Error ID Item Description 050106 Y 2 Axis Origin Y axis origin data (Y2) is over range. (Cause 1) See the indication. (Remedy 1) Set parameter (offset) in the "Y2[mm]" text box of the label "Y-axis origin&…
Error ID Item Description
050101 Y2 Axis Origin Encoder origin was not detected.
050102 Y2 Axis Origin Origin sensor (slide) was not detected.
050103 Y2 Axis Origin Origin sensor (slide) and Limit error has been de-
tected.
050104 Y2 Axis Origin Feedback value is indefinite.
050105 Y2 Axis Origin Y2 axis is not at origin.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-002 2-26-1 AHB01ETRP
Error ID Item Description
050106 Y2 Axis Origin Y axis origin data (Y2) is over range.
(Cause 1) See the indication.
(Remedy 1) Set parameter
(offset) in the "Y2[mm]" text box of the label "Y-axis origin".
050201 Y2 Axis Timing Task has not been completed unable to continue.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
050301 Y2 Axis Data The driver data was detected outside of the possible
range.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
050401 Y2 Axis Limit (+) Limit error has been detected.
050402 Y2 Axis Limit (-) Limit error has been detected.
(Cause 1) The X1 axis might have overrun due to generation of noises, overcurrent, etc.
The sensor may be defective.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-001 2-26-2 AHB01ETRP
Error ID Item Description
050502 Y2 Axis Servo Alarm Parameter breakdown.
050503 Y2 Axis Servo Alarm Main circuit encoder error.
050504 Y2 Axis Servo Alarm Parameter setting error.
050505 Y2 Axis Servo Alarm Combination error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
050510 Y2 Axis Servo Alarm Overcurrent or heat sink overheated.
050530 Y2 Axis Servo Alarm Regenaration error detected.
050532 Y2 Axis Servo Alarm Regenarative overload.
050540 Y2 Axis Servo Alarm Overvoltage.
050541 Y2 Axis Servo Alarm Undervoltage.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-002 2-27 AHB01ETRP
