Contents
LC2-0303
1 Base Section
Base...........................................................
1-1
2
Cover Section
Cover.........................................................
2-1
3
Moving-axis Section
X-axis .........................................................
3-1
Y-axis .........................................................
3-2
4 Feeder Holder Section
Feeder Holder ...........................................
4-1
5 Head Section
Head .........................................................
5-1
Vision Attachment .....................................
5-2
Nozzle Selection........................................
5-3
6
Camera Section
Multi-Camera.............................................
6-1
7
Conveyor Section
Main Conveyor-1 .......................................
7-1
Main Conveyor-2 .......................................
7-2
Main Stopper ............................................. 7-3
Push-Up Unit............................................. 7-4
8 ANC Station Section
ANC Station (Option) ................................
8-1
9 Controller Section
Controller ..................................................
9-1
10 Exterior, etc Section
Exterior, etc..............................................
10-1
1
1
Base
Base
LC2-000-0705
1
8
18
19
20
22
23
24
25
29
30
26
28
27
15
16
17
21
10
31
37
OLD
40
39
42
38
41
47
43
32
9
45
44
36
48
33
35
34
46
2
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 LC2-M1101-00X BASE 1 /
1-1 LC2-M1101-01X BASE 1 (2003/10/16) OK /
2 LC2-M1110-00X LEVELING BOLT ASSY. 4 /
3
4
5
6
7
8 LC2-M1121-00X PARALLEL PIN 1 /
Delete (2003/11/12) /
9 KGA-M4126-00X GUIDE RAIL L ASSY 1 /
9-1 KGA-M4126-01X GUIDE RAIL L ASSY 1 (2002/10/7) NG /
10 KGA-M4127-00X GUIDE RAIL R ASSY 1 /
10-1 KGA-M4127-01X GUIDE RAIL R ASSY 1 (2002/10/7) NG /
15 LC2-M1106-00X PLATE, FAN 1 /
16 LC2-M110A-01X PLATE-R 1 /
17
LC2-M110B-00X PLATE-L 1 /
18
LC2-M110D-00X PLATE, TRANS 1 /
19 LC2-M110E-00X COVER,PS. 1 /
19-1 LC2-M110E-01X COVER,PS. 1 (2002/8/20) OK /
20 LC2-M1114-01X STAY, AIR 1 /
21 LC2-M11A1-00X PLATE, CONTOROL
1
/
22
LC2-M11AD-00X CABLE, CLAMP
1
/
23 LC2-M110G-00X COVER,C2 1 /
23-1 LC2-M110G-01X COVER,C2 1 (2002/10/2) NG /
24
LC2-M132P-00X COVER, FH 1 /
25
LC2-M1118-00X AIR SET 1 /
26
KG7-M8596-00X
PRESSURE GAUGE
1
/
27
KG7-M8512-00X JOINT
1
/
28
KG7-M8513-00X JOINT
1
/
29
$SLY10-03 JOINT
1
/
30
KGA-M11B0-00X AIR TAG
1
/
31 LC2-M130B-00X COVER, 6
1
/
32 LC2-M130R-00X STAY,C1 1 /
32-1 LC2-M130R-01X STAY,C1 1 From the 26th (2002/9/27) NG /
33
LC2-M130T-00X STAY, CU
1
/
34 LC2-M130U-00X STAY,C4 1 /
34-1 LC2-M130U-01X STAY,C4 1 From the 26th (2002/9/27) NG /
35
LC2-M130V-00X STAY, CL 1 /
36
LC2-M130W-00X STAY, CFF 1 /
37 LC2-M131F-01X GUIDE,TAPE 1 /
37-1 LC2-M131F-02X GUIDE,TAPE 1 From the 26th (2002/10/7) NG /
38 LC2-M131G-00X STAY, COVER F
1
/
39 LC2-M131H-00X STAY COVER R 1 /
39-1 LC2-M131H-01X STAY,COVER R 1 (2002/8/8) OK /
40 LC2-M132B-00X STAY,C2 1 /
40-1 LC2-M132B-01X STAY,C2 1 From the 26th (2002/8/8) NG /
41 LC2-M132C-00X STAY,CB1 1 /
41-1 LC2-M132C-01X STAY,CB1 1 From the 26th (2002/8/8) NG /
42 LC2-M132D-00X STAY,CB1L 1 /
42-1 LC2-M132D-01X STAY,CB1L 1
From the 26th (2002/8/8) NG /
43 LC2-M132E-00X STAY,C2L 1 /
43-1 LC2-M132E-01X STAY,C2L 1 From the 26th (2002/8/8) NG /
44
LC2-M132F-00X STAY, CB2 1 /
45 LC2-M132G-00X STAY,CB3 1 /
45-1 LC2-M132G-00X STAY,CB3 1 (2002/8/8) OK /
46 LC2-M132H-00X STAY,CB3L 1 /
46-1 LC2-M132H-00X STAY,CB3L 1 (2002/8/8) OK /
47
LC2-M132M-00X STAY, CB7
1
/
48 LC2-M132N-00X STAY,CFR 1 /
48-1 LC2-M132N-01X STAY,CFR 1 From the 26th (2002/8/8) NG /
1
2
Cover
Cover
LC2-000-0705
34
30
32
31
41
37
37
40, (50)
45, (52)
46
48
48
27
47
42
43
44, (51)
37
35
2
3
1
37
29
15
13
17
18
10
53
39, (49)
5
12
11
6
14
22
27
7
9
19
28
20
23
26
24
25
36
21
8
16
4
33
38
28
54
From the 26th of them
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 LC2-M1302-00X FRAME,FRONT 1 /
1-2 LC2-M1302-01X FRAME,FRONT 1 (2002/8/8) NG /
2 LC2-M1303-00X FRAME,REAR 1 /
2-1 LC2-M1303-01X FRAME,REAR 1 (2002/8/8) NG /
3 LC2-M1304-00X COVER,SIDE U 1 /
3-1 LC2-M1304-01X COVER,SIDE U 1 (2003/9/9) NG /
4 LC2-M1305-00X COVER, SIDE L 1 /
5 LC2-M1307-00X COVER,2 1 /
5-1 LC2-M1307-01X COVER,2 1 (2002/9/27) NG /
6 LC2-M130A-00X COVER,5 1 /
6-1 LC2-M130A-01X COVER,5 1 (2002/9/27) NG /
7 LC2-M130D-00X COVER, 8 1 /
8 LC2-M130E-00X STAND,F 1 /
8-1 LC2-M130E-02X STAND,F 1 (2002/9/27) NG /
9 LC2-M130F-00X STAND,R 1 /
9-1 LC2-M130F-01X STAND,R 1 (2002/9/27) NG /
10 LC2-M130G-00X PANEL,INSIDE F 1 /
10-1 LC2-M130G-01X PANEL,INSIDE F 1 (2002/8/20) NG /
11 LC2-M130H-00X PANEL, INSIDE R 1 /
12 LC2-M130J-00X COVER,9 1 /
12-1 LC2-M130J-01X COVER,9 1 (2003/9/9) NG /
13 LC2-M130N-00X
WASHER 4 /
14 LC2-M130Y-00X STAY, SENSOR 1 /
15 LC2-M1321-00X PLATE, KEYBOARD 1 /
16 LG0-M110P-00X PAD, MOUSE 1 /
17 LC2-M132J-00X STAY,CRT 3 /
17-1 LC2-M132J-01X STAY,CRT 1 (2002/10/18) NG /
18
LC2-M132L-00X STAY, CRT (2)
2
/
19 LC2-M1331-00X FRAME,A 1 /
19-1 LC2-M1331-01X FRAME,A 1 (2002/9/27) NG /
20 LC2-M1332-00X COVER,A 1 /
20-1 LC2-M1332-02X COVER,A 1 (2002/10/2) NG /
20-2 LC2-M1332-03X COVER,A 1 (2002/12/4) NG /
21 LC2-M1335-00X STAY, FRAME 2 /
22
LC2-M1336-00X BRACKET, MG.
2
/
23
LC2-M133G-00X GRIP
2
/
24 LC2-M1338-00X HINGE,1 2 /
24-1 LC2-M1338-10X HINGE,1 2 (2003/3/19) OK /
25
LC2-M1339-00X DAMPER, 1
2
/
26
LC2-M133A-00X DAMPER, 2
2
/
27
LC2-M133B-00X MG. CATCH
4
/
28
K93-M1392-00X SPACER (TM-180-303)
2
/
29 LC2-M131P-00X GROMMET 1 /
29-1 LC2-M132K-00X GROMMET 1 (2002/9/27) OK /
30
KV7-M1350-00X CAP, PATLIGHT
1
/
31 KH1-M13A9-00X BUSH 1
/
32 LC2-M1301-00X FRAME,TOP 1 /
32-1 LC2-M1301-01X FRAME,TOP 1 (2002/9/27) NG /
32-2 LC2-M1301-02X FRAME,TOP 1 (2002/12/4) NG /
33 LC2-M1306-00X COVER,1 1 /
33-1 LC2-M1306-02X COVER,1 1 (2002/9/27) NG /
34 LC2-M1308-00X COVER,3 1 /
34-1 LC2-M1308-02X COVER,3 1 (2002/10/18) NG /
35
LC2-M1309-00X COVER, 4
1
/
36
LC2-M133C-01X COVER, FEEDER (IM)
1
/
37 LC2-M13D1-00X SEAL 1
4
/
38 LC2-M13D2-00X SEAL 2 1 /
39 LC2-M130C-10X COVER,7 1 /
39-1 LC2-M130C-13X COVER,7 1 (2002/10/7) NG /
39-2 LC2-M130C-14X COVER,7 1 (2003/9/9) NG /
40 LC2-M1313-10X COVER,TOP 1 1 /
40-1 LC2-M1313-12X COVER,TOP 2 1 (2002/10/7) NG /
41 LC2-M1315-00X GRIP 1 /
41-1 LC2-M1315-10X GRIP 1 (2002/12/4) OK /
41
LC2-M1315-10X GRIP
1
/
42
LC2-M1317-00X SLIDE RAIL L
1
/
43
LC2-M1318-00X SLIDE RAIL R
1
/
44 LC2-M1319-10X STAY,1 1 /
44-1 LC2-M1319-11X STAY,1 1 (2002/10/7) NG /
45 LC2-M131A-10X STAY,2 1 /
45-1 LC2-M131A-11X STAY,2 1 (2002/10/7) NG /
46 LC2-M131B-00X STAY, 3 1 /
47
LC2-M131C-00X STAY, 4
1
/
48
LC2-M131N-00X SPACER
2
/
49 LC2-M130C-00X COVER,7 1 /
49-1 LC2-M130C-03X COVER,7 1 (2002/10/7) NG /
49-2 LC2-M130C-04X COVER,7 1 (2003/9/9) NG /
50 LC2-M1313-00X COVER,TOP 1 1 /
50-1 LC2-M1313-02X COVER,TOP 1 1 (2002/10/7) NG /
51 LC2-M1319-00X STAY,1 1 /
51-1 LC2-M1319-01X STAY,1 1 (2002/10/7) NG /
52 LC2-M131A-00X STAY,2 1 /
52-1 LC2-M131A-01X STAY,2 1 (2002/10/7) NG /
53 LC2-M130B-00X COVER,6 1 /
54 KV7-M8880-00X BRUSH,FEEDER 1 (2003/3/5) /
54-1 KV7-M8880-20X BRUSH,FEEDER 1 (2005/6/30) OK /
