KHJ_SS_M-PL - 第3页
4 6 7 9 16 1 1 8 1 1 16 10 12 13 2 3 16 1 15 14 5 17 18 No. Part No. Part Name Q’ty Remarks 1 KHJ-MC106-00 PLA TE,UNDER 1 2 KHJ-MC16B-00 SHAFT ,P/O LEVER 2 1 3 KHJ-MC16E-00 SPRING,P/O LEVER 1 4 KHJ-MC16V -02 P/O LEVER AS…
Contents
KHJ-1001
NOTE:Serial No.Seal
Kind of Feeder
Type
1 SSY-008-A
................................ 1-1~1-2
(KHJ-MC100-00)
2 SSY-2T6-A
................................ 2-1~2-2
(KHJ-MC200-00)
3 SSY-024-A
................................ 3-1~3-2
(KHJ-MC400-00)
4 SSY-032-A
................................ 4-1~4-2
(KHJ-MC500-00)
5 SSY-044-A
................................ 5-1~5-2
(KHJ-MC600-00)
6 SSY-056-A
................................ 6-1~6-2
(KHJ-MC700-00)
7 SSY-072-A
................................ 7-1~7-2
(KHJ-MC800-00)
8 SSY-088-A
................................ 8-1~8-2
(KHJ-MC900-00)
4
6
7
9
16
11
8
11
16
10
12
13
2
3
16
1
15
14
5
17
18
No. Part No. Part Name Q’ty Remarks
1
KHJ-MC106-00
PLATE,UNDER
1
2
KHJ-MC16B-00
SHAFT,P/O LEVER 2
1
3
KHJ-MC16E-00 SPRING,P/O LEVER
1
4
KHJ-MC16V-02 P/O LEVER ASSY.
1
5
KHJ-MC1A9-00 CONNECTOR,BOARD
1
6
KLJ-MC141-00 TAPE GUIDE
1
STD
KLJ-MC14A-00 TAPE GUIDE,W8P1
1
1mm Pitch
KLJ-MC14B-00 TAPE GUIDE,W8P4
1
4mm Pitch
7
KHJ-MC144-00 LEVER,TAPE GUIDE R
1
8
KHJ-MC145-01 LEVER,TAPE GUIDE F
1
9
KHJ-MC146-02 SPRING,TAPE GUIDE R
1
10
KHJ-MC147-02 SPRING,TAPE GUIDE F
1
11
KHJ-MC15A-00 SHAFT 112
2
12
KHJ-MC104-00 RAIL,UNDER
1
13
KHJ-MC10F-00 SCREW,FLAT HEAD
2
14
90166-02JA08 SCREW PAN H.:M2.5X8
2
15
91317-03006 BOLT HEX.SOCKET HEAD
2
16
92A08-03303 SET SCREW M3X3
3
17
KHJ-MC149-00 STOPPER,LEVER R
1
18
KHJ-MC141-S0 PARTS,TAPE GUIDE
1
STD
KHJ-MC14A-S0 PARTS,TAPE GUIDE P1
1
1mm Pitch
KHJ-MC14B-S0 PARTS,TAPE GUIDE P4
1
4mm Pitch
KHJ-1110
1
1
TAPE GUIDE 8mm
No. Part No. Part Name Q'ty Remarks
1
KHJ-MC10W-00
FRONT BLOCK ASSY
1
2
KHJ-MC105-00
PIN,TAIL
1
3
KHJ-MC10M-00 BOLT,HEX. S/H
2
4
KHJ-MC139-00 SHAFT,IDLE GEAR 1
1
5
KHJ-MC16J-00 SCREW,FLAT HEAD
4
6
KHJ-MC181-00 HANDLE
1
7
KHJ-MC182-00 TENSION,WIRE 1
1
8
KHJ-MC183-00 SPACER,TENSION 1
1
9
KHJ-MC184-00 SPACER,TENSION 2
3
10
KHJ-MC185-00 PIN,HANDLE
1
11
KHJ-MC186-00 WIRE,UNCLAMP
1
12
KHJ-MC187-00 SPRING,TENSION
1
13
KHJ-MC189-01 PIN,CLAMP
1
14
KHJ-MC18A-00 SPRING,CLAMP
1
15
KHJ-MC18B-00 COVER,WIRE 1
1
16
KHJ-MC18C-00 COVER,WIRE 2
1
17
KLJ-MC18H-00 CLAMP LEVER ASSY.
1
18
91312-03008 BOLT HEX.SOCKET HEAD
2
19
92A08-03305 SCREW,SET
2
20
98702-03006 SCREW FLAT HEAD
1
19
6
10
8
7
9
12
11
5
16
5
15
18
413
3
1
14
17
19
20
2
KHJ-1110
1
2
CLAMP 8mm
