Minor Maintenance Maintenance Tasks for Nozzles 3.2.5 Performing Maintenance Tasks 34 Maintenance Manual SIPLACE Placement Heads DLM3/DLM4
Minor Maintenance
3.2.5 Performing Maintenance Tasks Maintenance Tasks for Nozzles
Maintenance Manual SIPLACE Placement Heads DLM3/DLM4 33
3.2.5.2
3.2.5.2 Replacing the Plastic Nozzles
Replacing the Plastic Nozzles
► Remove a full nozzle magazine from the nozzle
changer. When handling a nozzle magazine which is
not full, make a note of the orientation in the nozzle
changer, to ensure correct reinsertion later on.
► Check the nozzles.
Replace damaged nozzles.
► If you are using nozzles with a nozzle ID (1), vacuum
the nozzle shaft (dust, components).
If you are unable to clean here, replace the nozzle.
► Place the nozzle magazine back in the nozzle chang
-
er. When handling a nozzle magazine which is not
full, pay attention to correct orientation in the nozzle
changer.
NOTICE!
Prepare additional nozzle magazines according to the
current nozzle configuration and replace the complete
magazine.
Minor Maintenance
Maintenance Tasks for Nozzles 3.2.5 Performing Maintenance Tasks
34 Maintenance Manual SIPLACE Placement Heads DLM3/DLM4
Major Maintenance
4.1.1 Maintenance Intervals Maintenance Tasks for DLM
Maintenance Manual SIPLACE Placement Heads DLM3/DLM4 35
4
4 Major Maintenance
Major Maintenance
4.1
4.1 Maintenance Tasks for DLM
Maintenance Tasks for DLM
4.1.1
4.1.1 Maintenance Intervals
Maintenance Intervals
5005 - Major - DLM C&P6/12
NOTICE
Differences between the heads
The instructions apply in principle to all DLM variants from DLM3 onwards.
Any differences will be explicitly indicated.
Maintenance Tasks
DLM C&P6/12
Duration
[min]
CP6/12
Each
week
Every 3
months
Every 6
months
Every 12
months
Cleaning the Turning Station Read Unit 2/2 X
Z axis:
▪ Clean the toothed belt
▪ Clean the rollers and toothed wheels
▪ Check the toothed belt
▪ Grease the toothed belt
▪ Check the Z axis guide
▪ Check the jaws
▪ Grease the Z axis guide
6/6 X
Star:
▪ Clean the star and the vacuum distributor disk
▪ Grease the running surface of the star brake
▪ Clean the segments
▪ Remove dirt from around the segments
3/4 X
Distributor:
▪ Clean and grease the O-rings
▪ Check the distributor piece.
▪ Clean the distributor
▪ Blow air through the distributor
▪ Check the ball catches
▪ Clean the seat
3/3 X
Star brake:
▪ Check for damage and function
▪ Wipe/remove grease
▪ Fill the holes with grease
▪ Grease the surface
2/2 X
Valve adjustment drives:
▪ Clean the valve adjustment drives
▪ Clean the disk and the space between
▪ Clean the ball bearings
▪ Check that the ball bearings are working cor
-
rectly
▪ Remove visible dirt
2/2 X
