2 5 19 9 6 7 12 3 8 4 17 18 10 1 1 14 17 13 15 16 1 16 No. Part No. Part Name Q’ty Remarks 1 KHJ-MC10W -00 FRONT BLOCK ASSY 1 2 KHJ-MC105-00 PIN,T AIL 1 3 KHJ-MC16J-00 SCREW ,FLA T HEAD 1 1 4 KHJ-MC281-00 HANDLE 1 5 KHJ-…
No. Part No. Part Name Q’ty Remarks
1
KHJ-MC206-00
PLATE,UNDER
1
2
KHJ-MC241-05
TAPE GUIDE ASSY. 16
1
16mm Use
3
KHJ-MC24J-04 TAPE GUIDE ASSY.12
1
12mm Use
4
KHJ-MC244-00 LEVER,TAPE GUIDE R
1
5
KHJ-MC245-01 LEVER,TAPE GUIDE F
1
6
KHJ-MC146-02 SPRING,TAPE GUIDE R
1
7
KHJ-MC247-01 SPRING,TAPE GUIDE F
1
8
KHJ-MC24D-00 PLATE,GUIDE 12
1
9
KHJ-MC26E-00 SPRING,P/O LEVER
1
10
KHJ-MC26V-00 P/O LEVER ASSY.
1
11
KHJ-MC1A9-00 CONNECTOR,BOARD
1
12
KHJ-MC104-00 RAIL,UNDER
1
13
KHJ-MC10F-00 SCREW,FLAT HEAD
2
14
98707-03006 SCREW,FLAT HEAD
4
15
90166-02JA08 SCREW PAN H.:M2.5X8
2
16
92A08-03303 SET SCREW M3X3
2
17
99480-04022 PIN,PARALLEL
2
18
99480-05018 PIN,PARALLEL
1
19
KHJ-MC24W-S0 HOOK TAPE GUIDE KIT
1
11
15
10
18
9
16
17
5
8
1
14
12
13
14
16
7
4
6
16
17
2
3
19
KHJ-1110
2
1
TAPE GUIDE 12mm/16mm
2
5
19
9
6
7
12
3
8
4
17
1810
11
14
17
13
15
16
1
16
No. Part No. Part Name Q’ty Remarks
1
KHJ-MC10W-00 FRONT BLOCK ASSY
1
2
KHJ-MC105-00 PIN,TAIL
1
3
KHJ-MC16J-00 SCREW,FLAT HEAD
11
4
KHJ-MC281-00 HANDLE
1
5
KHJ-MC182-00 TENSION,WIRE 1
1
6
KHJ-MC183-00 SPACER,TENSION 1
1
7
KHJ-MC184-00 SPACER,TENSION 2
1
8
KHJ-MC286-00 WIRE,UNCLAMP
1
9
KHJ-MC187-00 SPRING,TENSION
1
10
KHJ-MC289-00 PIN,CLAMP
1
11
KHJ-MC18A-00 SPRING,CLAMP
1
12
KHJ-MC28B-00 COVER,WIRE 1
1
13
KHJ-MC18F-00 CIRCLIP (E)
1
14
KHJ-MC28H-00 CLAMP LEVER ASSY.
1
15
90440-01J030 CIRCLIP(E)
1
16
91317-03008 BOLT HEX.SOCKET HEAD
1
17
92A08-03303 SET SCREW M3X3
2
18
99480-04018 PIN,PARALLEL
1
19
99480-05012 PIN,PARALLEL
1
KHJ-1001
2
2
CLAMP 12mm/16mm
No. Part No. Part Name Q’ty Remarks
1
KHJ-MC406-00 PLATE,UNDER
1
2
KHJ-MC441-04 TAPE GUIDE ASSY.
1
3
KHJ-MC244-00 LEVER,TAPE GUIDE R
1
4
KHJ-MC445-01 LEVER,TAPE GUIDE F
1
5
KHJ-MC146-02 SPRING,TAPE GUIDE R
1
6
KHJ-MC247-01 SPRING,TAPE GUIDE F
1
7
KHJ-MC26E-00 SPRING,P/O LEVER
1
8
KHJ-MC46V-00 P/O LEVER ASSY.
1
9
KHJ-MC1A9-00 CONNECTOR,BOARD
1
10
KHJ-MC104-00 RAIL,UNDER
1
11
KHJ-MC10F-00 SCREW,FLAT HEAD
2
12
98707-03006 SCREW,FLAT HEAD
2
13
90166-02JA08 SCREW PAN H.:M2.5X8
2
14
92A08-03303 SET SCREW M3X3
5
15
99480-04030 PIN,PARALLEL
2
16
99480-05025 PIN,PARALLEL
1
17
KHJ-MC44W-S0 HOOK TAPE GUIDE KIT
1
10
11
9
13
3
5
14
2
17
15
8
16
7
14
1
12
15
4
6
14
KHJ-1110
3
1
TAPE GUIDE 24mm
