W i ri n g pa r t s l i s t
No Part No. Part Name Q'ty Remarks No Part No. Part Name Q'ty Remarks
77 KHY-M66G6-000 HNS,SMEMA 1 J0185 115 KHN-M4275-010 HNS,KEY/MOUSE 1 J0258
78 KHY-M66N3-000 HNS,LE-OUT 1 1 J0186 116 KHY-M66KA-002 HNS,FID LIGHT 1 1 J0300
79 KHY-M66N4-000 HNS,LE-OUT 2 1 J0187 117 KHY-M66KA-210 HNS,FID LIGHT SHORT 2 J0301,J0321
80 KHY-M66GA-000 HNS,Y-FLEX YORG OT 1 J0190 118 KKJ-M663T-000 HNS,CAM.SEL.DC24V 1 J0302
81 KHY-M66GE-000 HNS,CONV.TERMINAL F 1 J0191 119 KKD-M66J2-000 HNS,HEAD VAC SENSOR 1 J0304
82 KJJ-M66GP-010 HNS,LDC U/L DI 1 J0192 120 KKD-M66J3-010 HNS,HEAD DO 1 J0305
83 KHY-M66GE-100 HNS,CONV.TERMINAL R 1 J0193 121 KHY-M66J5-141 HNS,Z LINEAR PI 1 3 J0310 ～ J0312
84 KHY-M66GH-000 HNS,AIR PRESSURE 1 J0194 122 KHY-M66J5-251 HNS,Z LINEAR PI 2 2 J0313 ～ J0314
85 KHY-M66H7-000 HNS,BLOW VALVE 1 J0195 123 KHY-M66KA-210 HNS,FID LIGHT SHORT 1 J0321
86 KW3-M66GW-004 HNS,NEXT INTERFACE 1 J0198 124 KHY-M66K2-001 HNS,MULTI CAMERA 1 J0501,J0507
87 KKE-M66GX-002 HNS,PRE.INTERFACE 2 1 J0199 125 KHY-M66K0-010 HNS,Y-FLEX CAM.EXT 1 J0502
88 KHY-M666A-001 HNS,FEE.FLOAT SHORT 6 J0200,J0201,J0202,J0203,J0204,J0205 126 KHY-M66K1-020 HNS,X-FLEX CAM.EXT 1 J0503
89
KGA-M669V-040 HNS,SWITCH ACTIVE 1 J0207/J0213
127
KHY-M66K3-002 HNS,FID1 CAMERA 1 J0504
90 KGA-M669V-241 HNS,SWITCH START 1 J0208/J0214 128 KHY-M66BE-100 HNS,VISION TRG 1 J0530
91 KGA-M669V-321 HNS,SWITCH STOP 1 J0209/J0215 129 KJJ-M66RA-000 HNS,FDR PWR F1/R2 1 J0754
92
KHA-M669V-030 HNS,SWITCH STOP 1 J0209/J0215
130
KJJ-M66RA-100 HNS,FDR PWR F2/R1 1 J0755
93 KGA-M669V-421 HNS,SWITCH ERR.CLR. 1 J0210/J0216 131 KHY-M66RE-000 HNS,FDR PWR F1 R1 1 J0771,J0773
94 KHA-M669V-121 HNS,SWICTH ERR.CLR. 1 J0210/J0216 132 KHY-M66RE-100 HNS,FDR PWR F2 R2 1 J0772,J0774
95
KGA-M669V-140 HNS,SWITCH READY 1 J0211/J0217
133
KHY-M66R4-000 HNS,FES.CUNET 1 J0781/J0785/J0789/J0793
96 KGA-M669V-540 HNS,SWITCH RESET 1 J0212/J0218 134 KHY-M66R2-004 HNS,CLAMP MKY F1 R1 1 J0782
97 KHY-M66G4-000 HNS,SIG.TOWER 1 J0221 135 KHY-M66R5-000 HNS,FES.PWR 1 J0783/J0787/J0791/J0795
98 KKJ-M66H2-010 HNS,CONV VALVE 1 J0222 136 KHY-M66R3-001 HNS,CLAMP PWR F1 R1 1 J0784
99 KHY-M66H3-000 HNS,AMF 1 J0225 137 KHY-M66R2-103 HNS,CLAMP MKY F2 R2 1 J0786
100 KW3-M668J-020 HNS,TOUCH PANEL ASSY 1 J0231 138 KHY-M66R3-101 HNS,CLAMP PWR F2 R2 1 J0788
101 KU8-M66F5-203 HNS,VGA 2M 1 J0232 139 KHY-M66RL-120 HNS,FDR DI FIX 1 J0797,J0798,J0799,J0800
102 KHY-M6640-000 HNS,KEYBOARD ASSY 1 J0233 140 KHY-M66RL-030 HNS,FDR DI FES 1 J0797/J0798/J0799/J0800
103 KHY-M663H-010 HNS,LCD POWER 1 2 J0234,J0235 141 KHY-M66RM-001 HNS,FDR DO FES 1 J0801/J0802/J0803/J0804
104 KU8-M66F5-303 HNS,VGA 3M 1 J0236 142 KJJ-M66RM-211 HNS,FDR DO FIX-L 1 J0801/J0803
105 KU8-M66F5-503 HNS,VGA 5M 1 J0237 143 KHY-M66RM-101 HNS,FDR DO FIX-R 1 J0802/J0804
106 KGA-M6640-020 HNS,SWITCHER IN1 ASS 1 J0238 144 KHY-M66TE-003 HNS,F.CTRL - FDR 24 J1001-24/J1031-54/J1061-84/J1091-114
107 KGA-M6640-110 HNS,SWITCHER IN2 ASS 1 J0239 145 KHJ-M668A-001 HNS,RS232C 1 J1130/J1132/J1134/J1136
108 KGT-M6680-011 HNS,SERIAL 3M ASSY 1 J0240 146 KHJ-M668A-100 HNS,CN41-RS232C 1 J1131/J1133/J1135/J1137
109 KHY-M6640-100 HNS,MOUSE ASSY 1 J0241 147 KKE-M6522-000 RELAY,G3RZ DC24 1 KA01
110 KGK-M6681-000 HNS,SERIAL 4M ASSY 1 J0242 148 KV5-M6442-000 RELAY SOCKET 1 KA01
111 KHW-M662H-200 HNS,PANEL POWER 1 J0252/J0253 149 KHY-M537F-000 SAFETY RELAY 1 KM10
112 KHW-M662H-102 HNS,LCD POWER 2 1 J0252/J0253 150 KGS-M537G-000 CONTACTOR,1 1 KM11
113 KU8-M66F5-203 HNS,VGA 2M 1 J0254/J0255 151 KGS-M537G-100 CONTACTOR,1 1 KM11A
114 KGT-M6681-101 HNS,SERIAL 2M ASSY 1 J0256/J0257 152 KGS-M537H-200 CONTACTOR,2 1 KM12
Condential & Proprietary
PAGE
25
1302
W i ri n g pa r t s l i s t
No Part No. Part Name Q'ty Remarks No Part No. Part Name Q'ty Remarks
153 KGS-M537H-100 CONTACTOR,2 1 KM12A
154 KGT-M5106-B00 SMT OPE.PANEL ASSY 2 LCD1,LCD2
155 KKE-M5119-000 15 TOUCH LCD ASSY" 2 LCD1,LCD2
156 KHN-M537A-000 NOIZE FILTER 1 NF11
157 KJJ-M4554-000 TERMINAL BOARD ASSY 2 P013,P014
158 KJJ-M4580-040 I/O CONV.BOARD ASSY 1 P025
159 KGA-M4472-023 SWITCHER BOARD ASSY 1 P031
160 KHY-M4570-200 I/O HEAD BOARD ASSY 1 P041
161 KHY-M5802-021 Z SERVO UNIT ASSY 2 P042-P043
162 KHY-M5802-221 Z R SERVO UNIT ASSY 1 P044
163 KHN-M220F-061 CAMERA SELECTOR 1 P082
164 KHY-M4476-063 FDR.CTRL BOARD ASSY 1 P103,P104,P105,P106
165
KGS-M6510-000 BREAKER ASSY 1 QF11
166 KHN-M6513-010 CIRCUIT PROTECTOR,1P 1 QF21
167 KH1-M539M-410 PROTECTOR ACCES.1P 1 QF21
168
KJV-M6517-000 BREAKER,THERMAL 12A 1 QF23
169 KHY-M6517-300 BREAKER,THERMAL 10A 1 QF24
170 KHY-M6517-200 BREAKER,THERMAL 20A 1 QF24
171
KHY-M6517-100 BREAKER,THERMAL 4A 1 QF25
172 KHY-M6513-010 CIRCUIT PROTECTOR,3P 1 QF31
173 KM6-M539M-010 PROTECTOR ACCES.3P 1 QF31
174 KGS-M6573-111 SPARK KILLER ASSY 1 S10
175 KGK-M5138-000 SWITCH EMG ASSY 2 SB31,SB32
176 KGK-M5381-000 EMG PLATE 2 SB31,SB32
177 KGK-M5138-000 SWITCH EMG ASSY 2 SB31,SB32
178 KGK-M5381-000 EMG PLATE 2 SB31,SB32
179 KW7-M5126-H01 SAFETY SW UNIT ASSY 1 SQ101
180 KW7-M5127-000 SAFETY SWITCH KEY 1 SQ101
181 KHY-M5126-G02 SAFETY SW UNIT ASSY 1 SQ101
182 KJJ-M5328-100 POWER TRANSFORMER 1 TM11
183 KHY-M643A-001 TERMINAL,POWER 4 XB11
184 KHY-M643E-001 END PLATE 2 XB11
185 KG2-M643A-000 PARTS 3-1 1 XT21
186 K44-M643E-001 PARTS 3-2(END PLATE) 2 XT21
187 KG2-M643A-000 PARTS 3-1 1 XT31
188 K44-M643E-001 PARTS 3-2(END PLATE) 2 XT31
189
190
