Error ID Item Description
0e0301 Conveyor L Axis
0e0401 Conveyor L Axis
0e0402 Conveyor L Axis
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0e0601 Conveyor L Axis Interlock Driver Alarm
0e0602 Conveyor L Axis Interlock
0e0603 Conveyor L Axis Interlock
0e0604 Conveyor L Axis Interlock
0e0605 Conveyor L Axis Interlock
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0f0101 Conveyor P Axis
0f0102 Conveyor P Axis
0f0103 Conveyor P Axis
0f0110 Conveyor P Axis
0f0111 Conveyor P Axis
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-002 2-63 AHB01ETRP
Error ID Item Description
0f0301 Conveyor P Axis
0f0401 Conveyor P Axis
0f0402 Conveyor P Axis
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0f0601 Conveyor P Axis Driver Alarm
0f0602 Conveyor P Axis
0f0603 Conveyor P Axis
0f0604 Conveyor P Axis
0f0605 Conveyor P Axis
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
100101 Conveyor R Axis
100102 Conveyor R Axis
100103 Conveyor R Axis
100110 Conveyor R Axis
100111 Conveyor R Axis
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-002 2-64 AHB01ETRP
Error ID Item Description
100301 Conveyor R Axis
100401 Conveyor R Axis
100402 Conveyor R Axis
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
100601 Conveyor R Axis Interlock Driver Alarm
100602 Conveyor R Axis Interlock
100603 Conveyor R Axis Interlock
100604 Conveyor R Axis Interlock
100605 Conveyor R Axis Interlock
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
110101 TV #1 Axis Origin Rack shutter not opened within specified time. (5101)
110102 TV #1 Axis Origin Pallet chuck not closed within specified time. (5102)
110103 TV #1 Axis Origin Operatiing condition for zeroing not fulfilled. (5103)
110104 TV #1 Axis Origin Pallet installation error detected; BPH504/505 (5201)
110105 TV #1 Axis Origin Pallet detected. (5202)
110106 TV #1 Axis Origin Operation not completed normally. (5203)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
