https://www.phoenixcontact.com/sg/products/3210567 05/27/2020Page17/31 Double-level terminal block-PTTB 2,5-3210567 Accessories End cover-D-PTTB 2,5-3211634 End cover, length: 68 mm, width: 2.2 mm, height: …
https://www.phoenixcontact.com/sg/products/3210567
05/27/2020Page16/31
Double-level terminal block-PTTB 2,5-3210567
Accessories
DIN rail, unperforated-NS 35/15-2,3 UNPERF 2000MM-1201798
DIN rail, unperforated, Standard profile 2.3mm, width:35 mm, height:15 mm, acc. to EN 60715, material:Steel,
galvanized, passivated with a thick layer, length:2000 mm, color:silver
Documentation
Mounting material-PT-IL-3208090
Operating decal for the push-in Technology
End block
End clamp-CLIPFIX 35-3022218
Quick mounting end clamp for NS 35/7,5 DIN rail or NS 35/15 DIN rail, with marking option, width: 9.5 mm, color:
gray
End clamp-CLIPFIX 35-5-3022276
Quick mounting end clamp for NS 35/7,5 DIN rail or NS 35/15 DIN rail, with marking option, with parking option for
FBS...5, FBS...6, KSS 5, KSS 6, width: 5.15 mm, color: gray
End clamp-E/NS 35 N-0800886
End clamp, width: 9.5 mm, color: gray
End cover
https://www.phoenixcontact.com/sg/products/3210567
05/27/2020Page17/31
Double-level terminal block-PTTB 2,5-3210567
Accessories
End cover-D-PTTB 2,5-3211634
End cover, length: 68 mm, width: 2.2 mm, height: 39.6 mm, color: gray
Filler plug
Filler plugs-CEC 2,5-3062757
Cover for conductor shaft, 10-pos., for spring cage terminal blocks (ST) and terminal blocks with push-in technology
(PT) with a width of 5.2 mm
Front adapter
Front adapters-VIP-PA-PWR/20XOE/ 1,0M/S7-2904724
VIP power cabling, universal front adapter for connection to all popular 20-pos. SIMATIC S7-300 I/O modules, via 20
individual wires in rope structure, not assembled (field connection, e.g., via 20 modular terminal blocks), cable length:
1 m
Front adapters-VIP-PA-PWR/20XOE/ 2,0M/S7-2904725
VIP power cabling, universal front adapter for connection to all popular 20-pos. SIMATIC S7-300 I/O modules, via 20
individual wires in rope structure, not assembled (field connection, e.g., via 20 modular terminal blocks), cable length:
2 m
Front adapters-VIP-PA-PWR/20XOE/ 3,0M/S7-2904726
VIP power cabling, universal front adapter for connection to all popular 20-pos. SIMATIC S7-300 I/O modules, via 20
individual wires in rope structure, not assembled (field connection, e.g., via 20 modular terminal blocks), cable length:
3 m
https://www.phoenixcontact.com/sg/products/3210567
05/27/2020Page18/31
Double-level terminal block-PTTB 2,5-3210567
Accessories
Front adapters-VIP-PA-PWR/20XOE/10,0M/S7-2904730
VIP power cabling, universal front adapter for connection to all popular 20-pos. SIMATIC S7-300 I/O modules, via 20
individual wires in rope structure, not assembled (field connection, e.g., via 20 modular terminal blocks), cable length:
10 m
Front adapters-VIP-PA-PWR/40XOE/ 1,0M/S7-2904731
VIP power cabling, universal front adapter for connection to all popular 40-pos. SIMATIC S7-300 I/O modules, via 40
individual wires in rope structure, not assembled (field connection, e.g., via 40 modular terminal blocks), cable length:
1 m
Front adapters-VIP-PA-PWR/40XOE/ 2,0M/S7-2904732
VIP power cabling, universal front adapter for connection to all popular 40-pos. SIMATIC S7-300 I/O modules, via 40
individual wires in rope structure, not assembled (field connection, e.g., via 40 modular terminal blocks), cable length:
2 m
Front adapters-VIP-PA-PWR/40XOE/ 3,0M/S7-2904733
VIP power cabling, universal front adapter for connection to all popular 40-pos. SIMATIC S7-300 I/O modules, via 40
individual wires in rope structure, not assembled (field connection, e.g., via 40 modular terminal blocks), cable length:
3 m
Front adapters-VIP-PA-PWR/40XOE/10,0M/S7-2904737
VIP power cabling, universal front adapter for connection to all popular 40-pos. SIMATIC S7-300 I/O modules, via 40
individual wires in rope structure, not assembled (field connection, e.g., via 40 modular terminal blocks), cable length:
10 m
Insulating sleeve
