1)
ﾀｲﾏｳﾝﾄ (MB1)
35
63
EZ7-682-249-09
SCREW +K 3X10
+K 3X10
26
64
EZ7-682-246-09
SCREW +K 3X5
+K 3X5
9
65
EZ7-683-435-04
BOLT,HEXAGON SOCKET 5X10
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X10
55
66
EZ4-454-517-01
PIN (B4X16 SUS), PARALLEL
ﾍｲｺｳ ﾋﾟﾝ (B4X16 SUS)
6
67
EZ1-492-249-11
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟﾋﾟﾝ 2)
1
68
EZ7-621-255-75
SCREW +P 2X12
+P 2X12
12
69
EZ4-454-549-01
PIN (B3X8) PARALLEL
ﾍｲｺｳ ﾋﾟﾝ (B3X8)
2
70
401-55273
SLIT (OS-EX10-15)
ｽﾘｯﾄ (OS-EX10-15)
3
71
EZ1-492-250-12
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟﾋﾟﾝ 3)
1
72
EZ1-492-251-11
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟﾋﾟﾝ 4)
1
73
EZ1-492-229-22
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾊﾞ ﾘﾐﾂﾄ RL3)
1
74
EZ1-492-311-11
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾊﾞ ﾘﾐﾂﾄ RL3(2))
1
75
EZ1-492-215-11
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾊﾞ ｹﾞﾝﾃﾝ RL2)
1
76
EZ1-492-229-11
SENSOR ASSY
ｾﾝｻ ASSY (ﾊﾊﾞ ﾘﾐﾂﾄ RL2)
1
