Error ID Item Description 130530 Elevator #1 Axis Servo Alarm Regenaration error detected. 130532 Elevator #1 Axis Servo Alarm Regenarative overload. 130540 Elevator #1 Axis Servo Alarm Overvoltage. 130541 Elevator #1 Ax…
Error ID Item Description
130201 Elevator #1 Axis Timing Task has not been completed unable to continue.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
130301 Elevator #1 Axis Data The driver data was detected outside of the possible
range.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
130401 Elevator #1 Axis Limit (+) Limit error has been detected.
130402 Elevator #1 Axis Limit (-) Limit error has been detected.
(Cause 1) The X1 axis might have overrun due to generation of noises, overcurrent, etc.
The sensor may be defective.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
130502 Elevator #1 Axis Servo Alarm Parameter breakdown.
130503 Elevator #1 Axis Servo Alarm Main circuit encoder error.
130504 Elevator #1 Axis Servo Alarm Parameter setting error.
130505 Elevator #1 Axis Servo Alarm Combination error.
130510 Elevator #1 Axis Servo Alarm Overcurrent or heat sink overheated.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-002 2-78 AHB01ETRP
Error ID Item Description
130530 Elevator #1 Axis Servo Alarm Regenaration error detected.
130532 Elevator #1 Axis Servo Alarm Regenarative overload.
130540 Elevator #1 Axis Servo Alarm Overvoltage.
130541 Elevator #1 Axis Servo Alarm Undervoltage.
130551 Elevator #1 Axis Servo Alarm Overspeed.
130571 Elevator #1 Axis Servo Alarm Overload: High load.
130572 Elevator #1 Axis Servo Alarm Overload: Low load.
130573 Elevator #1 Axis Servo Alarm Dynamic brake overload.
130574 Elevator #1 Axis Servo Alarm Overload of surge current limit resistor.
13057a Elevator #1 Axis Servo Alarm Heat sink overheated.
130581 Elevator #1 Axis Servo Alarm Encoder backup error.
130582 Elevator #1 Axis Servo Alarm Encoder checksum error.
130583 Elevator #1 Axis Servo Alarm Absolute encoder battery error.
130584 Elevator #1 Axis Servo Alarm Encoder data error.
130585 Elevator #1 Axis Servo Alarm Encoder overspeed.
130586 Elevator #1 Axis Servo Alarm Encoder overheated.
130591 Elevator #1 Axis Servo Alarm Overload warning.
130592 Elevator #1 Axis Servo Alarm Regenerative overload warning.
130594 Elevator #1 Axis Servo Alarm Setting warning.
130595 Elevator #1 Axis Servo Alarm Command warning.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-002 2-79 AHB01ETRP
Error ID Item Description
130596 Elevator #1 Axis Servo Alarm Communications warning.
1305b1 Elevator #1 Axis Servo Alarm Reference speed input read error.
1305b2 Elevator #1 Axis Servo Alarm Reference torque input read error.
1305b6 Elevator #1 Axis Servo Alarm Gate array error.
1305bf Elevator #1 Axis Servo Alarm System alarm.
1305c1 Elevator #1 Axis Servo Alarm Servo overrun detected.
1305c6 Elevator #1 Axis Servo Alarm Fully closed loop phase A/B disconnected.
1305c7 Elevator #1 Axis Servo Alarm Fully closed loop phase C disconnected.
1305c8 Elevator #1 Axis Servo Alarm Absolute encoder clear error and multiturn limit
setting error.
1305c9 Elevator #1 Axis Servo Alarm Encoder communications error.
1305ca Elevator #1 Axis Servo Alarm Encoder parameter error.
1305cb Elevator #1 Axis Servo Alarm Encoder echoback error.
1305cc Elevator #1 Axis Servo Alarm Multiturn limit disagreement.
1305d0 Elevator #1 Axis Servo Alarm Position error pulse overflow.
1305e0 Elevator #1 Axis Servo Alarm No option unit installed.
1305e1 Elevator #1 Axis Servo Alarm No response from the board in the option unit.
1305e2 Elevator #1 Axis Servo Alarm Option WDC error.
1305e5 Elevator #1 Axis Servo Alarm WDT error.
1305e6 Elevator #1 Axis Servo Alarm Communications error.
1305ea Elevator #1 Axis Servo Alarm SERVOPACK damaged.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
