Error ID Item Description 132008 Elevator #1 Axis Move Check 132009 Elevator #1 Axis Move Check 13200a Elevator #1 Axis Move Check 13200b Elevator #1 Axis Move Check 13200c Elevator #1 Axis Move Check 13200d Elevator #1 …
Error ID Item Description
131003 Elevator #1 Axis Move Check Multi-layer tray feeder door opened. (K504)
131004 Elevator #1 Axis Move Check Safty relay off; K502
131005 Elevator #1 Axis Move Check Pallet installation error detected (on operator or
drawing side).; BPH504/505
131006 Elevator #1 Axis Move Check Rack shutter opened.; BPS502/504
131007 Elevator #1 Axis Move Check Pallet chuck opened.; BPS512
131008 Elevator #1 Axis Move Check L1 Axis Zeroing not completed
131009 Elevator #1 Axis Move Check
13100a Elevator #1 Axis Move Check
13100b Elevator #1 Axis Move Check Pallet detected.; BPS514
13100c Elevator #1 Axis Move Check
13100d Elevator #1 Axis Move Check
13100e Elevator #1 Axis Move Check Drawing step No. indefinite. Remove the pallet.
13100f Elevator #1 Axis Move Check Incorrect No. of Drawing Step
132001 Elevator #1 Axis Move Check
132002 Elevator #1 Axis Move Check
132003 Elevator #1 Axis Move Check
132004 Elevator #1 Axis Move Check
132005 Elevator #1 Axis Move Check Pallet installation error detected on operator side.;
BPH505
132006 Elevator #1 Axis Move Check Rack shutter closed.; BPS501/503
132007 Elevator #1 Axis Move Check
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-002 2-83 AHB01ETRP
Error ID Item Description
132008 Elevator #1 Axis Move Check
132009 Elevator #1 Axis Move Check
13200a Elevator #1 Axis Move Check
13200b Elevator #1 Axis Move Check
13200c Elevator #1 Axis Move Check
13200d Elevator #1 Axis Move Check
13200e Elevator #1 Axis Move Check
13200f Elevator #1 Axis Move Check
133001 Elevator #1 Axis Move Check
133002 Elevator #1 Axis Move Check
133003 Elevator #1 Axis Move Check
133004 Elevator #1 Axis Move Check
133005 Elevator #1 Axis Move Check Pallet installation error detected on traverse side;
BPH504
133006 Elevator #1 Axis Move Check
133007 Elevator #1 Axis Move Check
133008 Elevator #1 Axis Move Check
133009 Elevator #1 Axis Move Check
13300a Elevator #1 Axis Move Check
13300b Elevator #1 Axis Move Check
13300c Elevator #1 Axis Move Check
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-002 2-84 AHB01ETRP
Error ID Item Description
13300d Elevator #1 Axis Move Check
13300e Elevator #1 Axis Move Check
13300f Elevator #1 Axis Move Check
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
13f001 Elevator #1 Axis Operation Error Tray No. Error
13f002 Elevator #1 Axis Operation Error Step No. Error
13f003 Elevator #1 Axis Operation Error Designated speed error.
13f004 Elevator #1 Axis Operation Error Destination error
13f005 Elevator #1 Axis Operation Error Destination error
13f006 Elevator #1 Axis Operation Error Overtime in Operation
13f007 Elevator #1 Axis Operation Error Operation error
13f008 Elevator #1 Axis Operation Error Emergency stop
13f009 Elevator #1 Axis Operation Error
13f00a Elevator #1 Axis Operation Error
13f00b Elevator #1 Axis Operation Error
13f00c Elevator #1 Axis Operation Error
13f00d Elevator #1 Axis Operation Error
13f00e Elevator #1 Axis Operation Error
13f00f Elevator #1 Axis Operation Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0206-002 2-85 AHB01ETRP
3.3 Error IDs and Remedial Procedures
