Error ID Item Description
600101 Load Power Shutoff
600102 Load Power Shutoff
600103 Load Power Shutoff
600104 Load Power Shutoff
600105 Load Power Shutoff Load Power is OFF
600106 Load Power Shutoff
600107 Load Power Shutoff Load Power ON Out of Time Limit
600108 Load Power Shutoff
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0308-001 2-97-1 AHB01ETRP
Error ID Item Description
600201 Beam Power Shutoff
600202 Beam Power Shutoff Load Beam Power ON Out of Time Limit
600203 Beam Power Shutoff
600301 B Beam Power Shutoff
600302 B Beam Power Shutoff
600303 B Beam Power Shutoff
600401 Interlock Error
600402 Interlock Error
600403 Interlock Error
600404 Interlock Error
600405 Interlock Error
600406 Interlock Error
600407 Interlock Error
600408 Interlock Error
600409 Interlock Error
60040a Interlock Error
60040b Interlock Error
60040c Interlock Error
60040d Interlock Error
60040e Interlock Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-002 2-98 AHB01ETRP
Error ID Item Description
600501 Safety Circuit Activated
600502 Safety Circuit Activated Load Beam Power ON Out of Time Limit
600503 Safety Circuit Activated
600504 Safety Circuit Activated
600505 Safety Circuit Activated
610101 Nozzle Allocation No nozzle is specified in the current pattern program
data.
(Cause 1) The nozzles to be used in the current pattern program data are not prepared.
(Remedy 1) Set the nozzles for the production model in the nozzle stocker data and perform
the program change operation.
610102 Nozzle Allocation
610201 Recognition Internal Data XXXX
610301 Component Recognition Data
610302 Component Recognition Data
610401 Nozzle Replace Data No effective step exists in the current pattern pro-
gram when the nozzle change data is created.
610402 Nozzle Replace Data Adequate memory capacity was not left when the
nozzle change data was created.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
610403 Nozzle Replace Data Control Commands "-" were not specified for both
primary and secondary nozzles in the component
library data.
(Cause 1) The correct parameters are not set in the "Control command" text boxes of the
labels "Selected nozzle #1" and "Selected nozzle #2" in the component library data.
(Remedy 1) Set correct parameters.
3.3 Error IDs and Remedial Procedures
0308-003 2-99 AHB01ETRP
