Major Maintenance 4.1.2 Tools, Consumables, Spare and Wear Parts Maintenance Tasks for DLM Maintenance Manual SIPLACE Placement Heads DL M3/DLM4 37 Wear parts Item no. Star brake assembly DLM/RVC 03001653- xx PAS-LX-12 d…
Major Maintenance
Maintenance Tasks for DLM 4.1.2 Tools, Consumables, Spare and Wear Parts
36 Maintenance Manual SIPLACE Placement Heads DLM3/DLM4
4.1.2
4.1.2 Tools, Consumables, Spare and Wear Parts
Tools, Consumables, Spare and Wear Parts
Turning station:
▪ Clean the black O-rings
▪ Check the O-ring for damage
▪ Check the toothed belt for damage
▪ Clean the stop faces
▪ Clean the friction wheel
4/4 X
Vacuum generator:
▪ Installation/removal
▪ Clean the Venturi nozzles
▪ Blow air through Venturi nozzles
▪ Clean and grease the O-rings
▪ Clean and blow through the vacuum generator
block.
▪ Silencer: remove
▪ Silencer: clean holes to the Venturi nozzles
▪ Silencer: check for dirt
▪ Silencer: check the plastic fixtures
6/6 X
Component sensor
▪ Cleaning the Component Sensor
1/1 X
Installation and removal of the head front section 6/6 X
Calibrate and measure 20/25 X
Maintenance Tasks
DLM C&P6/12
Duration
[min]
CP6/12
Each
week
Every 3
months
Every 6
months
Every 12
months
Consumables Item no.
Protective latex gloves 00372972- xx
Cotton gloves, size 8 00359087- xx
Lint-free cloth, KM wipe 034082092- xx
Ethanol
Isopropanol – IPA can be used as an alternative.
SIPLACE cleanings ticks, lint-free 00352931- xx
Lubrication brush set 10 pieces 00370771- xx
Compressed Air
Microtips medium precision applicators (cleaning sticks) 03020860Sxx
ISOFLEX TOPAS, NCA 52 Tube 50 g 00330850- xx
UNISILKON L250L grease 00310259Sxx
Major Maintenance
4.1.2 Tools, Consumables, Spare and Wear Parts Maintenance Tasks for DLM
Maintenance Manual SIPLACE Placement Heads DLM3/DLM4 37
Wear parts Item no.
Star brake assembly DLM/RVC 03001653- xx
PAS-LX-12 distributor plate, complete 00368211- xx
Silencer for C&P head 03003134Sxx
O-ring for distributor 8*1 NBR 70 B 00201179Sxx
O-ring vacuum distributor 3*1,2 NBR 70 B 00320057Sxx
O-ring vacuum generator 10*1,5 NBR 70 B 00320047Sxx
O-ring vacuum generator 14*1,5 NBR 70 B 00320048Sxx
O-ring vacuum generator 8*1 Viton 75 00350661Sxx
O-ring vacuum generator 10*1 Viton 75 00350662Sxx
Synchroflex toothed belt 2.5 T2/90 (turning station) 00320041Sxx
O-ring turning station 16*2 E70B 00320043Sxx
Toothed belt T2 /DLM1 (Z axis DLM) 00334936Sxx
Vacuum nozzle diameter 1.0 00319423Sxx
For vacuum pump operation:
O-ring vacuum generator 30*1 00343022Sxx
Vacuum nozzle diameter 1.5 (rework for vacuum pump) 03003156- xx
For compressed air operation:
Vacuum nozzle diameter 1.5 00319420Sxx
Recommended spare parts Item no.
Star brake assembly DLM/RVC 03001653Sxx
PAS-LX-12 distributor plate, complete 00368211Sxx
Vacuum generator assembly 03003236Sxx
Distributor 00319827Sxx
Major Maintenance
Maintenance Tasks for DLM 4.1.2 Tools, Consumables, Spare and Wear Parts
38 Maintenance Manual SIPLACE Placement Heads DLM3/DLM4
See also
3.2.2 Tools, Consumables, Spare and Wear Parts [ ➙ 26]
Tools Item no.
Extension / straight 03043440- xx
Extension / with joint (170 x SK3) 03042635- xx
ESD wriststrap TYP.OK/WRS 00320279- xx
Universal placement head mounting rack 03056231- xx
Antistatic tweezers, type Bernstein 5
-
192 00377393- xx
Antistatic tweezers, type Bernstein 5
-
195 00377394- xx
TorqueVario-S screwdriver (1.0-5.0 Nm) 03078400- xx
Bit holder for TorqueVario screwdriver 03078706- xx
Extension / straight TX20 03073256- xx
Hexagon socket head cap screwdriver 0.7-2 00320265- xx
Torx Allen screwdriver TX8 03080081- xx
Calibration tool version SST23 03034148- xx
Set of Allen keys 00376492- xx
Set of Phillips screwdrivers 00319064- xx
Angled tweezers 00096487- xx
Oil dispenser Z axis with STRUCTVIS GHD 7 ml 00367071- xx
Cleaning tools for encoder disk 03049704Sxx
Pliers for fitting plastic hose 2MS-PK-3/4 00346929- xx
Calibration tool version 3 03010565- xx
Additionally required documentation Item no.
If required, service manual for removal and installation of placement head
in your machine.
► Note: You need more tools etc.
Assembling instruction for "component sensor" [00193356-xx], if required 00193356- xx
If required, assembly instructions "Universal placement head mounting
rack"
00196371- xx
Maintenance manual "Greasing the valve plunger with tool" 00195066- xx
